NISSAN TEANA 2008 Service Manual SEC-32
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
P1611 ID DISCORD, IMMU-ECM
P1611 ID DISCORD, IMMU-ECM
DescriptionINFOID:0000000003814930
BCM performs the ID verification with ECM that allows th

SEC-32
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
P1611 ID DISCORD, IMMU-ECM
P1611 ID DISCORD, IMMU-ECM
DescriptionINFOID:0000000003814930
BCM performs the ID verification with ECM that allows the engine to start. Start the engine if the ID is OK.
ECM prevents the engine from starting if the ID is not registered. BCM starts the communication with ECM if
ignition switch is turned ON.
DTC LogicINFOID:0000000003814931
DTC DETECTION LOGIC
NOTE:
If DTC B1611 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
If DTC B1611 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-32, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814932
1.PERFORM INITIALIZATION
Perform initialization with CONSULT-III. Re-register all Intelligent Keys.
For initialization and registration of Intelligent Key. Refer to “CONSULT-III Operation Manual NATS-IVIS/
NVIS”.
Can the system be initialized and can the engine be started with reregistered Intelligent Key?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE BCM
1. Replace BCM. Refer to BCS-78, "
Removal and Installation".
2. Perform initialization with CONSULT-III.
For initialization, refer to “CONSULT-III Operation Manual NATS-IVIS/NVIS”.
Can the system be initialized and can the engine be started with reregistered Intelligent Key?
YES >> INSPECTION END
NO >> GO TO 3.
3.REPLACE ECM
1. Replace ECM. Refer to EC-14, "
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Descrip-
tion".
2. Perform initialization with CONSULT-III.
For initialization, refer to “CONSULT-III Operation Manual NATS-IVIS/NVIS”.
Can the system be initialized and can the engine be started with reregistered Intelligent Key?
YES >> INSPECTION END
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
P1611ID DISCORD, IMMU-
ECMThe ID verification result between BCM and ECM is
NG. The registration is necessary.BCM
ECM

Page 4042 of 5121

NISSAN TEANA 2008 Service Manual P1611 ID DISCORD, IMMU-ECM
SEC-33
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
NO >> GO TO 4.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident"

Page 4043 of 5121

NISSAN TEANA 2008 Service Manual SEC-34
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
P1612 CHAIN OF ECM-IMMU
P1612 CHAIN OF ECM-IMMU
DescriptionINFOID:0000000003814933
BCM performs the ID verification with ECM that allows the engi

Page 4044 of 5121

NISSAN TEANA 2008 Service Manual P1614 CHAIN OF IMMU-KEY
SEC-35
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
P1614 CHAIN OF IMMU-KEY
DescriptionINFOID:0000000003814936
Performs ID verification thro

Page 4045 of 5121

NISSAN TEANA 2008 Service Manual SEC-36
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
P1614 CHAIN OF IMMU-KEY
3.CHECK KEY SLOT CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between key slot harness connector and BCM harn

Page 4046 of 5121

NISSAN TEANA 2008 Service Manual P1614 CHAIN OF IMMU-KEY
SEC-37
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
1. Turn ignition switch OFF.
2. Disconnect key slot connector.
3. Check continuity betwe

Page 4047 of 5121

NISSAN TEANA 2008 Service Manual SEC-38
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
P1615 DIFFRENCE OF KEY
P1615 DIFFRENCE OF KEY
DescriptionINFOID:0000000003814939
Performs ID verification through BCM and Intelligent Key when pu

Page 4048 of 5121

NISSAN TEANA 2008 Service Manual B2190 NATS ANTENNA AMP.
SEC-39
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2190 NATS ANTENNA AMP.
DescriptionINFOID:0000000003814942
Performs ID verification thro
