Page 1305 of 5121
![NISSAN TEANA 2008 Service Manual KEY SLOT ILLUMINATION
DLK-89
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace harness.
5.C NISSAN TEANA 2008 Service Manual KEY SLOT ILLUMINATION
DLK-89
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace harness.
5.C](/manual-img/5/57391/w960_57391-1304.png)
KEY SLOT ILLUMINATION
DLK-89
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace harness.
5.CHECK KEY SLOT GROUND CIRCUIT 1
Check continuity between key slot harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace harness.
6.CHECK KEY SLOT
Refer to DLK-89, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace key slot. Refer to DLK-241, "
Removal and Installation".
7.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
8.CHECK KEY SLOT GROUND CIRCUIT 2
Check continuity between key slot harness connector and ground.
Is the inspection result normal?
YES >> Repair or replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
Component InspectionINFOID:0000000003794905
1.CHECK KEY SLOT ILLUMINATION
1. Turn ignition switch OFF.
2. Disconnect key slot connector.
3. Connect battery power supply to key slot terminals 5 and 6, and check the operation.
Is the inspection result normal?
YES >> INSPECTION END
(+)
(–)Voltage (V)
(Approx.) Key slot
Connector Terminal
M99 5 Ground Battery voltage
Key slot
GroundContinuity
Connector Terminal
M99 7 Existed
Key slot
GroundContinuity
Connector Terminal
M99 7 Existed
Key slot
Operation
ConnectorTe r m i n a l
(+) (−)
M99 5 6 Key slot illuminates
Page 1306 of 5121
DLK-90
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
KEY SLOT ILLUMINATION
NO >> Replace key slot. Refer to DLK-241, "Removal and Installation".
Page 1307 of 5121
![NISSAN TEANA 2008 Service Manual HORN FUNCTION
DLK-91
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
HORN FUNCTION
DescriptionINFOID:0000000003794906
Perform answer-back for each operation with NISSAN TEANA 2008 Service Manual HORN FUNCTION
DLK-91
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
HORN FUNCTION
DescriptionINFOID:0000000003794906
Perform answer-back for each operation with](/manual-img/5/57391/w960_57391-1306.png)
HORN FUNCTION
DLK-91
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
HORN FUNCTION
DescriptionINFOID:0000000003794906
Perform answer-back for each operation with horn.
Component Function CheckINFOID:0000000003794907
1.CHECK FUNCTION
1. Select “HORN” in “ACTIVE TEST” mode with CONSULT-III.
2. Check the horn (high/low) operation.
Is the operation normal?
YES >> Horn function is OK.
NO >> Go to DLK-91, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000003794908
1.CHECK HORN FUNCTION
Check horn function with horn switch
Do the horns sound?
YES >> GO TO 2.
NO >> Go to HRN-2, "
Wiring Diagram - HORN -".
2.CHECK HORN RELAY POWER SUPPLY
1. Turn ignition switch ON.
2. Perform “ACTIVE TEST” (“HORN”) with CONSULT-Ill.
3. Check voltage between horn relayconnector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK HORN RELAY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector and horn relay.
3. Check continuity between IPDM E/R harness connector and horn relay connector.
4. Check continuity between driver seat control unit harness connector and ground.
Is the inspection result normal?
Test item Description
HORN ON Horn relay ON (for 20 ms)
Horn relay
GroundTe s t i t e mVoltage (V)
(Approx.)
Connector Terminal
E5 1 HORNONBattery voltage → 0 →
Battery voltage
Other than above Battery voltage
IPDM E/R Horn relay
Continuity
Connector Terminal Connector Terminal
E11 44 E5 1 Existed
IPDM E/R
GroundContinuity
Connector Terminal
E11 44 Not existed
Page 1308 of 5121
DLK-92
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HORN FUNCTION
YES >> Replace IPDM E/R. Refer to PCS-34, "Removal and Installation".
NO >> Repair or replace harness.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
Is the inspection result normal?
>> INSPECTION END
Page 1309 of 5121
COMBINATION METER DISPLAY FUNCTION
DLK-93
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
COMBINATION METER DISPLAY FUNCTION
DescriptionINFOID:0000000003794909
Displays each operation method guide and warning for system malfunction.
Component Function CheckINFOID:0000000003794910
1.CHECK FUNCTION
Check the operation with (“LCD”) in the Active Test.
Is the inspection result normal?
YES >> Meter display is OK.
NO >> Refer to DLK-93, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003794911
1.CHECK COMBINATION METER
Refer to MWI-67, "
DTC Index".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check combination meter. Refer to MWI-4, "
Work flow".
2.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END Is each warning displayed on meter display?
Page 1310 of 5121
DLK-94
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BUZZER (COMBINATION METER)
BUZZER (COMBINATION METER)
DescriptionINFOID:0000000003794912
Performs operation method guide and warning with buzzer.
Component Function CheckINFOID:0000000003794913
1.CHECK FUNCTION
1. Check the operation with “INSIDE BUZZER” in the Active Test.
2. Touch “TAKE OUT”, “KNOB”or “KEY”on screen.
Is the inspection result normal?
Yes >> Warning buzzer in combination meter is OK.
No >> Refer to DLK-94, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003794914
1.CHECK METER BUZZER CIRCUIT
Refer to WCS-21, "
Component Function Check".
Is the inspection result normal?
Ye s > > G O T O 2 .
No >> Repair or replace meter buzzer circuit.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
Page 1311 of 5121
KEY WARNING LAMP
DLK-95
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
KEY WARNING LAMP
DescriptionINFOID:0000000003794915
Performs operation method guide and warning together with buzzer.
Component Function CheckINFOID:0000000003794916
1.CHECK FUNCTION
Check the operation with “INDICATOR” in “Active Test” mode with CONSULT-III.
Is the inspection result normal?
YES >> Key warning lamp in combination meter is OK.
NO >> Refer to DLK-95, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003794917
1.CHECK KEY WARNING LAMP
Refer toMWI-4, "
Work flow".
Is the inspection result normal?
Yes >> GO TO 2.
No >> Repair or replace key warning lamp circuit.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
Test item Condition
INDICATORRED ON Key warning lamp (red) illuminates
RED IND Key warning lamp (red) flashes
Page 1312 of 5121
DLK-96
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HAZARD FUNCTION
HAZARD FUNCTION
DescriptionINFOID:0000000003794918
Perform answer-back for each operation with number of blinks.
Component Function CheckINFOID:0000000003794919
1.CHECK FUNCTION
Check hazard warning lamp (“FLASHER”) in Active Test.
Is the inspection result normal?
YES >> Hazard warning lamp circuit is OK.
NO >> Refer to DLK-96, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003794920
1.CHECK HAZARD SWITCH CIRCUIT
Refer to EXL-90, "
Wiring Diagram - TURN AND HAZARD WARNING LAMPS -" (For xenon type) or EXL-262,
"Wiring Diagram - TURN AND HAZARD WARNING LAMPS -" (For halogen type)
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace hazard warning switch circuit. Refer to EXL-328, "
Symptom Table".
2.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
