SUNROOF SYSTEM
Before Operation Switch condition Roof and sunshade operation After Operation
OPEN: 1st Opens the sunshade
OPEN: 2ndThe sunshade opens, and
then the sunroof opens.
PUSHThe sunshade opens, and
then the sunroof tilts up.
OPEN: 1st Opens the sunroof
PUSH
Tilts down
CLOSE: 1st
CLOSE: 2ndThe sunroof tilts down, and
then sunshade closes.
JMKIA2617GB
JMKIA2619ZZ
JMKIA2620ZZ
JMKIA2621ZZ
JMKIA2627GBJMKIA2628ZZ
JMKIA2618GB
JMKIA2622ZZ
JMKIA2623ZZ
Page 3738 of 5121

SUNROOF SYSTEM
RF-7
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
PAUTO OPERATION
The sunroof or sunshade operates automatically to the fully-open or fully-closes position by operating the sun-
roof switch to the OPEN (2nd) or CLOSE (2nd) position.
RETAINED POWER OPERATION
Retained power operation is an additional power supply function that enables sunroof system to operate for 45
seconds after ignition switch is turned OFF.
RETAINED POWER FUNCTION CANCEL CONDITIONS
Front door CLOSE (door switch OFF)→OPEN (door switch ON)
Ignition switch is ON again.
Timer passed. (45 seconds)
ANTI-PINCH FUNCTION
CAUTION:
There are some small distances immediately before the closed position which cannot be detected.
The CPU of sunroof motor assembly monitors the sunroof condition using the signals from sunroof motor.
When sunroof motor assembly detects an interruption during auto operation (close or tilt down operation),
sunroof motor will tilt up or open [150 mm (5.91 in) or more] sunroof.
The CPU of sunshade motor assembly monitors the sunshade condition using the signals from sunshade
motor. When sunshade motor assembly detects an interruption during auto close operation, sunshade motor
will open [150 mm (5.91 in) or more] sunshade.
PUSH Tilts up
CLOSE: 1st Closes the sunroof
CLOSE: 2ndThe sunroof closes, and then
the sunshade closes.
CLOSE: 1st Closes the sunshade Before Operation Switch condition Roof and sunshade operation After Operation
JMKIA2624GB
JMKIA2625ZZ
JMKIA2622ZZ
JMKIA2626ZZ
JMKIA2627GBJMKIA2629ZZ
Page 3739 of 5121

RF-8
< FUNCTION DIAGNOSIS >
SUNROOF SYSTEM
Component Parts Location
INFOID:0000000003812846
Component DescriptionINFOID:0000000003812847
1. BCM M118, M119, M123 2. Combination meter M34 3. Sunroof motor assembly R101
4. Sunshade motor assembly R102 5. Sunroof switch R6 6. Front door switch (driver side) B34
A. Behind the combination meter B. Behind headlining
JMKIA2348ZZ
Component Function
BCM Supplies power to sunroof motor assembly and sunshade motor assembly.
Controls retained power function.
Combination meter Transmits vehicle speed signal to sunroof motor assembly and sunshade motor assembly.
Sunroof motor assemblyThe sunroof motor and CPU integrated type enable tilt up/down and slide open/close sunroof op-
eration by sunroof switch operation. And sends sunroof switch operation signal to sunshade mo-
tor assembly via communication line.
Sunshade motor assemblyThe sunshade motor and CPU integrated type enable open/close sunshade operation by sunroof
switch operation.
Sunroof switch Transmits switch operation signal to sunroof motor assembly.
Front door switch
(driver side/passenger side)Detects door open/close condition and transmits to BCM.
Page 3740 of 5121

DIAGNOSIS SYSTEM (BCM)
RF-9
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Function (BCM - COMMON ITEM)INFOID:0000000003812848
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions for each system.
NOTE:
It can perform the diagnosis modes except the following for all sub system selection items.
×: Applicable item
NOTE:
*1:At model with Intelligent Key system this item is displayed, but is not used.
*2: This item is displayed, but is not used. Diagnosis mode Function Description
Work Support Changes the setting for each system function.
Self Diagnostic Result Displays the diagnosis results judged by BCM.
CAN Diag Support MonitorMonitors the reception status of CAN communication viewed from BCM. Refer to CONSULT-III opera-
tion manual.
Data Monitor The BCM input/output signals are displayed.
Active Test The signals used to activate each device are forcibly supplied from BCM.
Ecu Identification The BCM part number is displayed.
Configuration Read and save the vehicle specification.
Write the vehicle specification when replacing BCM.
System Sub system selection itemDiagnosis mode
Work Support Data Monitor Active Test
Door lock DOOR LOCK×××
Rear window defogger REAR DEFOGGER××
Warning chime BUZZER××
Interior room lamp timer INT LAMP×××
Remote keyless entry system
MULTI REMOTE ENT*
1×××
Exterior lamp HEAD LAMP×××
Wiper and washer WIPER××
Turn signal and hazard warning lamps FLASHER×××
—
AIR CONDITONER*
2
Intelligent Key system
Engine start systemINTELLIGENT KEY×××
Combination switch COMB SW×
Body control system BCM×
NVIS - NATS IMMU××
Interior room lamp battery saver BATTERY SAVER×××
Back door opener system TRUNK××
Vehicle security system THEFT ALM×××
RAP system RETAINED PWR×
Signal buffer system SIGNAL BUFFER××
TPMS TPMS (AIR PRESSURE MONITOR)×××
Page 3741 of 5121

