NISSAN TEANA 2008 Service Manual EC-284
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1720 VSS
3.CHECK COMBINATION METER FUNCTION
Refer to MWI-67, "
DTC Index".
>> INSPECTION END

Page 1746 of 5121

NISSAN TEANA 2008 Service Manual P1800 VIAS CONTROL SOLENOID VALVE 1
EC-285
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1800 VIAS CONTROL SOLENOID VALVE 1
DescriptionINFOID:0000000003856768
The VIAS contr

P1800 VIAS CONTROL SOLENOID VALVE 1
EC-285
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1800 VIAS CONTROL SOLENOID VALVE 1
DescriptionINFOID:0000000003856768
The VIAS control solenoid valve 1 cuts the intake manifold vacuum signal for power valve 1 control. It
responds to ON/OFF signals from the ECM. When the solenoid is OFF, the vacuum signal from the intake
manifold is cut. When the ECM sends an ON signal the coil pulls the plunger downward and sends the vac-
uum signal to the power valve actuator 1.
DTC LogicINFOID:0000000003856769
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm battery voltage is more than 11 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-285, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003856770
1.CHECK VIAS CONTROL SOLENOID VALVE 1 POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect VIAS control solenoid valve 1 harness connector.
3. Turn ignition switch ON.
4. Check the voltage between VIAS control solenoid valve 1 harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
2.CHECK VIAS CONTROL SOLENOID VALVE 1 OUTPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between VIAS control solenoid valve 1 harness connector and ECM harness con-
nector.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1800VIAS control solenoid valve 1
circuitAn excessively low or high voltage signal
is sent to ECM through the VIAS control
solenoid valve 1. Harness or connectors
(The solenoid valve 1 circuit is open or
shorted.)
VIAS control solenoid valve 1
VIAS control solenoid valve 1
Ground Voltage
Connector Terminal
F74 1 Ground Battery voltage

Page 1747 of 5121

NISSAN TEANA 2008 Service Manual EC-286
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1800 VIAS CONTROL SOLENOID VALVE 1
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >>

Page 1748 of 5121

NISSAN TEANA 2008 Service Manual P1800 VIAS CONTROL SOLENOID VALVE 1
EC-287
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Replace VIAS control solenoid valve 1

Page 1749 of 5121

NISSAN TEANA 2008 Service Manual EC-288
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1801 VIAS CONTROL SOLENOID VALVE 2
P1801 VIAS CONTROL SOLENOID VALVE 2
DescriptionINFOID:0000000003856772
The VIAS control solenoid valve 2 cuts the int

EC-288
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1801 VIAS CONTROL SOLENOID VALVE 2
P1801 VIAS CONTROL SOLENOID VALVE 2
DescriptionINFOID:0000000003856772
The VIAS control solenoid valve 2 cuts the intake manifold vacuum signal for power valve 2 control. It
responds to ON/OFF signals from the ECM. When the solenoid is OFF, the vacuum signal from the intake
manifold is cut. When the ECM sends an ON signal the coil pulls the plunger downward and sends the vac-
uum signal to the power valve actuator 2.
DTC LogicINFOID:0000000003856773
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm battery voltage is more than 11 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-288, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003856774
1.CHECK VIAS CONTROL SOLENOID VALVE 2 POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect VIAS control solenoid valve 2 harness connector.
3. Turn ignition switch ON.
4. Check the voltage between VIAS control solenoid valve 2 harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
2.CHECK VIAS CONTROL SOLENOID VALVE 2 OUTPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between VIAS control solenoid valve 2 harness connector and ECM harness con-
nector.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1801VIAS control solenoid valve 2
circuitAn excessively low or high voltage signal
is sent to ECM through the VIAS control
solenoid valve 2. Harness or connectors
(The solenoid valve 2 circuit is open or
shorted.)
VIAS control solenoid valve 2
VIAS control solenoid valve 2
Ground Voltage
Connector Terminal
F75 1 Ground Battery voltage

Page 1750 of 5121

NISSAN TEANA 2008 Service Manual P1801 VIAS CONTROL SOLENOID VALVE 2
EC-289
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
4. Also check harness for short to ground and short to power.
Is the inspection resul

Page 1751 of 5121

NISSAN TEANA 2008 Service Manual EC-290
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1801 VIAS CONTROL SOLENOID VALVE 2
NO >> Replace VIAS control solenoid valve 2

Page 1752 of 5121

NISSAN TEANA 2008 Service Manual P1805 BRAKE SWITCH
EC-291
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1805 BRAKE SWITCH
DescriptionINFOID:0000000003856776
Brake switch signal is applied to the ECM throug
