NISSAN TEANA 2008 Service Manual EC-324
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
COOLING FAN
COOLING FAN
DescriptionINFOID:0000000003856827
The ECM controls the cooling fan corresponding to the vehicle speed, engine coolant temperatur

Page 1786 of 5121

NISSAN TEANA 2008 Service Manual COOLING FAN
EC-325
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
2.DETECT MALFUNCTIONING PART
Check the following.
40A fusible link (letter K)
10A fuse (No.42)
IPDM E/R

Page 1787 of 5121

NISSAN TEANA 2008 Service Manual EC-326
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
COOLING FAN
3. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 7.
7.DETECT MALFUN

Page 1788 of 5121

NISSAN TEANA 2008 Service Manual COOLING FAN
EC-327
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 1

Page 1789 of 5121

NISSAN TEANA 2008 Service Manual EC-328
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
COOLING FAN
Check that cooling fan speed of condition B is higher than that of A.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace co

Page 1790 of 5121

NISSAN TEANA 2008 Service Manual ELECTRICAL LOAD SIGNAL
EC-329
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000003856832
The electrical load signal (Headlamp swi

Page 1791 of 5121

NISSAN TEANA 2008 Service Manual EC-330
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
ELECTRICAL LOAD SIGNAL
>> INSPECTION END
3.CHECK HEADLAMP SYSTEM
Refer to EXL-7, "
Work Flow" (XENON TYPE) or EXL-198, "Work Flow" (HALOGEN TYPE).
>> INS

Page 1792 of 5121

NISSAN TEANA 2008 Service Manual ELECTRONIC CONTROLLED ENGINE MOUNT
EC-331
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ELECTRONIC CONTROLLED ENGINE MOUNT
DescriptionINFOID:0000000003856835
The electronic c

ELECTRONIC CONTROLLED ENGINE MOUNT
EC-331
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ELECTRONIC CONTROLLED ENGINE MOUNT
DescriptionINFOID:0000000003856835
The electronic controlled engine mount control solenoid valve controls the intake manifold vacuum signal for
electronic controlled engine mount. The electronic controlled engine mount control solenoid valve is moved by
ON/OFF signal from the ECM. When the solenoid is OFF, the vacuum signal from the intake manifold is cut.
When the solenoid is ON, the intake manifold vacuum signal is sent to the electronic controlled engine mount.
Component Function CheckINFOID:0000000003856836
1.CHECK OVERALL FUNCTION
1. Start engine and warm it up to normal operating temperature.
2. Selector level position is D while depressing the brake pedal and parking brake pedal.
3. Disconnect electronic controlled engine mount control solenoid valve harness connector.
4. Check that body vibration increases compared to the condition of step 2 above (with vehicle stopped).
Is the inspection result normal?
YES >> INSPECTION END
NO >>EC-331, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003856837
1.CHECK VACUUM SOURCE
1. Turn ignition switch OFF.
2. Reconnect electronic controlled engine mount control solenoid valve harness connector.
3. Disconnect vacuum hose connected to electronic controlled engine mount.
4. Start engine and let it idle.
5. Check vacuum hose for vacuum existence.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 2.
2.CHECK VACUUM HOSES AND VACUUM GALLERY
1. Turn ignition switch OFF.
2. Check vacuum hoses and vacuum gallery for clogging, cracks or improper connection. Refer to EC-68,
"System Diagram".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace vacuum hoses and vacuum gallery.
3.CHECK ELECTRONIC CONTROLLED ENGINE MOUNT CONTROL SOLENOID VALVE POWER SUPPLY
CIRCUIT
1. Disconnect electronic controlled engine mount control solenoid valve harness connector.
2. Turn ignition switch ON.
3. Check the voltage between front electronic controlled engine mount harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PARTVacuum should exist.
Electronic controlled engine mount
control solenoid valve
Ground Voltage
Connector Terminal
F11 1 Ground Battery voltage
