Page 1233 of 5121

NISSAN TEANA 2008 Service Manual INTELLIGENT KEY SYSTEM
DLK-17
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR LOCK FUNCTION : System DiagramINFOID:0000000003794742
DOOR LOCK FUNCTION : Syste

Page 1234 of 5121

NISSAN TEANA 2008 Service Manual DLK-18
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
The outside key antenna detection area of door lock/unlock function
is in the range of approximately 80 cm (31.50 in)

DLK-18
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
The outside key antenna detection area of door lock/unlock function
is in the range of approximately 80 cm (31.50 in) surrounding the
driver and passenger door handles and (1) and trunk lid opener
request switch (2). However, this operating range depends on the
ambient conditions.
HAZARD AND BUZZER REMINDER FUNCTION
During lock, unlock, operation by each request switch, the hazard warning lamps and Intelligent Key warning
buzzer will blink or honk as a reminder.
When doors are locked, unlocked by each request switch, BCM honks Intelligent Key warning buzzer as a
reminder and blinks.
Operating Function of Hazard and Buzzer Reminder
How to Change Hazard and Buzzer Reminder Mode
Refer to SEC-22, "INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
AUTO DOOR LOCK FUNCTION
When all doors are locked, ignition switch is in OFF position and key switch is OFF (Intelligent Key is not
inserted in key slot). Doors are unlocked with door request switch.
When BCM does not receive the following signals within 60 seconds, all doors are locked.
Door switch is ON (door is opened)
Door is locked
Ignition switch is ON (ignition switch is pressed)
Key switch is ON (Intelligent Key is inserted in key slot)
Auto door lock mode can be changed by “AUTO LOCK SET” mode in “WORK SUPPORT”. Refer to SEC-22,
"INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
LIST OF OPERATION RELATED PARTS
The operation related parts are marked with ×.
JMKIA2511ZZ
Operation Hazard warning lamp flash Intelligent Key warning buzzer honk
Unlock Once Once
Lock Twice Twice
Door lock function
Intelligent Key
Key slot
Remote keyless entry receiver
Door switch
Door request switch
Door lock actuator
Inside key antenna
Outside key antenna
Intelligent Key warning buzzer
CAN communication system
BCM
Hazard warning lamp
Push-button ignition switch
Combination meter
Door lock/unlock function by request switch×××××××× ×
Hazard and buzzer reminder function for door lock/un-
lock operation×××× ×
Key reminder function××××××××× ××
Auto door lock function×× ××× × ×

Page 1235 of 5121

NISSAN TEANA 2008 Service Manual INTELLIGENT KEY SYSTEM
DLK-19
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR LOCK FUNCTION : Component Parts LocationINFOID:0000000003841720
1. BCM M118, M11

Page 1236 of 5121

NISSAN TEANA 2008 Service Manual DLK-20
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
DOOR LOCK FUNCTION : Component Description
INFOID:0000000003794745
TRUNK OPEN FUNCTION
10. Inside key antenna (instrum

Page 1237 of 5121

NISSAN TEANA 2008 Service Manual INTELLIGENT KEY SYSTEM
DLK-21
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK OPEN FUNCTION : System DiagramINFOID:0000000003794746
TRUNK OPEN FUNCTION : Sys

Page 1238 of 5121

NISSAN TEANA 2008 Service Manual DLK-22
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
Door lock function
Intelligent Key
Key slot
Remote keyless entry receiver
Door switch
Door request switch
Door lock ac

Page 1239 of 5121

NISSAN TEANA 2008 Service Manual INTELLIGENT KEY SYSTEM
DLK-23
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK OPEN FUNCTION : Component Parts LocationINFOID:0000000003841721
1. BCM M118, M1

Page 1240 of 5121

NISSAN TEANA 2008 Service Manual DLK-24
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
TRUNK OPEN FUNCTION : Component Description
INFOID:0000000003794749
REMOTE KEYLESS ENTRY FUNCTION
10. Inside key anten
