Page 4577 of 5121
TM-104
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SHIFT LOCK SYSTEM
JCDWM0253GB
Page 4578 of 5121
SHIFT LOCK SYSTEM
TM-105
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Component Function CheckINFOID:0000000003862438
1. CHECK CVT SHIFT LOCK OPERATION
1. Turn ignition switch ON.
2. Shift the selector lever to the “P” position.
3. Attempt to shift the selector lever to any other position with the brake pedal released.
Can the selector lever be shifted to any other position?
JCDWM0254GB
Page 4579 of 5121
![NISSAN TEANA 2008 Service Manual TM-106
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SHIFT LOCK SYSTEM
YES >> Go to TM-106, "Diagnosis Procedure".
NO >> GO TO 2.
2. CHECK CVT SHIFT LOCK OPERATION
Attempt to shift the selector lever to any o NISSAN TEANA 2008 Service Manual TM-106
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SHIFT LOCK SYSTEM
YES >> Go to TM-106, "Diagnosis Procedure".
NO >> GO TO 2.
2. CHECK CVT SHIFT LOCK OPERATION
Attempt to shift the selector lever to any o](/manual-img/5/57391/w960_57391-4578.png)
TM-106
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SHIFT LOCK SYSTEM
YES >> Go to TM-106, "Diagnosis Procedure".
NO >> GO TO 2.
2. CHECK CVT SHIFT LOCK OPERATION
Attempt to shift the selector lever to any other position with the brake pedal depressed.
Can the selector lever be shifted to any other position?
YES >> INSPECTION END
NO >> Go to TM-106, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003862439
1. CHECK POWER SOURCE
1. Turn ignition switch ON.
2. Check voltage between stop lamp switch vehicle side harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check the following.
Harness for short or open between fuse block J/B connector terminal 4F and stop lamp switch
harness connector terminal 3
10 A fuse [No. 3, located in the fuse block J/B]
Ignition switch
2.CHECK STOP LAMP SWITCH
Check stop lamp switch. Refer to TM-107, "
Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace stop lamp switch. Refer to BR-17, "
Exploded View".
3.CHECK HARNESS BETWEEN STOP LAMP SWITCH AND CONTROL DEVICE (PART 1)
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch vehicle side harness connector and control device vehicle side harness con-
nector.
3. Check continuity between stop lamp switch vehicle side harness connector terminal and control device
vehicle side harness connector terminal.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts
4.CHECK HARNESS BETWEEN STOP LAMP SWITCH AND CONTROL DEVICE (PART 2)
Check continuity between stop lamp switch vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts
Stop lamp switch vehicle side harness connector
GroundVoltage (Approx.)
Connector Terminal
E115 3 Battery Voltage
Stop lamp switch vehicle side harness connector Control device vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
E115 4 M57 6 Existed
Stop lamp switch vehicle side harness connector
GroundContinuity
Connector Terminal
E115 4 Not existed
Page 4580 of 5121
![NISSAN TEANA 2008 Service Manual SHIFT LOCK SYSTEM
TM-107
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
5.CHECK GROUND CIRCUIT
Check continuity between control device vehicle side harness connector and ground. NISSAN TEANA 2008 Service Manual SHIFT LOCK SYSTEM
TM-107
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
5.CHECK GROUND CIRCUIT
Check continuity between control device vehicle side harness connector and ground.](/manual-img/5/57391/w960_57391-4579.png)
SHIFT LOCK SYSTEM
TM-107
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
5.CHECK GROUND CIRCUIT
Check continuity between control device vehicle side harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace damaged parts
6.CHECK CONTROL DEVICE
1. Shift selector lever to “P” position.
2. Check continuity between control device connector.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace shift lock unit. Refer to TM-155, "
Exploded View".
Component Inspection (Stop Lamp Switch)INFOID:0000000003862440
1.CHECK STOP LAMP SWITCH
Check continuity between stop lamp switch connector terminals 3 and 4.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace stop lamp switch. Refer to BR-17, "
Exploded View".
Control device vehicle side harness connector
GroundContinuity
Connector Terminal
M57 7 Existed
Control device connector
Continuity
Connector Terminal
M57 6 7 Existed
Stop lamp switch connector
Condition Continuity
Connector Terminal
E115 3 4Depressed brake pedal Existed
Released brake pedal Not existed
Page 4581 of 5121
![NISSAN TEANA 2008 Service Manual TM-108
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SPORT MODE SWITCH
SPORT MODE SWITCH
DescriptionINFOID:0000000003858969
The sport mode switch is installed to the selector lever knob.
When pushing the NISSAN TEANA 2008 Service Manual TM-108
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SPORT MODE SWITCH
SPORT MODE SWITCH
DescriptionINFOID:0000000003858969
The sport mode switch is installed to the selector lever knob.
When pushing the](/manual-img/5/57391/w960_57391-4580.png)
TM-108
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SPORT MODE SWITCH
SPORT MODE SWITCH
DescriptionINFOID:0000000003858969
The sport mode switch is installed to the selector lever knob.
When pushing the sport mode switch (SPORT indicator lamp turns ON), the driving condition becomes sport
mode. When pushing again the sport mode switch (SPORT indicator lamp turns OFF), the driving condition
changes to D range.
Component Function CheckINFOID:0000000003858970
1.CHECK SPORT MODE SWITCH SIGNAL
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Check the On/Off operations of monitor item.
Is the inspection result normal?
YES >> INSPECTION END.
NO >> Go to TM-108, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003858971
1. CHECK CAN COMMUNICATION CIRCUIT
Perform “Self Diagnostic Results” mode for “TRANSMISSION”.
Is
“U1000 CAN COMM CIRCUIT” indicated?
YES >> Check CAN communication line. Refer to TM-41, "Description".
