![NISSAN TEANA 2008 Service Manual BRC-36
< COMPONENT DIAGNOSIS >[ABS]
C1140 ACTUATOR RELAY SYSTEM
C1140 ACTUATOR RELAY SYSTEM
DescriptionINFOID:0000000003766753
Activates or deactivates each solenoid valve according to the signals tra NISSAN TEANA 2008 Service Manual BRC-36
< COMPONENT DIAGNOSIS >[ABS]
C1140 ACTUATOR RELAY SYSTEM
C1140 ACTUATOR RELAY SYSTEM
DescriptionINFOID:0000000003766753
Activates or deactivates each solenoid valve according to the signals tra](/manual-img/5/57391/w960_57391-976.png)
BRC-36
< COMPONENT DIAGNOSIS >[ABS]
C1140 ACTUATOR RELAY SYSTEM
C1140 ACTUATOR RELAY SYSTEM
DescriptionINFOID:0000000003766753
Activates or deactivates each solenoid valve according to the signals transmitted by the ABS actuator and
electric unit (control unit).
DTC LogicINFOID:0000000003766754
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1140” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-36, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766755
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check terminal for deformation, disconnection, looseness, etc.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK SOLENOID AND ACTUATOR RELAY POWER SUPPLY CIRCUIT
Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK SOLENOID AND ACTUATOR RELAY GROUND CIRCUIT
Check the continuity between ABS actuator and electric unit (control unit) harness connector and ground.
DTC Display item Malfunction detected condition Possible cause
C1140 ACTUATOR RLYDuring the actuator relay operating with OFF, when the
actuator relay turns ON, or when the control line for the
relay is shorted to the ground. Harness or connector
ABS actuator and electric unit
(control unit) During the actuator relay operating with ON, when the
actuator relay turns ON, or when the control line for the
relay is open.
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E34 3 Ground Battery voltage
ABS actuator and electric unit (control unit)
— Continuity
Connector Terminal
E341
Ground Existed
4
Page 978 of 5121
C1140 ACTUATOR RELAY SYSTEM
BRC-37
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace damaged parts.
Component InspectionINFOID:0000000003767291
1.CHECK ACTIVE TEST
1. On “ACTIVE TEST”, select “ABS MOTOR”.
2. Touch “On” and “Off” on screen. Make sure motor relay and actuator relay operates as shown in table
below.
NOTE:
A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is
an operation for checking.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to diagnosis procedure. Refer to BRC-36, "
Diagnosis Procedure".
Test item Display itemDisplay
On Off
ABS MOTORMOTOR RELAY On Off
ACTUATOR RLY (Note) On On
Page 979 of 5121
![NISSAN TEANA 2008 Service Manual BRC-38
< COMPONENT DIAGNOSIS >[ABS]
U1000, U1002 CAN COMM CIRCUIT
U1000, U1002 CAN COMM CIRCUIT
DescriptionINFOID:0000000003766819
CAN (Controller Area Network) is a serial communication line for real NISSAN TEANA 2008 Service Manual BRC-38
< COMPONENT DIAGNOSIS >[ABS]
U1000, U1002 CAN COMM CIRCUIT
U1000, U1002 CAN COMM CIRCUIT
DescriptionINFOID:0000000003766819
CAN (Controller Area Network) is a serial communication line for real](/manual-img/5/57391/w960_57391-978.png)
BRC-38
< COMPONENT DIAGNOSIS >[ABS]
U1000, U1002 CAN COMM CIRCUIT
U1000, U1002 CAN COMM CIRCUIT
DescriptionINFOID:0000000003766819
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
DTC LogicINFOID:0000000003766820
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“U1000” or “U1002” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-38, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766821
1.PERFORM ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“U1000” or “U1002” detected?
YES >> Proceed to diagnosis procedure. Refer to LAN-14, "Trouble Diagnosis Flow Chart".
NO >> INSPECTION END
DTC Display item Malfunction detected condition Possible cause
U1000 CAN COMM CIRCUITWhen ABS actuator and electric unit (control unit) is not
transmitting or receiving CAN communication signal for 2
seconds or more. CAN communication line
ABS actuator and electric unit
(control unit)
U1002 SYSTEM COMM (CAN)When ABS actuator and electric unit (control unit) is not
transmitting or receiving CAN communication signal for 2
seconds or less.
