NISSAN TEANA 2008 Service Manual EM-142
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
*1: Diameter made by intersection point of conic angles “α1” and “α2”
*
2: Diameter made b

Page 2018 of 5121

NISSAN TEANA 2008 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-143
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Unit: mm (in)
Cylinder BlockINFOID:0000000003802307
CYLINDER BLOCK
Unit: mm (in)
I

SERVICE DATA AND SPECIFICATIONS (SDS)
EM-143
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Unit: mm (in)
Cylinder BlockINFOID:0000000003802307
CYLINDER BLOCK
Unit: mm (in)
Items Limit
Squareness2.1 (0.083)
Engine VQ25DE VQ35DE
Surface flatnessStandard Less than 0.03 (0.0012)
Limit 0.1 (0.004)
Main bearing housing inner
diameterStandard 63.993 - 64.017 (2.5194 - 2.5203)
Cylinder
boreInner diame-
terStandardGrade No. 1 85.000 - 85.010 (3.3465 - 3.3468) 95.500 - 95.510 (3.7598 - 3.7602)
Grade No. 2 85.010 - 85.020 (3.3468 - 3.3472) 95.510 - 95.520 (3.7602 - 3.7606)
Grade No. 3 85.020 - 85.030 (3.3472 - 3.3476) 95.520 - 95.530 (3.7606 - 3.7610)
Wear limit 0.2 (0.008)
Out-of-round
Limit0.015 (0.0006)
Ta p e r 0.010 (0.0004)
Main bearing housing inner diameter
grade (Without bearing)Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W
Grade No. X
Grade No. Y
Grade No. 4
Grade No. 763.993 - 63.994 (2.5194 - 2.5194)
63.994 - 63.995 (2.5194 - 2.5195)
63.995 - 63.996 (2.5195 - 2.5195)
63.996 - 63.997 (2.5195 - 2.5196)
63.997 - 63.998 (2.5196 - 2.5196)
63.998 - 63.999 (2.5196 - 2.5196)
63.999 - 64.000 (2.5196 - 2.5197)
64.000 - 64.001 (2.5197 - 2.5197)
64.001 - 64.002 (2.5197 - 2.5198)
64.002 - 64.003 (2.5198 - 2.5198)
64.003 - 64.004 (2.5198 - 2.5198)
64.004 - 64.005 (2.5198 - 2.5199)
64.005 - 64.006 (2.5199 - 2.5199)
64.006 - 64.007 (2.5199 - 2.5200)
64.007 - 64.008 (2.5200 - 2.5200)
64.008 - 64.009 (2.5200 - 2.5200)
64.009 - 64.010 (2.5200 - 2.5201)
64.010 - 64.011 (2.5201 - 2.5201)
64.011 - 64.012 (2.5201 - 2.5202)
64.012 - 64.013 (2.5202 - 2.5202)
64.013 - 64.014 (2.5202 - 2.5202)
64.014 - 64.015 (2.5202 - 2.5203)
64.015 - 64.016 (2.5203 - 2.5203)
64.016 - 64.017 (2.5203 - 2.5203)
Difference in inner diameter
between cylindersStandard Less than 0.03 (0.0012)
JPBIA2238GB

Page 2019 of 5121

NISSAN TEANA 2008 Service Manual EM-144
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
AVAILABLE PISTON
VQ25DE
Unit: mm (in)
VQ35DE
Unit: mm (in)
PISTON RING
Items Standard Oversize (Service) [0.2 (0.0

Page 2020 of 5121

NISSAN TEANA 2008 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-145
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O VQ25DE
Unit: mm (in)
VQ35DE
Unit: mm (in)
PISTON PIN
Unit: mm (in)
CONNECTING ROD

Page 2021 of 5121

NISSAN TEANA 2008 Service Manual EM-146
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
*: Total indicator reading
Main BearingINFOID:0000000003802308
MAIN BEARING
Engine VQ25DE VQ35DE
Mai

EM-146
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
*: Total indicator reading
Main BearingINFOID:0000000003802308
MAIN BEARING
Engine VQ25DE VQ35DE
Main journal diameter. “Dm”
gradeStandardGrade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W
Grade No. X
Grade No. Y
Grade No. 4
Grade No. 759.975 - 59.974 (2.3612 - 2.3612)
59.974 - 59.973 (2.3612 - 2.3611)
59.973 - 59.972 (2.3611 - 2.3611)
59.972 - 59.971 (2.3611 - 2.3611)
59.971 - 59.970 (2.3611 - 2.3610)
59.970 - 59.969 (2.3610 - 2.3610)
59.969 - 59.968 (2.3610 - 2.3609)
59.968 - 59.967 (2.3609 - 2.3609)
59.967 - 59.966 (2.3609 - 2.3609)
59.966 - 59.965 (2.3609 - 2.3608)
59.965 - 59.964 (2.3608 - 2.3608)
59.964 - 59.963 (2.3608 - 2.3607)
59.963 - 59.962 (2.3607 - 2.3607)
59.962 - 59.961 (2.3607 - 2.3607)
59.961 - 59.960 (2.3607 - 2.3606)
59.960 - 59.959 (2.3606 - 2.3606)
59.959 - 59.958 (2.3606 - 2.3605)
59.958 - 59.957 (2.3605 - 2.3605)
59.957 - 59.956 (2.3605 - 2.3605)
59.956 - 59.955 (2.3605 - 2.3604)
59.955 - 59.954 (2.3604 - 2.3604)
59.954 - 59.953 (2.3604 - 2.3603)
59.953 - 59.952 (2.3603 - 2.3603)
59.952 - 59.951 (2.3603 - 2.3603)
Pin journal diameter. “Dp” grade StandardGrade No. 0 44.968 - 44.974 (1.7704 - 1.7706) 51.968 - 51.974 (2.0460 - 2.0462)
Grade No. 1 44.962 - 44.968 (1.7702 - 1.7704) 51.962 - 51.968 (2.0457 - 2.0460)
Grade No. 2 44.956 - 44.962 (1.7699 - 1.7702) 51.956 - 51.962 (2.0445 - 2.0457)
Center distance “r” 36.61 - 36.69 (1.4413 - 1.4445) 40.66 - 40.74 (1.6008 - 1.6039)
Taper (Difference between “A”
and “B”)
Limit0.002 (0.0001)
Out-of-round (Difference between
“X” and “Y”)0.002 (0.0001)
Crankshaft runout [TIR*]Standard Less than 0.05 (0.0020)
Limit 0.10 (0.0039)
Crankshaft end playStandard 0.10 - 0.25 (0.0039 - 0.0098)
Limit 0.30 (0.0118)
SEM645SBIA0535E

Page 2022 of 5121

NISSAN TEANA 2008 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-147
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Unit: mm (in)
UNDERSIZE
Unit: mm (in)
MAIN BEARING OIL CLEARANCE
Unit: mm (in)
*:

Page 2023 of 5121

NISSAN TEANA 2008 Service Manual EM-148
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
UNDERSIZE
Unit: mm (in)
CONNECTING ROD BEARING OIL CLEARANCE
Unit: mm (in)
*: Actual clearanceGrade
