2008 NISSAN TEANA Service Manual

spare wheel 4WD maintenance reset wheel tire pressure reset check engine light

Load previous 8 pages

Page 3937 of 5121

NISSAN TEANA 2008 Service Manual HI MODE OF HEATED SEAT DOES NOT OPERATE
SE-73
< SYMPTOM DIAGNOSIS >[WITH VENTILATION SEAT]
C
D
E
F
G
H
I
K
L
MA
B
SE
N
O
P
HI MODE OF HEATED SEAT DOES NOT OPERATE
FRONT SEAT
FRONT SEAT : Diagnosis Pro

Page 3938 of 5121

NISSAN TEANA 2008 Service Manual SE-74
< SYMPTOM DIAGNOSIS >[WITH VENTILATION SEAT]
LO MODE OF HEATED SEAT DOES NOT OPERATE
LO MODE OF HEATED SEAT DOES NOT OPERATE
FRONT SEAT
FRONT SEAT : DescriptionINFOID:0000000003901738
NOTE:
Wh

Page 3939 of 5121

NISSAN TEANA 2008 Service Manual LO MODE OF HEATED SEAT DOES NOT OPERATE
SE-75
< SYMPTOM DIAGNOSIS >[WITH VENTILATION SEAT]
C
D
E
F
G
H
I
K
L
MA
B
SE
N
O
P
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the

Page 3940 of 5121

NISSAN TEANA 2008 Service Manual SE-76
< SYMPTOM DIAGNOSIS >[WITH VENTILATION SEAT]
ONLY SEATBACK HEATER IS OPERATED IN HI MODE OF HEATED SEAT
ONLY SEATBACK HEATER IS OPERATED IN HI MODE OF HEATED SEAT
FRONT SEAT
FRONT SEAT : Descrip

Page 3941 of 5121

NISSAN TEANA 2008 Service Manual ONLY SEAT CUSHION HEATER IS OPERATED IN HI MODE OF HEATED SEAT
SE-77
< SYMPTOM DIAGNOSIS >[WITH VENTILATION SEAT]
C
D
E
F
G
H
I
K
L
MA
B
SE
N
O
P
ONLY SEAT CUSHION HEATER IS OPERATED IN HI MODE OF HEA

Page 3942 of 5121

NISSAN TEANA 2008 Service Manual SE-78
< SYMPTOM DIAGNOSIS >[WITH VENTILATION SEAT]
HEATED SEAT SWITCH INDICATOR DOES NOT TURN ON
HEATED SEAT SWITCH INDICATOR DOES NOT TURN ON
FRONT SEAT
FRONT SEAT : Diagnosis ProcedureINFOID:0000000

Page 3943 of 5121

NISSAN TEANA 2008 Service Manual VENTILATION SEAT SWITCH INDICATOR DOES NOT TURN ON
SE-79
< SYMPTOM DIAGNOSIS >[WITH VENTILATION SEAT]
C
D
E
F
G
H
I
K
L
MA
B
SE
N
O
P
VENTILATION SEAT SWITCH INDICATOR DOES NOT TURN ON
FRONT SEAT
FRON

Page 3944 of 5121

NISSAN TEANA 2008 Service Manual SE-80
< SYMPTOM DIAGNOSIS >[WITH VENTILATION SEAT]
SQUEAK AND RATTLE TROUBLE DIAGNOSES
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Work FlowINFOID:0000000003940143
CUSTOMER INTERVIEW
Interview the customer if

SE-80
< SYMPTOM DIAGNOSIS >[WITH VENTILATION SEAT]
SQUEAK AND RATTLE TROUBLE DIAGNOSES
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Work FlowINFOID:0000000003940143
CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag-
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any of
the customer's comments; refer to SE-84, "
Diagnostic Worksheet". This information is necessary to duplicate
the conditions that exist when the noise occurs.
The customer may not be able to provide a detailed description or the location of the noise. Attempt to obtain
all the facts and conditions that exist when the noise occurs (or does not occur).
If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer is
concerned about. This can be accomplished by a test drive with the customer.
After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
are provided so the customer, service adviser and technician are all speaking the same language when
defining the noise.
Squeak – (Like tennis shoes on a clean floor)
Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard surfaces
= higher pitch noise/softer surfaces = lower pitch noises/edge to surface = chirping
Creak – (Like walking on an old wooden floor)
Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch depen-
dent on materials/often brought on by activity.
Rattle – (Like shaking a baby rattle)
Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
clip or fastener/incorrect clearance.
Knock – (Like a knock on a door)
Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.
Tick – (Like a clock second hand)
Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
action or road conditions.
Thump – (Heavy, muffled knock noise)
Thump characteristics include softer knock/dead sound often brought on by activity.
Buzz – (Like a bumble bee)
Buzz characteristics include high frequency rattle/firm contact.
Often the degree of acceptable noise level will vary depending upon the person. A noise that a technician
may judge as acceptable may be very irritating to the customer.
Weather conditions, especially humidity and temperature, may have a great effect on noise level.
DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on
the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to
duplicate the same conditions when the repair is reconfirmed.
SBT842
