INL-98
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Bulb SpecificationsINFOID:0000000003774604
Item Type Wattage (W)
Push-button ignition switch illumination LED —
Map lamp Wedge 8
Mood lampMap lamp
LED — Front door grip
Rear door grip
Vanity mirror lamp — 2
Ashtray illumination Wedge 1.4
Glove box lamp Wedge 1.4
Ste p l am p We dg e 2. 7
Personal lamp Wedge 8
Trunk room lamp Wedge 3.4
Page 2978 of 5121

INT-1
BODY INTERIOR
C
D
E
F
G
H
I
K
L
M
SECTION INT
A
B
INT
N
O
P
CONTENTS
INTERIOR
BASIC INSPECTION ....................................3
DIAGNOSIS AND REPAIR WORKFLOW ..........3
WorkFlow ..................................................................3
FUNCTION DIAGNOSIS ...............................4
REAR SUNSHADE SYSTEM ..............................4
System Diagram ........................................................4
System Description ...................................................4
Component Parts Location ........................................4
Component Description .............................................5
COMPONENT DIAGNOSIS ..........................6
POWER SUPPLY AND GROUND CIRCUIT .......6
REAR SUNSHADE CONTROL UNIT ..........................6
REAR SUNSHADE CONTROL UNIT : Diagnosis
Procedure ..................................................................
6
REAR SUNSHADE SWITCH ..............................7
FRONT .........................................................................7
FRONT : Description .................................................7
FRONT : Component Function Check ......................7
FRONT : Diagnosis Procedure .................................7
FRONT : Component Inspection ...............................8
REAR ...........................................................................8
REAR : Description ...................................................8
REAR : Component Function Check .........................8
REAR : Diagnosis Procedure ....................................8
REAR : Component Inspection ...............................10
REAR SUNSHADE MOTOR ..............................11
Description ..............................................................11
Component Function Check ....................................11
Diagnosis Procedure ...............................................11
REVERSE SIGNAL CIRCUIT .............................12
Description ..............................................................12
Component Function Check ....................................12
Diagnosis Procedure ...............................................12
ECU DIAGNOSIS .........................................13
REAR SUNSHADE CONTROL UNIT ...............13
Reference Value ......................................................13
Wiring Diagram - REAR SUNSHADE CONTROL
SYSTEM - ................................................................
14
SYMPTOM DIAGNOSIS ..............................18
REAR SUNSHADE DOES NOT OPERATE .....18
WHEN TURNING ON REAR SUNSHADE SWITCH
(FRONT AND REAR) .................................................
18
WHEN TURNING ON REAR SUNSHADE
SWITCH (FRONT AND REAR) : Diagnosis Proce-
dure .........................................................................
18
WHEN TURNING ON REAR SUNSHADE SWITCH
(FRONT) .....................................................................
18
WHEN TURNING ON REAR SUNSHADE
SWITCH (FRONT) : Diagnosis Procedure ..............
18
WHEN TURNING ON REAR SUNSHADE SWITCH
(REAR) .......................................................................
18
WHEN TURNING ON REAR SUNSHADE
SWITCH (REAR) : Diagnosis Procedure .................
18
REAR SUNSHADE DOES NOT LOWER
WHEN SHIFT LEVER IS IN THE "R" POSI-
TION ..................................................................
20
Diagnosis Procedure ...............................................20
SQUEAK AND RATTLE TROUBLE DIAG-
NOSES ..............................................................
21
Work Flow ................................................................21
Inspection Procedure ...............................................23
Diagnostic Worksheet ..............................................25
PRECAUTION ..............................................27
PRECAUTIONS .................................................27
Page 2979 of 5121

INT-2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .................................................................
27
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect ..................................
27
Precaution for Procedure without Cowl Top Cover ...28
Precaution for Work ................................................28
PREPARATION ...........................................29
PREPARATION .................................................29
Commercial Service Tools ......................................29
ON-VEHICLE REPAIR ................................30
FRONT DOOR FINISHER .................................30
DRIVER SIDE ............................................................30
DRIVER SIDE : Exploded View ..............................30
DRIVER SIDE : Removal and Installation ..............30
PASSENGER SIDE ...................................................32
PASSENGER SIDE : Exploded View .....................33
PASSENGER SIDE : Removal and Installation .....33
REAR DOOR FINISHER ....................................36
Exploded View ........................................................36
Removal and Installation ........................................36
BODY SIDE TRIM ..............................................39
Exploded View ........................................................39
Removal and Installation ........................................39
REAR PARCEL SHELF FINISHER ...................43
Exploded View ........................................................43
Removal and Installation ........................................43
REAR SUNSHADE ............................................45
Exploded View ........................................................45
Removal and Installation .........................................45
FLOOR TRIM .....................................................47
Exploded View ........................................................47
Removal and Installation .........................................47
HEADLINING .....................................................49
NORMAL ROOF ........................................................49
NORMAL ROOF : Exploded View ..........................49
NORMAL ROOF : Removal and Installation ...........50
SUNROOF .................................................................52
SUNROOF : Exploded View ...................................53
SUNROOF : Removal and Installation ....................54
TRUNK ROOM TRIM .........................................57
Exploded View ........................................................57
Removal and Installation .........................................57
TRUNK LID TRIM ..............................................59
Exploded View ........................................................59
Removal and Installation .........................................59
REAR SUNSHADE CONTROL UNIT ................61
Exploded View ........................................................61
Removal and Installation .........................................61
REAR SUNSHADE SWITCH .............................62
FRONT .......................................................................62
FRONT : Exploded View .........................................62
FRONT : Removal and Installation .........................62
REAR .........................................................................62
REAR : Exploded View ...........................................63
REAR : Removal and Installation ............................63
Page 2980 of 5121

DIAGNOSIS AND REPAIR WORKFLOW
INT-3
< BASIC INSPECTION >
C
D
E
F
G
H
I
K
L
MA
B
INT
N
O
P
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORKFLOW
WorkFlowINFOID:0000000003824895
DETAILED FLOW
1.OBTAIN INFORMATION ABOUT SYMPTOM
Interview the customer to obtain as much malfunction information (conditions and environment when the mal-
function occurred) as possible when the customer brings the vehicle in.
>> GO TO 2.
2.REPRODUCE THE MALFUNCTION INFORMATION
Check the malfunction on the vehicle that the customer describes.
Inspect the relation of the symptoms and the condition when the symptoms occur.
>> GO TO 3.
3.IDENTIFY THE MALFUNCTIONING SYSTEM WITH “SYMPTOM DIAGNOSIS”
Use “Symptom Diagnosis” from the symptom inspection result in step 2 and then identify where to start per-
forming the diagnosis based on possible causes and symptoms.
>> GO TO 4.
4.IDENTIFY THE MALFUNCTIONING PARTS WITH “COMPONENT DIAGNOSIS”
Perform the diagnosis with “Component Diagnosis” of the applicable system.
>> GO TO 5.
5.REPAIR OR REPLACE THE MALFUNCTIONING PARTS
Repair or replace the specified malfunctioning parts.
>> GO TO 6.
6.FINAL CHECK
Check that malfunctions are not reproduced when obtaining the malfunction information from the customer,
referring to the symptom inspection result in step 2.
Are the malfunctions corrected?
YES >> INSPECTION END
NO >> GO TO 3.
Page 2981 of 5121
INT-4
< FUNCTION DIAGNOSIS >
REAR SUNSHADE SYSTEM
FUNCTION DIAGNOSIS
REAR SUNSHADE SYSTEM
System DiagramINFOID:0000000003819258
