24. Remove console switch panel.
Disengage pawls of console switch panel (1) with remover tool
(A).
Pull up console switch panel.
25. Remove console finisher assembly.
Put selector lever in the [N] position.
Remove console finisher assembly (1) fixing metal clips and
pawls sequentially from the front side with remover tool.
Pull console finisher assembly, upward to disengage from cen-
ter console.
Disconnect harness connectors.
26. Remove control device upper case.
Put selector lever in the [P] position.
Remove control device upper case (1) mounting screws (A).
Pull control device upper case, upward to disengage from con-
trol device assembly.
Disconnect harness clip (B).
27. Remove console rear finisher.
Pull back console rear finisher (1) by using a remover tool (A),
then disengage pawls and metal clips.
Disconnect inside key antenna connector.
28. Remove center console assembly.
Remove center console fixing screws (A).
: Pawl
JMJIA1904ZZ
: Pawl
: Metal clip
JMJIA1905ZZ
JMJIA1906ZZ
: Pawl
: Metal clip
JMJIA1907ZZ
JMJIA1908ZZ
Page 3058 of 5121

IP-18
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
Put front seat to the front most position.
Remove center console fixing screws (B).
Put front seat to the rear most position.
Lift up center console assembly back side.
Disconnect harness connectors.
29. Remove steering wheel assembly. Refer to ST-12, "
Removal and Installation".
30. Remove steering column covers.
Remove steering column cover fixing screws (A).
Pull up steering column upper cover (1), and then remove
steering column upper cover.
Pull down steering column lower cover (2), and then remove
steering column lower cover.
31. Remove combination switch. Refer to BCS-79, "
Removal and Installation".
32. Remove spiral cable. Refer to SR-9, "
Removal and Installation".
33. Remove instrument finisher A.
Pull back instrument finisher A (1), and disengage metal clips.
34. Remove cluster lid A.
Disconnect meter control switch harness connector (A).
JMJIA1909ZZ
: Pawl
JMJIA1910ZZ
: Metal clip
JMJIA1911ZZ
JMJIA1912ZZ
Page 3059 of 5121
INSTRUMENT PANEL ASSEMBLY
IP-19
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
IP
N
O
P
Pull back cluster lid A (1), and disengage metal clips.
35. Remove combination meter. Refer to MWI-126, "
Removal and Installation".
36. Remove cluster lid D.
Remove cluster lid D (1) fixing pawls and metal clip with
remover tool (A).
Pull back cluster lid D.
Disconnect harness connectors.
37. Remove push button ignition switch. Refer to SEC-205, "
Removal and Installation".
38. Remove cluster lid lower finisher.
Remove cluster lid lower finisher (1) fixing screws (A).
Pull back cluster lid lower finisher.
39. Remove cluster lid C.
Remove cluster lid C (1) fixing screws (A).
Pull back cluster lid C.
Disconnect harness connector.
: Metal clip
JMJIA1913ZZ
: Pawl
: Metal clip
JMJIA1915ZZ
: Pawl
JMJIA1916ZZ
JMJIA1917ZZ
Page 3060 of 5121

