NISSAN TEANA 2008 Service Manual SEC-96
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2108 STEERING LOCK RELAY
B2108 STEERING LOCK RELAY
DescriptionINFOID:0000000003815038
The steering lock relay ON signal is transmitted to IPDM E

Page 4106 of 5121

NISSAN TEANA 2008 Service Manual B2109 STEERING LOCK RELAY
SEC-97
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2109 STEERING LOCK RELAY
DescriptionINFOID:0000000003815041
The steering lock relay O

Page 4107 of 5121

NISSAN TEANA 2008 Service Manual SEC-98
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B210A STEERING LOCK CONDITION SWITCH
B210A STEERING LOCK CONDITION SWITCH
DescriptionINFOID:0000000003815044
There are 2 switches in the steering

SEC-98
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B210A STEERING LOCK CONDITION SWITCH
B210A STEERING LOCK CONDITION SWITCH
DescriptionINFOID:0000000003815044
There are 2 switches in the steering lock unit. IPDM E/R compares those 2 switches conditions to judge the
present steering status and transmit the result to BCM via CAN communication.
DTC LogicINFOID:0000000003815045
DTC DETECTION LOGIC
NOTE:
If DTC B210A is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to SEC-
28, "IPDM E/R : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE 1
1. Press the push-button ignition switch under the following conditions and wait for at least 1 second.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-98, "Diagnosis Procedure".
NO >> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE 2
1. Turn ignition switch ON.
2. Turn ignition switch OFF.
3. Press driver side door switch and wait for at least 1 second.
4. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-98, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003815046
1.INSPECTION START
Check the case in which DTC is detected.
Case1: It is detected after ignition switch is changed from OFF to ON
Case2: It is detected after ignition switch is changed from ON to OFF and door switch is pressed
In which case is DTC detected?
Case1 >> GO TO 2.
Case2 >> GO TO 6.
2.CHECK BCM OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect steering lock unit connector and IPDM E/R connector.
3. Check voltage between steering lock unit harness connector and ground.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B210ASTRG LCK STATE
SWIPDM E/R detects the difference between steering
condition switches 1 and 2 for 1 second Harness or connectors
[Steering lock unit circuit (BCM
side) is open or shorted]
Harness or connectors
[Steering lock unit circuit (IPDM E/
R side) is open or shorted]
Steering lock unit
IPDM E/R

Page 4108 of 5121

NISSAN TEANA 2008 Service Manual B210A STEERING LOCK CONDITION SWITCH
SEC-99
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK STE

Page 4109 of 5121

NISSAN TEANA 2008 Service Manual SEC-100
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B210A STEERING LOCK CONDITION SWITCH
NO >> Repair or replace harness.
6.CHECK BCM OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect steer

Page 4110 of 5121

NISSAN TEANA 2008 Service Manual B210A STEERING LOCK CONDITION SWITCH
SEC-101
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-34,

Page 4111 of 5121

NISSAN TEANA 2008 Service Manual SEC-102
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B210B STARTER CONTROL RELAY
B210B STARTER CONTROL RELAY
DescriptionINFOID:0000000003815047
Starter control relay, integrated in IPDM E/R, permit

Page 4112 of 5121

NISSAN TEANA 2008 Service Manual B210C STARTER CONTROL RELAY
SEC-103
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B210C STARTER CONTROL RELAY
DescriptionINFOID:0000000003815050
Starter control rela
