NISSAN TEANA 2008 Service Manual EXL-164
< SYMPTOM DIAGNOSIS >[XENON TYPE]
EXTERIOR LIGHTING SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
EXTERIOR LIGHTING SYSTEM SYMPTOMS
Symptom TableINFOID:0000000003774367
CAUTION:
Perform the self-diagnosis

EXL-164
< SYMPTOM DIAGNOSIS >[XENON TYPE]
EXTERIOR LIGHTING SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
EXTERIOR LIGHTING SYSTEM SYMPTOMS
Symptom TableINFOID:0000000003774367
CAUTION:
Perform the self-diagnosis with CONSULT-III before the symptom diagnosis. Perform the trouble diag-
nosis if any DTC is detected.
Symptom Possible cause Inspection item
Headlamp (HI) is not
turned ON.One sideFuse
Halogen bulb (HI)
Harness between IPDM E/R
and the headlamp high
IPDM E/RHeadlamp (HI) circuit
Refer to EXL-54
.
Both sides
Symptom diagnosis
“BOTH SIDE HEADLAMPS (HI) ARE NOT TURNED ON”
Refer to EXL-168
.
Headlamp (HI) is not
turned OFF.When ignition switch is
turned ON.
When ignition switch is
turned OFF.IPDM E/R —
High beam indicator lamp is not turned ON.
[Headlamp (HI) is turned ON.]Combination meter Combination meter
Data monitor “HI-BEAM IND”
BCM (HEAD LAMP)
Active test “HEADLAMP”
Headlamp (LO) is not
turned ON.One sideFuse
Xenon bulb (LO)
Harness between IPDM E/R
and the front combination lamp
IPDM E/RHeadlamp (LO) circuit
Refer to EXL-56
.
Both sides
Symptom diagnosis
“BOTH SIDE HEADLAMPS (LO) ARE NOT TURNED ON”
Refer to EXL-169
.
Headlamp (LO) is not
turned OFF.When ignition switch is
turned ON.
When ignition switch is
turned OFF.IPDM E/R —
Each lamps are not turned ON/OFF with lighting
switch AUTO. Combination switch
Harness between the combina-
tion switch and BCM
BCMCombination switch
Refer to BCS-76
.
Optical sensor
Harness between the optical
sensor and BCM
BCMOptical sensor circuit
Refer to EXL-69
.
Front fog lamp is not
turned ON.One side Front fog lamp bulb
Harness between IPDM E/R
and the front fog lamp
Front fog lamp
IPDM E/RFront fog lamp circuit
Refer to EXL-62
.
Both sidesSymptom diagnosis
“BOTH SIDE FRONT FOG LAMPS ARE NOT TURNED ON”
Refer to EXL-171
. Front fog lamp is not turned ON.
Front fog lamp indicator is not turned ON.
(Front fog lamp is turned ON.)Combination meter Combination meter
Data monitor “FR FOG IND”
BCM (HEAD LAMP)
Active test “FR FOG LAMP”

Page 2194 of 5121

NISSAN TEANA 2008 Service Manual EXTERIOR LIGHTING SYSTEM SYMPTOMS
EXL-165
< SYMPTOM DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
Parking lamp is not turned ON. Parking lamp bulb
Harness between IPDM E/R
and the front

