Page 3009 of 5121

NISSAN TEANA 2008 Service Manual INT-32 < ON-VEHICLE REPAIR > FRONT DOOR FINISHER 7. Disconnect lock knob cable (1), inside handle cable (2), power window switch finisher harness connectors (B) and seat memory switch harness connecto

Page 3010 of 5121

NISSAN TEANA 2008 Service Manual FRONT DOOR FINISHER INT-33 < ON-VEHICLE REPAIR > C D E F G H I K L MA B INT N O P PASSENGER SIDE : Exploded ViewINFOID:0000000003819218 PASSENGER SIDE : Removal and InstallationINFOID:0000000003819219

Page 3011 of 5121

NISSAN TEANA 2008 Service Manual INT-34 < ON-VEHICLE REPAIR > FRONT DOOR FINISHER 2. Remove inside handle escutcheon (1) with a flat-bladed screw- driver (A) wrapped in a tape as shown in the figure. 3. Remove screw (A) located on th

Page 3012 of 5121

NISSAN TEANA 2008 Service Manual FRONT DOOR FINISHER INT-35 < ON-VEHICLE REPAIR > C D E F G H I K L MA B INT N O P 7. Remove step lamp and then disconnect the harness connector. Refer to INL-96, "Removal and Installa- tion". 8. Inser

Page 3013 of 5121

NISSAN TEANA 2008 Service Manual INT-36 < ON-VEHICLE REPAIR > REAR DOOR FINISHER REAR DOOR FINISHER Exploded ViewINFOID:0000000003819220 Removal and InstallationINFOID:0000000003819221 CAUTION: Wrap the tip of flat-bladed screwdriver

Page 3014 of 5121

NISSAN TEANA 2008 Service Manual REAR DOOR FINISHER INT-37 < ON-VEHICLE REPAIR > C D E F G H I K L MA B INT N O P 2. Remove inside handle escutcheon (1) with a flat-bladed screw- driver (A) wrapped in a tape as shown in the figure. 3

Page 3015 of 5121

NISSAN TEANA 2008 Service Manual INT-38 < ON-VEHICLE REPAIR > REAR DOOR FINISHER 7. Insert a remover tool (A) between the door finisher and door panel to disengage the clips. CAUTION: Insert a remover tool (A) into the part shown in

Page 3016 of 5121

NISSAN TEANA 2008 Service Manual BODY SIDE TRIM INT-39 < ON-VEHICLE REPAIR > C D E F G H I K L MA B INT N O P BODY SIDE TRIM Exploded ViewINFOID:0000000003819222 Removal and InstallationINFOID:0000000003819223 CAUTION:  Wrap the tip