RF-10
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (BCM)
FREEZE FRAME DATA (FFD) AND IGN COUNTER
Freeze Frame Data
The BCM records the following condition at the moment a particular DTC is detected.
Vehicle Speed
Odo/Trip Meter
Vehicle Condition (BCM detected condition)
IGN Counter
IGN counter indicates the number of times that ignition switch is turned ON after DTC is detected.
The number is 0 when a malfunction is detected now.
The number increases like 1 → 2 → 3...38 → 39 after returning to the normal condition whenever ignition
switch OFF → ON.
The number is fixed to 39 until the self-diagnosis results are erased if it is over 39.
RETAINED PWR
RETAINED PWR : CONSULT-III Function (BCM - RETAINED PWR)INFOID:0000000003812849
Data monitor
CONSULT screen terms Description
SLEEP>LOCKWhile turning BCM status from low power consumption mode to normal mode (Power supply
position is “LOCK”)
SLEEP>OFFWhile turning BCM status from low power consumption mode to normal mode (Power supply
position is “OFF”.)
LOCK>ACC While turning power supply position from “LOCK” to “ACC”
ACC>ON While turning power supply position from “ACC” to “IGN”
RUN>ACCWhile turning power supply position from “RUN” to “ACC” (Vehicle is stopping and selector
lever is except P position.)
CRANK>RUNWhile turning power supply position from “CRANKING” to “RUN” (From cranking up the en-
gine to run it)
RUN>URGENT While turning power supply position from “RUN“ to “ACC” (Emergency stop operation)
ACC>OFF While turning power supply position from “ACC” to “OFF”
OFF>LOCK While turning power supply position from “OFF” to “LOCK”
OFF>ACC While turning power supply position from “OFF” to “ACC”
ON>CRANK While turning power supply position from “IGN” to “CRANKING”
OFF>SLEEPWhile turning BCM status from normal mode (Power supply position is “OFF”.) to low power
consumption mode
LOCK>SLEEPWhile turning BCM status from normal mode (Power supply position is “LOCK”.) to low pow-
er consumption mode
LOCK Power supply position is “LOCK” (Ignition switch OFF with steering is locked.)
OFF Power supply position is “OFF” (Ignition switch OFF with steering is unlocked.)
ACC Power supply position is “ACC” (Ignition switch ACC)
ON Power supply position is “IGN” (Ignition switch ON with engine stopped)
ENGINE RUN Power supply position is “RUN” (Ignition switch ON with engine running)
CRANKING Power supply position is “CRANKING” (At engine cranking)
Monitor Item Description
DOOR SW-DR Indicates [ON/OFF] condition of driver side door switch.
DOOR SW-AS Indicates [ON/OFF] condition of passenger side door switch.
Page 3742 of 5121

POWER SUPPLY AND GROUND CIRCUIT
RF-11
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
COMPONENT DIAGNOSIS
POWER SUPPLY AND GROUND CIRCUIT
BCM
BCM : Diagnosis ProcedureINFOID:0000000003812850
1.CHECK FUSE AND FUSIBLE LINK
Check that the following fuse and fusible link are not blown.
Is the fuse fusing?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit if a fuse or fusible link is
blown.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connectors.
3. Check voltage between BCM harness connector and ground.
Is the measurement value normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
Does continuity exist?
YES >> INSPECTION END
NO >> Repair or replace harness.
SUNROOF MOTOR ASSEMBLY
SUNROOF MOTOR ASSEMBLY : Diagnosis ProcedureINFOID:0000000003812851
1.CHECK POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect sunroof motor assembly connector.
3. Turn ignition switch ON.
4. Check voltage between sunroof motor assembly harness connector and ground.
Signal name Fuse and fusible link No.
Battery power supplyI (40A)
10 (10A)
(+)
Vol tag e
(Approx.) BCM (−)
Ground Connector Terminal
M118 1
Battery voltage
M119 11
BCM
GroundContinuity
Connector Terminal
M119 13 Existed
Page 3743 of 5121

RF-12
< COMPONENT DIAGNOSIS >
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between sunroof motor assembly harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
3.CHECK SUNROOF MOTOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM harness connector and sunroof motor assembly harness connector.
4. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
SUNSHADE MOTOR ASSEMBLY
SUNSHADE MOTOR ASSEMBLY : Diagnosis ProcedureINFOID:0000000003812852
1.CHECK POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect sunshade motor assembly connector.
3. Turn ignition switch ON.
(+)
(–)Voltage (V)
(Approx.) Sunroof motor assembly
Connector Terminal
R1013
Ground Battery voltage
6
Sunroof motor assembly
GroundContinuity
Connector Terminal
R1011
Existed
2
BCM Sunroof motor assembly
Continuity
Connector Terminal Connector Terminal
M1182
R1016
Existed
33
BCM
GroundContinuity
Connector Terminal
M1182
Not existed
3
Page 3744 of 5121

POWER SUPPLY AND GROUND CIRCUIT
RF-13
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
4. Check voltage between sunshade motor assembly harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between sunshade motor assembly harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
3.CHECK SUNSHADE MOTOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM harness connector and sunshade motor assembly harness connector.
4. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
(+)
(–)Voltage (V)
(Approx.) Sunshade motor assembly
Connector Terminal
R102 6 Ground Battery voltage
Sunshade motor assembly
GroundContinuity
Connector Terminal
R102 1 Existed
BCM Sunshade motor assembly
Continuity
Connector Terminal Connector Terminal
M118 2 R102 6 Existed
BCM
GroundContinuity
Connector Terminal
M118 2 Not existed
