2008 NISSAN TEANA Service Manual

oil dipstick height adjustment tire size fuel filter location check engine brakes

Page 4769 of 5121

NISSAN TEANA 2008 Service Manual TM-296
< SYMPTOM DIAGNOSIS >[CVT: RE0F10A]
SYSTEM SYMPTOM
30
OthersEngine starts in posi-
tions other than “N” or
“P”.ON vehicle1. Ignition switch and starterPG-55
,
STR-10
2. CVT positionTM

Page 4770 of 5121

NISSAN TEANA 2008 Service Manual PRECAUTIONS
TM-297
< PRECAUTION >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOI

PRECAUTIONS
TM-297
< PRECAUTION >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003901473
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the “SRS AIRBAG” and
“SEAT BELT” of this Service Manual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIRBAG”.
Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.
Precaution Necessary for Steering Wheel Rotation after Battery Disconnect
INFOID:0000000003901477
NOTE:
Before removing and installing any control units, first turn the push-button ignition switch to the LOCK posi-
tion, then disconnect both battery cables.
After finishing work, confirm that all control unit connectors are connected properly, then re-connect both
battery cables.
Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If a DTC is detected, perform trouble diagnosis according to self-diagnosis results.
This vehicle is equipped with a push-button ignition switch and a steering lock unit.
If the battery is disconnected or discharged, the steering wheel will lock and cannot be turned.
If turning the steering wheel is required with the battery disconnected or discharged, follow the procedure
below before starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Turn the push-button ignition switch to ACC position.
(At this time, the steering lock will be released.)
3. Disconnect both battery cables. The steering lock will remain released with both battery cables discon-
nected and the steering wheel can be turned.
4. Perform the necessary repair operation.
5. When the repair work is completed, re-connect both battery cables. With the brake pedal released, turn
the push-button ignition switch from ACC position to ON position, then to LOCK position. (The steering
wheel will lock when the push-button ignition switch is turned to LOCK position.)
6. Perform self-diagnosis check of all control units using CONSULT-III.

Page 4771 of 5121

NISSAN TEANA 2008 Service Manual TM-298
< PRECAUTION >[CVT: RE0F10A]
PRECAUTIONS
Precaution for Procedure without Cowl Top Cover
INFOID:0000000003901480
When performing the procedure after removing cowl top cover, cover
the lower end

TM-298
< PRECAUTION >[CVT: RE0F10A]
PRECAUTIONS
Precaution for Procedure without Cowl Top Cover
INFOID:0000000003901480
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
Precaution for On Board Diagnosis (OBD) System of CVT and EngineINFOID:0000000003806496
The ECM has an on board diagnostic system. It will light up the Malfunction Indicator Lamp (MIL) to warn the
driver of a malfunction causing emission deterioration.
CAUTION:
Be sure to turn the ignition switch OFF and disconnect the battery cable from the negative terminal
before any repair or inspection work. The open/short circuit of related switches, sensors, solenoid
valves, etc. will cause the MIL to light up.
Be sure to connect and lock the connectors securely after work. A loose (unlocked) connector will
cause the MIL to light up due to an open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)
Be sure to route and secure the harnesses properly after work. Interference of the harness with a
bracket, etc. may cause the MIL to light up due to a short circuit.
Be sure to connect rubber tubes properly after work. A misconnected or disconnected rubber tube
may cause the MIL to light up due to a malfunction of the EVAP system or fuel injection system, etc.
Be sure to erase the unnecessary malfunction information (repairs completed) from the TCM and
ECM before returning the vehicle to the customer.
Precaution for TCM and CVT Assembly ReplacementINFOID:0000000003806497
CAUTION:
Check if new data (Unit ID) are entered correctly after replacing CVT assembly and erasing data in
TCM. (Connect CONSULT-III, and then turn ignition switch OFF.)
When replacing CVT assembly or TCM, refer to the pattern table below and erase the EEPROM in the
TCM if necessary.
EEPROM ERASING PATTERNS
Removal and Installation Procedure for CVT Unit ConnectorINFOID:0000000003806498
REMOVAL
PIIB3706J
CVT assembly TCM Erasing EEPROM in TCM Remarks
Replaced Replaced Not requiredNot required because the EEPROM in the TCM is in
the default state. (CVT assembly must be replaced
first.)
Not replaced Replaced Not requiredNot required because the EEPROM in the TCM is in
the default state.
Replaced Not replaced RequiredRequired because data has been written in the EE-
PROM in the TCM and because the TCM cannot write
data from the ROM assembly in the transmission.

Page 4772 of 5121

NISSAN TEANA 2008 Service Manual PRECAUTIONS
TM-299
< PRECAUTION >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Rotate bayonet ring (1) counterclockwise. Pull out CVT unit harness
connector (2) upward and remove it.
INSTALLATION
1.

Page 4773 of 5121

NISSAN TEANA 2008 Service Manual TM-300
< PRECAUTION >[CVT: RE0F10A]
PRECAUTIONS
Turn ignition switch OFF and disconnect negative battery
cable before connecting or disconnecting the TCM harness
connector. Because battery voltage is

Page 4774 of 5121

NISSAN TEANA 2008 Service Manual PRECAUTIONS
TM-301
< PRECAUTION >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Certain systems and components, especially those related to OBD, may use the new style slide-lock-
ing type harness con

Page 4775 of 5121

NISSAN TEANA 2008 Service Manual TM-302
< PREPARATION >[CVT: RE0F10A]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000003806502
Commercial Service ToolsINFOID:0000000003806503
Tool number
Tool nameDescription
1

Page 4776 of 5121

NISSAN TEANA 2008 Service Manual PREPARATION
TM-303
< PREPARATION >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Drift
a: 54 mm (2.13 in) dia.
b: 47 mm (1.85 in) dia.Installing differential side oil seal
Drift
a: 65 mm (2.56 in) d