NO >> GO TO 2.
2.CHECK COMBINATION METER
Perform “Self Diagnostic Results” mode for “METER/M&A”.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check DTC detected item. Refer to MWI-67, "
DTC Index".
3.CHECK SPORT MODE SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect control device connector.
3. Turn ignition switch ON.
4. Check voltage between control device vehicle side harness connector terminals.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 6.
4.CHECK SPORT MODE SWITCH
Check continuity between control device connector terminals.
Monitor item Condition Status
SPORT MODE SWWhile pushing sport mode switch On
Other conditions Off
Control device vehicle side harness connector
Voltage (Approx.)
ConnectorTe r m i n a l
(+) (−)
M57 1 4 5 V
Page 4582 of 5121
![NISSAN TEANA 2008 Service Manual SPORT MODE SWITCH
TM-109
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK MALFUNCTI NISSAN TEANA 2008 Service Manual SPORT MODE SWITCH
TM-109
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK MALFUNCTI](/manual-img/5/57391/w960_57391-4581.png)
SPORT MODE SWITCH
TM-109
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK MALFUNCTIONING ITEM
Check control device connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace damaged parts.
6.CHECK GROUND CIRCUIT
Check continuity between control device vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace damaged parts.
7.CHECK HARNESS BETWEEN CONTROL DEVICE AND COMBINATION METER (PART 1)
1. Turn ignition switch OFF.
2. Disconnect combination meter connector.
3. Check continuity between control device vehicle side harness connector terminal and combination meter
vehicle side harness connector terminal.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace damaged parts.
8.CHECK HARNESS BETWEEN CONTROL DEVICE AND COMBINATION METER (STEP 2)
Check continuity between control device vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair or replace damaged parts.
9.DETECT MALFUNCTIONING ITEMS
Check combination meter connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace damaged parts.
Control device connector
Condition Continuity
Connector Terminal
M57 1 4While pushing sport mode switch Existed
Other condition Not existed
Control device vehicle side harness connector
GroundContinuity
Connector Terminal
M57 4 Existed
Control device vehicle side harness connector Combination meter vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
M57 1 M34 32 Existed
Control device vehicle side harness connector
GroundContinuity
Connector Terminal
M57 1 Not existed
Page 4583 of 5121
TM-110
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SPORT MODE SWITCH
10.CHECK COMBINATION METER
1. Reconnect all the connectors.
2. Turn ignition switch ON.
3. Select “SPORT MODE SW” on “Data Monitor” mode for “METER/M&A”, and check the On/Off operations
of monitor item. Refer to MWI-53, "
Reference Value".
Is the inspection result normal?
YES >> GO TO 11.
NO >> Replace combination meter. Refer to MWI-126, "
Exploded View".
11 .DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-153, "Exploded View".
NO >> Repair or replace damaged parts.
Page 4584 of 5121
![NISSAN TEANA 2008 Service Manual TCM
TM-111
< ECU DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ECU DIAGNOSIS
TCM
Reference ValueINFOID:0000000003849059
VALUES ON THE DIAGNOSIS TOOL
Item name Condition Display value (App NISSAN TEANA 2008 Service Manual TCM
TM-111
< ECU DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ECU DIAGNOSIS
TCM
Reference ValueINFOID:0000000003849059
VALUES ON THE DIAGNOSIS TOOL
Item name Condition Display value (App](/manual-img/5/57391/w960_57391-4583.png)
TCM
TM-111
< ECU DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ECU DIAGNOSIS
TCM
Reference ValueINFOID:0000000003849059
VALUES ON THE DIAGNOSIS TOOL
Item name Condition Display value (Approx.)
VSP SENSOR During drivingApproximately matches the speedometer
reading.
ESTM VSP SIG During drivingApproximately matches the speedometer
reading.
PRI SPEED SEN During driving (lock-up ON) Approximately matches the engine speed.
ENG SPEED SIG Engine running Closely matches the tachometer reading.
SEC HYDR SEN “N” position idle 0.5 - 0.8 V
PRI HYDR SEN “N” position idle 0.7 - 3.5 V
ATFTEMP COUNT* When CVT fluid temperature is 20°C (68°F). 47
When CVT fluid temperature is 80°C (176°F). 161
VIGN SEN Ignition switch: ON Battery voltage
VEHICLE SPEED During drivingApproximately matches the speedometer
reading.
PRI SPEED During driving (lock-up ON) Approximately matches the engine speed.
SEC SPEED During driving50 X Approximately matches the speedom-
eter reading.
ENG SPEED Engine running Closely matches the tachometer reading.
GEAR RATIO During driving 2.37 - 0.43
ACC PEDAL OPENReleased accelerator pedal - Fully depressed
accelerator pedal0.0/8 - 8.0/8
SEC PRESS “N” position idle 0.5 - 0.9 MPa
PRI PRESS “N” position idle 0.3 - 0.9 MPa
STM STEP During driving -20 step – 190 step
ISOLT1Lock-up OFF 0.0 A
Lock-up ON 0.7 A
ISOLT2Release your foot from the accelerator pedal. 0.8 A
Press the accelerator pedal all the way down. 0.0 A
ISOLT3Secondary pressure low - Secondary pressure
high.0.8 - 0.0 A
SOLMON1Lock-up OFF 0.0 A
Lock-up ON 0.6 - 0.7 A
SOLMON2“N” position idle 0.8 A
When stalled 0.3 - 0.6 A
SOLMON3“N” position idle 0.6 - 0.7 A
When stalled 0.4 - 0.6 A
INH SW3MSelector lever in “D” and “L” positions On
Selector lever in “P”, “R” and “N” positions Off
INH SW4Selector lever in “R” and “D” positions On
Selector lever in “P”, “N” and “L” positions Off
