REAR REGULATOR
Install in the reverse order of removal.
Disassembly and AssemblyINFOID:0000000003825391
DISASSEMBLY
Remove power window motor from regulator assembly.
ASSEMBLY
Assemble in the reverse order of disassembly.
Inspection and AdjustmentINFOID:0000000003825392
Inspection after Removal
Check the regulator assembly for the following items. Replace or grease it if a malfunction is detected.
Wire wear
Regulator deformation
The arrows in the figure show the application points of the multi-purpose grease.
FITTING INSPECTION
Check that the glass is fit securely into the sash groove.
Lower the glass slightly [approximately 10 to 20 mm (0.394 to 0.787 in)], and check that the clearance to the
sash is parallel. Loosen the regulator mounting bolts, guide rail mounting bolts, and glass and carrier plate
mounting bolts to correct the glass position if the clearance between the glass and sash is not parallel.
: Grease application point
JMKIA2318ZZ
