Page 4201 of 5121

NISSAN TEANA 2008 Service Manual S E C -192
< SYMPTOM DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
SECURITY CONTROL SYSTEM
SYMPTOM DIAGNOSIS
SECURITY CONTROL SYSTEM
Symptom TableINFOID:0000000003815090
The engine start function, door lock fun

S E C -192
< SYMPTOM DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
SECURITY CONTROL SYSTEM
SYMPTOM DIAGNOSIS
SECURITY CONTROL SYSTEM
Symptom TableINFOID:0000000003815090
The engine start function, door lock function, power distribution system and NATS-IVIS/NVIS in the Intelligent
Key system are closely related to each other regarding control. Narrow down the functional area in question
by performing following table to identify which function is malfunctioning. The vehicle security function can
operate only when the door lock and power distribution system are operating normally. Therefore, it is easy to
identify any factor unique to the vehicle security system by performing following table.
Use the chart below to help you find the cause of the symptom. The numbers indicate the order of the inspec-
tion.
NOTE:
Before starting vehicle security system operation check, the following conditions must be met.
Open front windows
Turn ignition switch OFF
Pull out Intelligent Key from key slot.
NO. Function Operation condition Symptom Diagnostic ItemReference
page
1INTELLIGENT
KEY SYSTEM/
DOOR LOCK
FUNCTIONLock/unlock door with door re-
quest switch.
(Intelligent Key is into the out-
side key antenna detection ar-
ea)Door does not lock/unlock —DLK-158
2POWER DIS-
TRIBUTION
FUNCTIONPress push-button ignition
switch under the following con-
dition.
Selector lever position is in
the P or N position.
Do not depress brake pedal.Push-button ignition switch is
not operated—PCS-124
3INTELLIGENT
KEY SYSTEM/
ENGINE START
FUNCTIONStart engine with Intelligent Key
into the vehicle (inside key an-
tenna detection area)Engine can not start with Intel-
ligent Key—SEC-193
4Open the door after ignition
switch is turned ON to OFF.Steering is not locked —SEC-194
5NISSAN VEHI-
CLE IMMOBI-
LIZER
SYSTEM-NATS
FUNCTIONStart engine with Intelligent Key
into the key slot.Engine can not start (Intelli-
gent Key into the key slot)—SEC-195
6Insert Intelligent Key into the
key slot.Key slot indicator does not illu-
minate—SEC-201
7VEHICLE SE-
CURITY SYS-
TEMLock all doors with Intelligent
Key or door request switchVehicle security system can
not be setIntelligent keySEC-197
Door request switchSEC-197
Lock all doors with Intelligent
Key or door request switchSecurity indicator lamp does
not turn ON—SEC-196
In the armed phase, open the
doorVehicle security alarm does
not activate—SEC-199
When alarm sounds, press In-
telligent Key button
Vehicle security system can
not be canceledIntelligent KeySEC-200
When alarm sounds, press door
request switchDoor request switchSEC-200
8POWER DIS-
TRIBUTION
FUNCTIONPress push-button ignition
switch under the following con-
ditions.
Selector lever position is in
the P or N position.
Do not depress brake pedal.Push-button ignition switch
position indicator does not
turn on —PCS-125

Page 4202 of 5121

NISSAN TEANA 2008 Service Manual ENGINE DOES NOT START WHEN INTELLIGENT KEY IS INSIDE OF VEHICLE
SEC-193
< SYMPTOM DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
ENGINE DOES NOT START WHEN INTELLIGENT KEY IS INS

Page 4203 of 5121

NISSAN TEANA 2008 Service Manual SEC-194
< SYMPTOM DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
STEERING DOES NOT LOCK
STEERING DOES NOT LOCK
DescriptionINFOID:0000000003815093
If door switch is malfunctioning, BCM cannot lock the steering. I

Page 4204 of 5121

NISSAN TEANA 2008 Service Manual ENGINE DOES NOT START WHEN INTELLIGENT KEY IS INSERTED INTO KEY
SLOT
SEC-195
< SYMPTOM DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
ENGINE DOES NOT START WHEN INTELLIGENT KEY

Page 4205 of 5121

NISSAN TEANA 2008 Service Manual SEC-196
< SYMPTOM DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
SECURITY INDICATOR LAMP DOES NOT TURN ON OR FLASH
SECURITY INDICATOR LAMP DOES NOT TURN ON OR FLASH
DescriptionINFOID:0000000003815097
Before pe

Page 4206 of 5121

NISSAN TEANA 2008 Service Manual VEHICLE SECURITY SYSTEM CAN NOT BE SET
SEC-197
< SYMPTOM DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
VEHICLE SECURITY SYSTEM CAN NOT BE SET
INTELLIGENT KEY
INTELLIGENT KEY : D

Page 4207 of 5121

NISSAN TEANA 2008 Service Manual SEC-198
< SYMPTOM DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
VEHICLE SECURITY SYSTEM CAN NOT BE SET
2.CHECK TRUNK ROOM LAMP SWITCH
Check trunk lid lock assembly (trunk room lamp switch).
Refer to DLK-57, "
C

Page 4208 of 5121

NISSAN TEANA 2008 Service Manual VEHICLE SECURITY ALARM DOES NOT ACTIVATE
SEC-199
< SYMPTOM DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
VEHICLE SECURITY ALARM DOES NOT ACTIVATE
DescriptionINFOID:0000000003815