EXTERIOR LIGHTING SYSTEM SYMPTOMS
EXL-165
< SYMPTOM DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
Parking lamp is not turned ON. Parking lamp bulb
Harness between IPDM E/R
and the front combination lamp
Front combination lamp
IPDM E/RParking lamp circuit
Refer to EXL-64.
Tail lamp is not turned ON. Harness between IPDM E/R
and the rear combination lamp
Rear combination lampTail lamp circuit
Refer to EXL-74
.
License plate lamp is not turned ON. License plate lamp bulb
Harness between IPDM E/R
and the license plate lamp
License plate lampLicense plate lamp circuit
Refer to EXL-76
.
Tail lamp and the license plate lamp are not turned
ON.Fuse
Harness between IPDM E/R
and the rear combination lamp
IPDM E/RLicense plate lamp circuit
Refer to EXL-76
.
Parking lamp, the tail lamp and the license plate
lamp are not turned ON.
Parking lamp, the tail lamp and the license plate
lamp are not turned OFF.
(Each illumination is turned ON/OFF.)Symptom diagnosis
“PARKING, LICENSE PLATE AND TAIL LAMPS ARE NOT TURNED
ON”
Refer to EXL-170
.
Tail lamp indicator is not turned ON.
(Parking, tail lamps are turned ON.)Combination meter Combination meter
Data monitor “LIGHT IND”
BCM (HEAD LAMP)
Active test “TAIL LAMP”
Turn signal lamp does not
blink.Indicator lamp is nor-
mal.
(Applicable side per-
forms the high flasher
activation.) Harness between BCM and
each turn signal lamp
Turn signal lamp bulbTurn signal circuit
Refer to EXL-66
.
Indicator lamp is includ-
ed. Combination switch
Harness between the combina-
tion switch and BCM
BCMCombination switch
Refer to BCS-76
.
Turn signal indicator lamp
does not blink.
(Turn signal indicator
lamp is normal.)One side Combination meter —
Both sides
(Always) Turn signal indicator lamp sig-
nal
-BCM
Combination meter Combination meter
Data monitor “TURN IND”
BCM (FLASHER)
Active test “FLASHER”
Both sides
(Only when activating
hazard warning lamp
with the ignition switch
OFF) Combination meter power sup-
ply and the ground circuit
Combination meterCombination meter
Power supply and the ground circuit
Refer to MWI-42
.
Hazard warning lamp does not activate.
Hazard warning lamp continues activating.
(Turn signal is normal.) Hazard switch
Harness between the hazard
switch and BCM
BCMHazard switch
Refer to EXL-72
.
Rear fog lamp is not
turned ON.Rear fog lamp indicator
lamp is normal. Harness between BCM and the
rear fog lamp
Rear fog lamp bulb
BCMRear fog lamp circuit
Refer to EXL-77
.
Rear fog lamp indicator
lamp is included. Combination switch
Harness between the combina-
tion switch and BCM
BCMCombination switch
Refer to BCS-76
. Symptom Possible cause Inspection item

Page 2195 of 5121

NISSAN TEANA 2008 Service Manual EXL-166
< SYMPTOM DIAGNOSIS >[XENON TYPE]
EXTERIOR LIGHTING SYSTEM SYMPTOMS
Rear fog lamp indicator lamp is not turn ON.
(Rear fog lamp turns ON) Rear fog lamp status signal
-BCM
Combination meter

Page 2196 of 5121

NISSAN TEANA 2008 Service Manual NORMAL OPERATING CONDITION
EXL-167
< SYMPTOM DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000003774368
XENON HEADLAMP
Brightness and the

Page 2197 of 5121

NISSAN TEANA 2008 Service Manual EXL-168
< SYMPTOM DIAGNOSIS >[XENON TYPE]
BOTH SIDE HEADLAMPS (HI) ARE NOT TURNED ON
BOTH SIDE HEADLAMPS (HI) ARE NOT TURNED ON
DescriptionINFOID:0000000003774369
Both side headlamps (HI) are not turn

Page 2198 of 5121

NISSAN TEANA 2008 Service Manual BOTH SIDE HEADLAMPS (LO) ARE NOT TURNED ON
EXL-169
< SYMPTOM DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
BOTH SIDE HEADLAMPS (LO) ARE NOT TURNED ON
DescriptionINFOID:0000000003774371
Both

Page 2199 of 5121

NISSAN TEANA 2008 Service Manual EXL-170
< SYMPTOM DIAGNOSIS >[XENON TYPE]
PARKING, LICENSE PLATE AND TAIL LAMPS ARE NOT TURNED ON
PARKING, LICENSE PLATE AND TAIL LAMPS ARE NOT TURNED ON
DescriptionINFOID:0000000003773608
The parking

Page 2200 of 5121

NISSAN TEANA 2008 Service Manual BOTH SIDE FRONT FOG LAMPS ARE NOT TURNED ON
EXL-171
< SYMPTOM DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
BOTH SIDE FRONT FOG LAMPS ARE NOT TURNED ON
DescriptionINFOID:0000000003773610
Th