Page 980 of 5121
![NISSAN TEANA 2008 Service Manual POWER SUPPLY AND GROUND CIRCUIT
BRC-39
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
POWER SUPPLY AND GROUND CIRCUIT
DescriptionINFOID:0000000003766827
Supplies power to ABS actuator a NISSAN TEANA 2008 Service Manual POWER SUPPLY AND GROUND CIRCUIT
BRC-39
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
POWER SUPPLY AND GROUND CIRCUIT
DescriptionINFOID:0000000003766827
Supplies power to ABS actuator a](/manual-img/5/57391/w960_57391-979.png)
POWER SUPPLY AND GROUND CIRCUIT
BRC-39
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
POWER SUPPLY AND GROUND CIRCUIT
DescriptionINFOID:0000000003766827
Supplies power to ABS actuator and electric unit (control unit).
Diagnosis ProcedureINFOID:0000000003766828
1.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) IGNITION POWER SUPPLY
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
4. Turn the ignition switch ON.
CAUTION:
Never start the engine.
5. Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform the trouble diagnosis for power supply circuit.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY
1. Turn the ignition switch OFF.
2. Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Perform the trouble diagnosis for power supply circuit.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND
Check the continuity between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair or replace damaged parts.
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E34 18 Ground Approx. 0 V
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E34 18 Ground Battery voltage
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E34 3 Ground Battery voltage
ABS actuator and electric unit (control unit)
—Continuity
Connector Terminal
E341
Ground Existed
4
Page 981 of 5121
![NISSAN TEANA 2008 Service Manual BRC-40
< COMPONENT DIAGNOSIS >[ABS]
ABS WARNING LAMP
ABS WARNING LAMP
DescriptionINFOID:0000000003766836
×: ON –: OFF
Component Function CheckINFOID:0000000003766837
1.CHECK ABS WARNING LAMP OPERAT NISSAN TEANA 2008 Service Manual BRC-40
< COMPONENT DIAGNOSIS >[ABS]
ABS WARNING LAMP
ABS WARNING LAMP
DescriptionINFOID:0000000003766836
×: ON –: OFF
Component Function CheckINFOID:0000000003766837
1.CHECK ABS WARNING LAMP OPERAT](/manual-img/5/57391/w960_57391-980.png)
BRC-40
< COMPONENT DIAGNOSIS >[ABS]
ABS WARNING LAMP
ABS WARNING LAMP
DescriptionINFOID:0000000003766836
×: ON –: OFF
Component Function CheckINFOID:0000000003766837
1.CHECK ABS WARNING LAMP OPERATION
Check that the lamp illuminates for approximately 1 second after the ignition switch is turned ON.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to diagnosis procedure. Refer to BRC-40, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003766838
1.CHECK SELF-DIAGNOSIS
Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check items displayed by self-diagnosis.
2.CHECK COMBINATION METER
Check if the indication and operation of combination meter are normal. Refer to MWI-32, "
Diagnosis Descrip-
tion".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace combination meter.
Condition ABS warning lamp
Ignition switch OFF–
For 1 second after turning ignition switch ON×
1 second later after turning ignition switch ON –
ABS function is malfunctioning.×
EBD function is malfunctioning.×
Page 982 of 5121
![NISSAN TEANA 2008 Service Manual BRAKE WARNING LAMP
BRC-41
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
BRAKE WARNING LAMP
DescriptionINFOID:0000000003766839
×: ON –: OFF
NOTE:
1: Brake warning lamp will turn on NISSAN TEANA 2008 Service Manual BRAKE WARNING LAMP
BRC-41
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
BRAKE WARNING LAMP
DescriptionINFOID:0000000003766839
×: ON –: OFF
NOTE:
1: Brake warning lamp will turn on](/manual-img/5/57391/w960_57391-981.png)
BRAKE WARNING LAMP
BRC-41
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
BRAKE WARNING LAMP
DescriptionINFOID:0000000003766839
×: ON –: OFF
NOTE:
1: Brake warning lamp will turn on in case of parking brake operation (when switch is ON) or of brake fluid level switch operation
(when brake fluid is insufficient).
2: After starting the engine, brake warning lamp is turned off.
Component Function CheckINFOID:0000000003766840
1.BRAKE WARNING LAMP OPERATION CHECK 1
Check that the lamp illuminates for approximately 1 second after the ignition switch is turned ON.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Proceed to diagnosis procedure. Refer to BRC-41, "
Diagnosis Procedure".
2.BRAKE WARNING LAMP OPERATION CHECK 2
Check that the brake warning lamp in the combination meter turns ON/OFF correctly when operating the park-
ing brake pedal.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Check parking brake switch.
Diagnosis ProcedureINFOID:0000000003766841
1.CHECK PARKING BRAKE SWITCH
Check that the brake warning lamp in the combination meter turns ON/OFF correctly when operating the park-
ing brake pedal.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check parking brake switch.
2.CHECK SELF-DIAGNOSIS
Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check items displayed by self-diagnosis.
