INTAKE MANIFOLD COLLECTOR
2. Remove air cleaner cases (upper and lower) with mass air flow sensor and air duct assembly. Refer to
EM-26, "
Exploded View".
3. Drain engine coolant, or when water hoses are disconnected, attach plug to prevent engine coolant leak-
age. Refer to CO-8, "
Draining".
CAUTION:
Perform this step when the engine is cold.
4. Remove front wiper arm and extension cowl top. Refer to WW-105, "
Exploded View" and EXT-20,
"Exploded View".
5. Disconnect water hoses from electric throttle control actuator.
When engine coolant is not drained from radiator, attach plug to water hoses to prevent engine coolant
leakage.
6. Remove electric throttle control actuator as follows:
a. Disconnect harness connector.
b. Loosen mounting bolts in reverse order as shown in the figure.
CAUTION:
Handle carefully to avoid any shock to electric throttle
control actuator.
Never disassemble.
7. Remove the following parts:
Vacuum hose
PCV hose
High pressure piping from intake manifold collector: Refer to ST-34, "
Exploded View".
Electronic controlled engine mount control solenoid valve
8. Disconnect EVAP hoses and harness connector from EVAP canister purge control solenoid valve.
9. Remove EVAP canister purge control solenoid valve and bracket assembly.
10. Remove VIAS control solenoid valve mounting bolts and vacuum gallery mounting bolts, and then move
vacuum gallery.
Add mating marks as necessary for easier installation.
11. Loosen mounting nuts and bolts in reverse order as shown in
the figure, and remove intake manifold collector and gasket.
CAUTION:
Cover engine openings to avoid entry of foreign materials.
NOTE:
Figure is shown as an example of VQ35DE.
INSTALLATION
Note the following, and install in the reverse order of removal.
Intake Manifold Collector
JPBIA1631ZZ
: Engine front
JPBIA1628ZZ
Page 1906 of 5121
INTAKE MANIFOLD COLLECTOR
EM-31
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Tighten mounting nuts and bolts in numerical order as shown in the
figure.
NOTE:
Figure is shown as an example of VQ35DE.
Electric Throttle Control Actuator
Tighten mounting bolts in numerical order as shown in the figure.
Perform the “Throttle Valve Closed Position Learning” when har-
ness connector of electric throttle control actuator is disconnected.
Refer to EC-16, "
THROTTLE VALVE CLOSED POSITION
LEARNING : Special Repair Requirement".
Perform the “Idle Air Volume Learning” and “Throttle Valve Closed
Position Learning” when electric throttle control actuator is
replaced. Refer to EC-16, "
IDLE AIR VOLUME LEARNING : Spe-
cial Repair Requirement".
: Engine front
JPBIA1628ZZ
JPBIA1631ZZ
Page 1907 of 5121
EM-32
< ON-VEHICLE REPAIR >
INTAKE MANIFOLD
INTAKE MANIFOLD
Exploded ViewINFOID:0000000003802255
Removal and InstallationINFOID:0000000003802256
REMOVAL
1. Release fuel pressure. Refer to EC-411, "Inspection".
2. Remove intake manifold collector. Refer to EM-28, "
Exploded View".
3. Remove fuel tube and fuel injector assembly. Refer to EM-44, "
Exploded View".
4. Loosen mounting nuts and bolts in reverse order as shown in
the figure to remove intake manifold with power tool.
5. Remove gaskets.
CAUTION:
Cover engine openings to avoid entry of foreign materials.
INSTALLATION
Note the following, and install in the reverse order or removal.
Intake Manifold
If stud bolts were removed, install them and tighten to the specified torque below.
1. Intake manifold 2. Gasket
A. Refer to EM-32
Refer to GI-4, "Components" for symbols in the figure.
JPBIA1629GB
: Engine front
JPBIA1630ZZ
: 10.8 N·m (1.1 kg-m, 8 ft-lb)
Page 1908 of 5121
INTAKE MANIFOLD
EM-33
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Tighten all mounting nuts and bolts to the specified torque in two or
more steps in numerical order shown in the figure.
InspectionINFOID:0000000003802257
INSPECTION AFTER REMOVAL
Surface Distortion
Check the surface distortion of the intake manifold mating surface
with a straightedge (A) and a feeler gauge (B).
If it exceeds the limit, replace intake manifold.
: Engine front
1st step: 7.4 N·m (0.75 kg-m, 5 ft-lb)
2nd step and after: 25.5 N·m (2.6 kg-m, 19 ft-lb)
JPBIA1630ZZ
Limit : Refer to EM-136, "Intake Manifold".
JPBIA0015ZZ
Page 1909 of 5121

EM-34
