VTL-86
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
INTAKE SENSOR
Removal and Installation
INFOID:0000000003894498
REMOVAL
1. Remove evaporator pipe assembly. Refer to HA-54, "Exploded View".
2. Disconnect intake sensor connector.
3. Slide evaporator (1) toward the right side of the vehicle (as
shown in the figure), and then remove intake sensor (2).
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Replace O-rings with new ones. Then apply compressor oil to them when installing.
Mark the mounting position of intake sensor bracket prior to removal so that the reinstalled sensor
can be located in the same position.
Do not rotate the bracket insertion part when removing and installing the intake sensor.
Check for refrigerant leakage when charging refrigerant.
37. Defroster door link 38. Foot door link 39. Max. cool door lever
40. Foot door lever 41. Defroster door lever 42. Adapter case
43. Distributor lower case 44. Ventilator door 45. Intake sensor
46. Intake sensor bracket 47. Foot door 48. Max. cool door
49. Defroster door 50. Air mix door (Slide door)
Refer to GI-4, "
Components" for symbols in the figure.
JPIIA0907ZZ
Page 4898 of 5121
BLOWER UNIT
VTL-87
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
BLOWER UNIT
Exploded ViewINFOID:0000000003894499
DISASSEMBLY
1. Blower unit 2. Heater & cooling unit assembly 3. Steering member
4. Instrument stay 5. Instrument panel assembly
Refer to GI-4, "
Components" for symbols in the figure.
JPIIA0914GB
Page 4899 of 5121
VTL-88
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
BLOWER UNIT
Removal and Installation
INFOID:0000000003940511
REMOVAL
1. Remove instrument panel assembly. Refer to IP-11, "Exploded View".
2. Remove mounting nuts (A), and then remove instrument stay
(1).
3. Disconnect intake door motor and blower motor connectors.
1. Shutter box case 2. Intake door 3. Intake door motor
4. Blower motor 5. Intake lower case 6. Outlet seal
7. Intake upper case 8. Intake seal
JPIIA0908ZZ
JPIIA0909ZZ
Page 4900 of 5121
BLOWER UNIT
VTL-89
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
4. Remove heater & cooling unit assembly mounting bolts (A) and blower unit mounting bolts (B).
5. Remove steering member mounting bolts (C) (right).
6. Remove blower unit (2) while pulling steering member (1).
INSTALLATION
Installation is basically the reverse order of removal.
JPIIA0910ZZ
Page 4901 of 5121
VTL-90
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
BLOWER MOTOR
BLOWER MOTOR
Exploded ViewINFOID:0000000003894501
Removal and InstallationINFOID:0000000003894502
REMOVAL
1. Remove globe box assembly. Refer to IP-11, "Exploded View".
2. Disconnect blower motor connector.
3. Remove mounting screws (A), and then remove blower motor
(1).
INSTALLATION
Installation is basically the reverse order of removal.
1. Shutter box case 2. Intake door 3. Intake door motor
4. Blower motor 5. Intake lower case 6. Outlet seal
7. Intake upper case 8. Intake seal
JPIIA0908ZZ
JPIIA0911ZZ
Page 4902 of 5121
INTAKE DOOR MOTOR
VTL-91
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
INTAKE DOOR MOTOR
Exploded ViewINFOID:0000000003894503
Removal and InstallationINFOID:0000000003894504
REMOVAL
1. Remove globe box assembly. Refer to IP-11, "Exploded View".
2. Remove mounting screw (A), and then move remote keyless
entry receiver (1) to a position where it does not inhibit work.
1. Shutter box case 2. Intake door 3. Intake door motor
4. Blower motor 5. Intake lower case 6. Outlet seal
7. Intake upper case 8. Intake seal
JPIIA0908ZZ
JPIIA0912ZZ
Page 4903 of 5121
VTL-92
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
INTAKE DOOR MOTOR
3. Remove mounting screw (A), and then remove intake door
motor (1).
4. Disconnect intake door motor connector.
INSTALLATION
Installation is basically the reverse order of removal.
JPIIA0913ZZ
Page 4904 of 5121
HEATER & COOLING UNIT ASSEMBLY
VTL-93
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
HEATER & COOLING UNIT ASSEMBLY
Exploded ViewINFOID:0000000003894505
DISASSEMBLY
1. Blower unit 2. Heater & cooling unit assembly 3. Steering member
4. Instrument stay 5. Instrument panel assembly
Refer to GI-4, "
Components" for symbols in the figure.
JPIIA0914GB
