2008 NISSAN TEANA Service Manual

spare tire location seat memory airbag disable traction control radiator cap check engine light

Page 1377 of 5121

NISSAN TEANA 2008 Service Manual DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DLK-161
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DRIVER

DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DLK-161
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000003795004
NOTE:
Before performing the diagnosis in the following procedure, check “Work Flow”. Refer to DLK-7, "
Work
Flow".
Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
Intelligent Key is removed from key slot.
Ignition switch is in OFF position.
No Intelligent Keys are inside the vehicle.
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000003795005
1.CHECK REMOTE KEYLESS ENTRY FUNCTION
Check remote keyless entry function.
Does door lock/unlock with Intelligent Key button?
YES >> GO TO 2.
NO >> Go to DLK-158, "
Description".
2.CHECK “LOCK/UNLOCK BY I-KEY” SETTING IN “WORK SUPPORT”
Check “LOCK/UNLOCK BY I-KEY” in “WORK SUPPORT”.
Refer to DLK-43, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “LOCK/UNLOCK BY I-KEY” in “WORK SUPPORT”.
3.CHECK DOOR REQUEST SWITCH
Check door request switch (driver side).
Refer to DLK-72, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK OUTSIDE KEY ANTENNA
Check outside key antenna (driver side).
Refer to DLK-80, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check Intermittent Incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.
PASSENGER SIDE
PASSENGER SIDE : DescriptionINFOID:0000000003795006
NOTE:
Before performing the diagnosis in the following procedure, check “Work Flow”. Refer to DLK-7, "
Work
Flow".

Page 1378 of 5121

NISSAN TEANA 2008 Service Manual DLK-162
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
Check that vehicle is under the condition shown in “Conditions of vehicle” before st

DLK-162
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
Intelligent Key is removed from key slot.
Ignition switch is in the OFF position.
No Intelligent Keys are inside the vehicle.
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000003795007
1.CHECK REMOTE KEYLESS ENTRY FUNCTION
Check remote keyless entry function.
Does door lock/unlock with Intelligent key button?
YES >> GO TO 2.
NO >> Go to DLK-158, "
Description".
2.CHECK “LOCK/UNLOCK BY I-KEY” SETTING IN “WORK SUPPORT”
Check “LOCK/UNLOCK BY I-KEY” in “WORK SUPPORT”.
Refer to DLK-43, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “LOCK/UNLOCK BY I-KEY” in “WORK SUPPORT”.
3.CHECK DOOR REQUEST SWITCH
Check door request switch (passenger side).
Refer to DLK-72, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK OUTSIDE KEY ANTENNA
Check outside key antenna (passenger side).
Refer to DLK-80, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check Intermittent Incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.
TRUNK
TRUNK : DescriptionINFOID:0000000003908231
NOTE:
Before performing the diagnosis in the following table, check “Work Flow”. Refer to DLK-7, "
Work Flow".
Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
Door lock function is normal.
Vehicle speed is less than 5 km/h (3MPH).
All doors are unlocked.

Page 1379 of 5121

NISSAN TEANA 2008 Service Manual DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DLK-163
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK : Diagnosis ProcedureINFOID:0000000003907977
1.CHEC

Page 1380 of 5121

NISSAN TEANA 2008 Service Manual DLK-164
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
TRUNK LID DOES NOT OPEN WITH TRUNK LID OPENER SWITCH
TRUNK LID DOES NOT OPEN WITH TRUNK LID OPENER SWITCH
DescriptionINFOID:0000000003843873

Page 1381 of 5121

NISSAN TEANA 2008 Service Manual TRUNK LID DOES NOT OPEN WITH INTELLIGENT KEY
DLK-165
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK LID DOES NOT OPEN WITH INTELLIGENT KEY
DescriptionINFOID:

Page 1382 of 5121

NISSAN TEANA 2008 Service Manual DLK-166
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
TRUNK LID DOES NOT OPEN WITH TRUNK LID OPENER REQUEST SWITCH
TRUNK LID DOES NOT OPEN WITH TRUNK LID OPENER REQUEST
SWITCH
DescriptionINFOID:0

Page 1383 of 5121

NISSAN TEANA 2008 Service Manual HAZARD AND BUZZER REMINDER DOES NOT OPERATE
DLK-167
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
HAZARD AND BUZZER REMINDER DOES NOT OPERATE
DescriptionINFOID:00

HAZARD AND BUZZER REMINDER DOES NOT OPERATE
DLK-167
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
HAZARD AND BUZZER REMINDER DOES NOT OPERATE
DescriptionINFOID:0000000003795012
NOTE:
Before performing the diagnosis in the following procedure, check “Work Flow”. Refer to DLK-7, "
Work
Flow".
Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
Intelligent Key is removed from key slot.
Ignition switch is in OFF position.
No Intelligent Keys are inside the vehicle.
Diagnosis ProcedureINFOID:0000000003795013
1.CHECK “HAZARD ANSWER BACK” SETTING IN “WORK SUPPORT”
Check “HAZARD ANSWER BACK” setting in “WORK SUPPORT”.
Refer to DLK-42, "
DOOR LOCK : CONSULT-III Function (BCM - DOOR LOCK)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Set “HAZARD ANSWER BACK” in “WORK SUPPORT”.
2.CHECK “ANS BACK I-KEY LOCK” SETTING IN “WORK SUPPORT”
Check “ANS BACK I-KEY LOCK” setting in “WORK SUPPORT”.
Refer to DLK-42, "
DOOR LOCK : CONSULT-III Function (BCM - DOOR LOCK)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “ANS BACK I-KEY LOCK” in “WORK SUPPORT”.
3.CHECK “ANS BACK I-KEY UNLOCK” SETTING IN “WORK SUPPORT”
Check “ANS BACK I-KEY UNLOCK” setting in “WORK SUPPORT”.
Refer to DLK-42, "
DOOR LOCK : CONSULT-III Function (BCM - DOOR LOCK)".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Set “ANS BACK I-KEY UNLOCK” in “WORK SUPPORT”.
4.CHECK HAZARD WARNING LAMP
Check hazard warning lamp.
Refer to DLK-96, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK INTELLIGENT KEY WARNING BUZZER
Check Intelligent Key warning buzzer.
Refer to DLK-82, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.

Page 1384 of 5121

NISSAN TEANA 2008 Service Manual DLK-168
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
KEY REMINDER FUNCTION DOES NOT OPERATE
KEY REMINDER FUNCTION DOES NOT OPERATE
DescriptionINFOID:0000000003795014
NOTE:
Before performing th
