NISSAN TEANA 2008 Service Manual BRC-140
< ECU DIAGNOSIS >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
For malfunction of ABS, only the EBD is activated and the condition of vehicle is the same condition of vehi-
cle

BRC-140
< ECU DIAGNOSIS >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
For malfunction of ABS, only the EBD is activated and the condition of vehicle is the same condition of vehi-
cles without TCS/ABS system.
NOTE:
ABS self-diagnosis sound may be heard. That is a normal condition because a self-diagnosis for “Ignition
switch ON” and “The first starting” are being performed.
For malfunction of EBD, EBD and ABS become inoperative, and the condition of vehicle is the same as the
condition of vehicles without TCS/ABS, EBD system.
VDC/TCS
If VDC/TCS/ABS system malfunction electrically, VDC OFF indicator lamp, SLIP indicator lamp are turned on,
and the condition of vehicle is the same as the condition of vehicles without VDC/TCS control.
CAUTION:
If the Fail-Safe function is activated, then perform self-diagnosis for VDC/TCS/ABS control system.
DTC No. IndexINFOID:0000000003767022
DTC Items (CONSULT screen terms) Reference
C1101 RR RH SENSOR-1
BRC-85, "
DTC Logic"C1102 RR LH SENSOR-1
C1103 FR RH SENSOR-1
C1104 FR LH SENSOR-1
C1105 RR RH SENSOR-2
BRC-88, "
DTC Logic"C1106 RR LH SENSOR-2
C1107 FR RH SENSOR-2
C1108 FR LH SENSOR-2
C1109 BATTERY VOLTAGE [ABNORMAL]BRC-91, "
DTC Logic"
C1110 CONTROLLER FAILUREBRC-93, "DTC Logic"
C 1111 P U M P M O T O RBRC-94, "DTC Logic"
C1115 ABS SENSOR [ABNORMAL SIGNAL]BRC-96, "DTC Logic"
C1116 STOP LAMP SWBRC-99, "DTC Logic"
C1120 FR LH IN ABS SOLBRC-101, "DTC Logic"
C1121 FR LH OUT ABS SOLBRC-103, "DTC Logic"
C1122 FR RH IN ABS SOLBRC-101, "DTC Logic"
C1123 FR RH OUT ABS SOLBRC-103, "DTC Logic"
C1124 RR LH IN ABS SOLBRC-101, "DTC Logic"
C1125 RR LH OUT ABS SOLBRC-103, "DTC Logic"
C1126 RR RH IN ABS SOLBRC-101, "DTC Logic"
C1127 RR RH OUT ABS SOLBRC-103, "DTC Logic"
C1130 ENGINE SIGNAL 1BRC-105, "DTC Logic"
C1140 ACTUATOR RLYBRC-106, "DTC Logic"
C1142 PRESS SEN CIRCUITBRC-108, "DTC Logic"
C1143 ST ANG SEN CIRCUITBRC-110, "DTC Logic"
C1144 ST ANG SEN SIGNALBRC-112, "DTC Logic"
C1145 YAW RATE SENSOR
BRC-113, "DTC Logic"C1146 SIDE G-SEN CIRCUIT
C1153 EMERGENCY BRAKEBRC-93, "
DTC Logic"
C1155 BR FLUID LEVEL LOWBRC-116, "DTC Logic"
C1164 CV 1
BRC-118, "DTC Logic"C1165 CV 2

Page 1082 of 5121

NISSAN TEANA 2008 Service Manual ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-141
< ECU DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
C1166 SV 1
BRC-120, "DTC Logic"C1167 SV 2
C1170 VARIANT CORDINGBRC-93, "
DTC Logic

Page 1083 of 5121

NISSAN TEANA 2008 Service Manual BRC-142
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
SYMPTOM DIAGNOSIS
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
Diagnosis ProcedureINFOID:0000000003767023
1.CHECK ST

Page 1084 of 5121

NISSAN TEANA 2008 Service Manual UNEXPECTED PEDAL REACTION
BRC-143
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
UNEXPECTED PEDAL REACTION
Diagnosis ProcedureINFOID:0000000003767024
1.CHECK BRAKE PEDAL STROKE
Ch

Page 1085 of 5121

NISSAN TEANA 2008 Service Manual BRC-144
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
THE BRAKING DISTANCE IS LONG
THE BRAKING DISTANCE IS LONG
Diagnosis ProcedureINFOID:0000000003767025
CAUTION:
The stopping distance on slippery road surfaces

Page 1086 of 5121

NISSAN TEANA 2008 Service Manual ABS FUNCTION DOES NOT OPERATE
BRC-145
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
ABS FUNCTION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000003767026
CAUTION:
ABS does not

Page 1087 of 5121

NISSAN TEANA 2008 Service Manual BRC-146
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
Diagnosis ProcedureINFOID:0000000003767027
CAUTION:
Under the fol

Page 1088 of 5121

NISSAN TEANA 2008 Service Manual VEHICLE JERKS DURING VDC/TCS/ABS CONTROL
BRC-147
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
VEHICLE JERKS DURING VDC/TCS/ABS CONTROL
Diagnosis ProcedureINFOID:0000000003767028