3.CHECK COMBINATION METER
Check if the indication and operation of combination meter are normal. Refer to MWI-32, "
Diagnosis Descrip-
tion".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace combination meter.
Condition Brake warning lamp (Note 1)
Ignition switch OFF–
For 1 second after turning ignition switch ON× (Note 2)
1 second later after turning ignition switch ON× (Note 2)
EBD function is malfunctioning.×
Page 983 of 5121
![NISSAN TEANA 2008 Service Manual BRC-42
< ECU DIAGNOSIS >[ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
ECU DIAGNOSIS
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Reference ValueINFOID:0000000003766848
VALUES ON THE DIAGNOSIS T NISSAN TEANA 2008 Service Manual BRC-42
< ECU DIAGNOSIS >[ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
ECU DIAGNOSIS
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Reference ValueINFOID:0000000003766848
VALUES ON THE DIAGNOSIS T](/manual-img/5/57391/w960_57391-982.png)
BRC-42
< ECU DIAGNOSIS >[ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
ECU DIAGNOSIS
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Reference ValueINFOID:0000000003766848
VALUES ON THE DIAGNOSIS TOOL
CAUTION:
The display shows the control unit calculation data, so a normal value might be displayed even in the
event the output circuit (harness) is open or short-circuited.
Monitor item Display contentData monitor
ConditionReference value in
normal operation
FR LH SENSORWheel sensor calculated by front LH
wheel sensor signal is displayedVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note 1)Nearly matches the
speedometer dis-
play (± 10% or less)
FR RH SENSORWheel sensor calculated by front RH
wheel sensor signal is displayedVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note 1)Nearly matches the
speedometer dis-
play (± 10% or less)
RR LH SENSORWheel sensor calculated by rear LH
wheel sensor signal is displayedVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note 1)Nearly matches the
speedometer dis-
play (± 10% or less)
RR RH SENSORWheel sensor calculated by rear RH
wheel sensor signal is displayedVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note 1)Nearly matches the
speedometer dis-
play (± 10% or less)
STOP LAMP SW Stop lamp switch signal statusWhen brake pedal is depressed On
When brake pedal is not depressed Off
BATTERY VOLTBattery voltage supplied to the ABS ac-
tuator and electric unit (control unit)Ignition switch ON 10 – 16 V
FR RH IN SOLOperation status of each solenoid
valve Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT-III)On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON)Off
FR RH OUT SOLOperation status of each solenoid
valve Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT-III)On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON)Off
FR LH IN SOLOperation status of each solenoid
valve Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT-III)On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON)Off
FR LH OUT SOLOperation status of each solenoid
valve Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT-III)On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON)Off
Page 984 of 5121
![NISSAN TEANA 2008 Service Manual ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-43
< ECU DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
NOTE:
1: Confirm tire pressure is normal.
2: A brief moment of On/Off condition occurs NISSAN TEANA 2008 Service Manual ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-43
< ECU DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
NOTE:
1: Confirm tire pressure is normal.
2: A brief moment of On/Off condition occurs](/manual-img/5/57391/w960_57391-983.png)
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-43
< ECU DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
NOTE:
1: Confirm tire pressure is normal.
2: A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an
operation for checking.
3: On and off timing for warning lamp and indicator lamp.
- ABS warning lamp: Refer to BRC-40, "
Description".
- Brake warning lamp: Refer to BRC-41, "
Description". RR RH IN SOLOperation status of each solenoid
valve Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT-III)On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON)Off
RR RH OUT SOLOperation status of each solenoid
valve Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT-III)On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON)Off
RR LH IN SOLOperation status of each solenoid
valve Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT-III)On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON)Off
RR LH OUT SOLOperation status of each solenoid
valve Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT-III)On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON)Off
MOTOR RELAY Motor and motor relay operationWhen the motor relay and motor are op-
eratingOn
When the motor relay and motor are not
operatingOff
ACTUATOR RLY
(Note 2)Actuator relay operationWhen the actuator relay is operating On
When the actuator relay is not operating Off
ABS WARN LAMPABS warning lamp
(Note 3)When ABS warning lamp is ON On
When ABS warning lamp is OFF Off
EBD WARN LAMPBrake warning lamp
(Note 3)When brake warning lamp is ON On
When brake warning lamp is OFF Off
EBD SIGNAL EBD operationEBD is active On
EBD is inactive Off
ABS SIGNAL ABS operationABS is active On
ABS is inactive Off
EBD FAIL SIG EBD fail-safe signalIn EBD fail-safe On
EBD is normal Off
ABS FAIL SIG ABS fail-safe signalIn ABS fail-safe On
ABS is normal Off Monitor item Display contentData monitor
ConditionReference value in
normal operation
