2008 NISSAN TEANA Service Manual

maintenance schedule fog light bulb manual radio set immobilizer refuelling windshield wipers

Load previous 8 pages

Page 4049 of 5121

NISSAN TEANA 2008 Service Manual SEC-40
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2190 NATS ANTENNA AMP.
3.CHECK KEY SLOT CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between key slot harness connector and BCM harn

Page 4050 of 5121

NISSAN TEANA 2008 Service Manual B2190 NATS ANTENNA AMP.
SEC-41
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
1. Turn ignition switch OFF.
2. Disconnect key slot connector.
3. Check continuity betwe

Page 4051 of 5121

NISSAN TEANA 2008 Service Manual SEC-42
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2191 DIFFERENCE OF KEY
B2191 DIFFERENCE OF KEY
DescriptionINFOID:0000000003814945
Performs ID verification through BCM and Intelligent Key when

Page 4052 of 5121

NISSAN TEANA 2008 Service Manual B2192 ID DISCORD, IMMU-ECM
SEC-43
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2192 ID DISCORD, IMMU-ECM
DescriptionINFOID:0000000003814948
BCM performs the ID ver

B2192 ID DISCORD, IMMU-ECM
SEC-43
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2192 ID DISCORD, IMMU-ECM
DescriptionINFOID:0000000003814948
BCM performs the ID verification with ECM that allows the engine to start. Start the engine if the ID is OK.
ECM prevents the engine from starting if the ID is not registered. BCM starts the communication with ECM if
ignition switch is turned ON.
DTC LogicINFOID:0000000003814949
DTC DETECTION LOGIC
NOTE:
If DTC B2192 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
If DTC B2192 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-43, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814950
1.PERFORM INITIALIZATION
Perform initialization with CONSULT-III. Reregister all Intelligent Keys.
For initialization and registration of Intelligent Key. Refer to “CONSULT-III Operation Manual NATS-IVIS/
NVIS”.
Can the system be initialized and can the engine be started with reregistered Intelligent Key?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE BCM
1. Replace BCM. Refer to BCS-78, "
Removal and Installation".
2. Perform initialization with CONSULT-III.
For initialization, refer to “CONSULT-III Operation Manual NATS-IVIS/NVIS”.
Can the system be initialized and can the engine be started with reregistered Intelligent Key?
YES >> INSPECTION END
NO >> GO TO 3.
3.REPLACE ECM
1. Replace ECM. Refer to EC-14, "
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Descrip-
tion".
2. Perform initialization with CONSULT-III.
Can the system be initialized and can the engine be started with reregistered Intelligent Key?
YES >> INSPECTION END
NO >> GO TO 4.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2192ID DISCORD, IMMU-
ECMThe ID verification result between BCM and ECM is
NG. The registration is necessary.BCM
ECM

Page 4053 of 5121

NISSAN TEANA 2008 Service Manual SEC-44
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2192 ID DISCORD, IMMU-ECM
4.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END

Page 4054 of 5121

NISSAN TEANA 2008 Service Manual B2193 CHAIN OF ECM-IMMU
SEC-45
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2193 CHAIN OF ECM-IMMU
DescriptionINFOID:0000000003814951
BCM performs the ID verificat

Page 4055 of 5121

NISSAN TEANA 2008 Service Manual SEC-46
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2013 ID DISCORD, IMMU-STRG
B2013 ID DISCORD, IMMU-STRG
DescriptionINFOID:0000000003814954
BCM performs the ID verification with the steering loc

Page 4056 of 5121

NISSAN TEANA 2008 Service Manual B2014 CHAIN OF STRG-IMMU
SEC-47
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2014 CHAIN OF STRG-IMMU
DescriptionINFOID:0000000003814957
BCM performs the ID verific