IP-20
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
40. Remove AV C/U (or Audio unit).
AV C/U: Refer to AV-648, "
Removal and Installation".
Audio unit: Refer to AV-37, "
Removal and Installation".
Remove AV C/U (or Audio unit) (1) fixing screws (A).
Pull back AV C/U (or Audio unit).
Disconnect harness connectors.
41. Remove display unit.
Remove display unit (1) fixing screws (A).
Pull toward the arrow direction.
Disconnect harness connector.
42. Remove center speaker grille.
Disengage center speaker grille (1) fixing clips and pawls with
remover tool (A).
Pull up center speaker grille.
43. Remove center speaker (with BOSE AUDIO). Refer to AV-384, "
Removal and Installation".
44. Disconnect front passenger air bag module connector. Refer to SR-12, "
Exploded View".
45. Remove front passenger air bag module fixing bolt. Refer to SR-12, "
Removal and Installation".
46. Remove instrument panel assembly mounting bolt (A), screws (B) and clips (C).
47. Remove instrument panel assembly.
JMJIA1918ZZ
JMJIA1919ZZ
: Clip
: Pawl
JMJIA1920ZZ
JMJIA1921ZZ
Page 3061 of 5121
![NISSAN TEANA 2008 Service Manual INSTRUMENT PANEL ASSEMBLY
IP-21
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
IP
N
O
P
Put selector lever in the [D] position.
Pull back instrument panel assembly, and then remove front
squawker LH NISSAN TEANA 2008 Service Manual INSTRUMENT PANEL ASSEMBLY
IP-21
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
IP
N
O
P
Put selector lever in the [D] position.
Pull back instrument panel assembly, and then remove front
squawker LH](/manual-img/5/57391/w960_57391-3060.png)
INSTRUMENT PANEL ASSEMBLY
IP-21
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
IP
N
O
P
Put selector lever in the [D] position.
Pull back instrument panel assembly, and then remove front
squawker LH harness clip (A).
Remove instrument panel from passenger door opening portion.
CAUTION:
Cover center console upper surface with a shop cloth to prevent it from being damaged.
When removing instrument panel assembly, 2 workers are required so as to prevent it from drop-
ping.
48. Remove the following parts after removing instrument panel assembly.
Front passenger air bag module. Refer to SR-12, "
Removal and Installation".
Side ventilator grille LH/RH. Refer to VTL-46, "
SIDE VENTILATOR GRILLE : Removal and Installation".
Side defroster nozzle LH/RH. Refer to VTL-47, "
SIDE DEFROSTER GRILLE : Removal and Installa-
tion".
Ventilator duct LH/RH. Refer to VTL-48, "
VENTILATOR DUCT : Removal and Installation".
Defroster nozzle. Refer to VTL-49, "
SIDE DEFROSTER NOZZLE : Removal and Installation".
Antenna feeder. Refer to AV-44, "
Harness Layout".
INSTALLATION
Install in the reverse order of removal.
JMJIA1923ZZ
Page 3062 of 5121
IP-22
< ON-VEHICLE REPAIR >
CENTER CONSOLE ASSEMBLY
CENTER CONSOLE ASSEMBLY
Exploded ViewINFOID:0000000003816779
Removal and InstallationINFOID:0000000003819349
REMOVAL
1. Ashtray lamp harness 2. Cigarette lighter complete 3. Cigarette lighter ring
4. Console ashtray assembly 5. Instrument lower cover RH 6. Instrument lower cover LH
7. Center console assembly 8. Console switch panel 9. Console bracket
10. Inside key antenna 11. Console rear ashtray 12. Console rear finisher
13. Rear ventilator grille 14. Power socket cap 15. Power socket inner case
16. Console mask 17. Console lid assembly 18. Cup holder assembly
19. Console finisher assembly 20. Indicator lamp harness 21. Shift lock switch
22. Inner ashtray 23. Control device upper case 24. Auxiliary input jacks
JMJIA1924ZZ
Page 3063 of 5121

CENTER CONSOLE ASSEMBLY
IP-23
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
IP
N
O
P
1. Remove instrument finisher D.
Remove instrument finisher D (1) fixing clips with remover tool
(A).
Pull back instrument finisher D, and then remove instrument
finisher D.
2. Remove instrument finisher E.
Remove instrument finisher E (1) fixing clips with remover tool
(A).
Pull back instrument finisher E, and then remove instrument
finisher E.
3. Remove front body side welt LH. Refer to INT-39, "
Removal and Installation".
4. Remove hood opener lever fixing bolts. Refer to DLK-220, "
Removal and Installation".
5. Remove fuse block lid.
Open the fuse block lid (1).
Pull fuse block lid, backward to disengage from instrument
lower panel LH.
6. Remove instrument lower panel LH.
Remove instrument lower panel LH (1) fixing screw (A).
Pull instrument lower panel LH, backward to disengage from
instrument panel assembly.
Release data link connector (pawl) then remove it from instru-
ment lower panel LH.
Disconnect harness connectors and aspirator duct.
: Clip
JMJIA1892ZZ
: Clip
JMJIA1893ZZ
: Pawl
JMJIA1896ZZ
: Clip
: Pawl
JMJIA1897ZZ
Page 3064 of 5121
IP-24
< ON-VEHICLE REPAIR >
CENTER CONSOLE ASSEMBLY
7. Remove instrument lower cover LH.
