NISSAN TEANA 2008 Service Manual EXL-116 < ECU DIAGNOSIS >[XENON TYPE] BCM (BODY CONTROL MODULE) 39 (BR/W)GroundRear bumper anten- na (+)OutputWhen the trunk lid opener request switch is operat- ed with ignition switch OFFWhen Int

Page 2146 of 5121

NISSAN TEANA 2008 Service Manual BCM (BODY CONTROL MODULE) EXL-117 < ECU DIAGNOSIS >[XENON TYPE] C D E F G H I J K MA B EXL N O P 67 (L/R)GroundTrunk lid opener switchInputTrunk lid opener switchPressed 0 V Not pressed 11.8 V 68 (R

Page 2147 of 5121

NISSAN TEANA 2008 Service Manual EXL-118 < ECU DIAGNOSIS >[XENON TYPE] BCM (BODY CONTROL MODULE) 73 (W/R)GroundRoom antenna 2 (+) (center console)OutputIgnition switch OFFWhen Intelligent Key is in the passenger compart- ment When

Page 2148 of 5121

NISSAN TEANA 2008 Service Manual BCM (BODY CONTROL MODULE) EXL-119 < ECU DIAGNOSIS >[XENON TYPE] C D E F G H I J K MA B EXL N O P 76 (V)GroundDriver door antenna (-)OutputWhen the driver door request switch is operat- ed with igni

Page 2149 of 5121

NISSAN TEANA 2008 Service Manual EXL-120 < ECU DIAGNOSIS >[XENON TYPE] BCM (BODY CONTROL MODULE) 79 (G)GroundRoom antenna 1 (+) (instrument panel)OutputIgnition switch OFFWhen Intelligent Key is in the passenger compart- ment When

Page 2150 of 5121

NISSAN TEANA 2008 Service Manual BCM (BODY CONTROL MODULE) EXL-121 < ECU DIAGNOSIS >[XENON TYPE] C D E F G H I J K MA B EXL N O P 87 (R/Y)GroundCombination switch INPUT 5InputCombination switchAll switch OFF (Wiper intermittent dia

Page 2151 of 5121

NISSAN TEANA 2008 Service Manual EXL-122 < ECU DIAGNOSIS >[XENON TYPE] BCM (BODY CONTROL MODULE) 88 (R/G)GroundCombination switch INPUT 3InputCombination switchAll switch OFF (Wiper intermittent dial 4) 1.4 V Lighting switch HI (Wi

Page 2152 of 5121

NISSAN TEANA 2008 Service Manual BCM (BODY CONTROL MODULE) EXL-123 < ECU DIAGNOSIS >[XENON TYPE] C D E F G H I J K MA B EXL N O P 93 (Y)Ground ON indicator lamp Output Ignition switchOFF (LOCK indicator is not illuminated)Battery vo
