NISSAN TEANA 2008 Service Manual POWER WINDOW SWITCH DOES NOT ILLUMINATE
PWC-83
< SYMPTOM DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
PWC
N
O
P
POWER WINDOW SWITCH DOES NOT ILLUMINATE
Diagnosis ProcedureINFOID:0000000003826049
1.REPLACE POWER

Page 3714 of 5121

NISSAN TEANA 2008 Service Manual PWC-84
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003826050
The Supplemental Restraint

PWC-84
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003826050
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIRBAG” and “SEAT BELT” of this
Service Manual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIRBAG”.
Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.
Precaution Necessary for Steering Wheel Rotation after Battery Disconnect
INFOID:0000000003826051
NOTE:
Before removing and installing any control units, first turn the push-button ignition switch to the LOCK posi-
tion, then disconnect both battery cables.
After finishing work, confirm that all control unit connectors are connected properly, then re-connect both
battery cables.
Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If a DTC is detected, perform trouble diagnosis according to self-diagnosis results.
This vehicle is equipped with a push-button ignition switch and a steering lock unit.
If the battery is disconnected or discharged, the steering wheel will lock and cannot be turned.
If turning the steering wheel is required with the battery disconnected or discharged, follow the procedure
below before starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Turn the push-button ignition switch to ACC position.
(At this time, the steering lock will be released.)
3. Disconnect both battery cables. The steering lock will remain released with both battery cables discon-
nected and the steering wheel can be turned.
4. Perform the necessary repair operation.
5. When the repair work is completed, re-connect both battery cables. With the brake pedal released, turn
the push-button ignition switch from ACC position to ON position, then to LOCK position. (The steering
wheel will lock when the push-button ignition switch is turned to LOCK position.)
6. Perform self-diagnosis check of all control units using CONSULT-III.

Page 3715 of 5121

NISSAN TEANA 2008 Service Manual POWER WINDOW MAIN SWITCH
PWC-85
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
PWC
N
O
P
ON-VEHICLE REPAIR
POWER WINDOW MAIN SWITCH
Exploded ViewINFOID:0000000003826052
Removal and InstallationINFOID:00

Page 3716 of 5121

NISSAN TEANA 2008 Service Manual PWC-86
< ON-VEHICLE REPAIR >
FRONT POWER WINDOW SWITCH (PASSENGER SIDE)
FRONT POWER WINDOW SWITCH (PASSENGER SIDE)
Exploded ViewINFOID:0000000003857778
Removal and InstallationINFOID:0000000003857779

Page 3717 of 5121

NISSAN TEANA 2008 Service Manual REAR POWER WINDOW SWITCH
PWC-87
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
PWC
N
O
P
REAR POWER WINDOW SWITCH
Exploded ViewINFOID:0000000003857780
Removal and InstallationINFOID:0000000003857781
REM

Page 3718 of 5121

NISSAN TEANA 2008 Service Manual PWO
PWO-1
ELECTRICAL & POWER CONTROL
C
DE
F
G H
I
J
K L
B
SECTION PWO
A
O P
N
CONTENTS
POWER OUTLET
COMPONENT DIAGNOSIS
..........................2
CIGARETTE LIGHTER ................................

Page 3719 of 5121

NISSAN TEANA 2008 Service Manual PWO-2
< COMPONENT DIAGNOSIS >
CIGARETTE LIGHTER
COMPONENT DIAGNOSIS
CIGARETTE LIGHTER
Wiring Diagram - CIGARETTE LIGHTER -INFOID:0000000003792628
JCMWM1667GB

Page 3720 of 5121

NISSAN TEANA 2008 Service Manual PWO
CIGARETTE LIGHTER
PWO-3
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L B A
O
P N
JCMWM1668GB
