Page 3617 of 5121

NISSAN TEANA 2008 Service Manual PG
STANDARDIZED RELAY
PG-99
< COMPONENT DIAGNOSIS >[POWER SUPPLY&GROUND CIRCUIT]
C
D
E
F
G
H
I
J
K
L B A
O
P N
STANDARDIZED RELAY
DescriptionINFOID:0000000003792683
NORMAL OPEN, NORMAL CLOSED AND MIXE

Page 3618 of 5121

NISSAN TEANA 2008 Service Manual PG-100
< COMPONENT DIAGNOSIS >[POWER SUPPLY&GROUND CIRCUIT]
STANDARDIZED RELAY
SEL188W

Page 3619 of 5121

NISSAN TEANA 2008 Service Manual PG
FUSE BLOCK - JUNCTION BOX (J/B)
PG-101
< COMPONENT DIAGNOSIS >[POWER SUPPLY&GROUND CIRCUIT]
C
D
E
F
G
H
I
J
K
L B A
O
P N
FUSE BLOCK - JUNCTION BOX (J/B)
Fuse, Connector and Terminal ArrangementINF

Page 3620 of 5121

NISSAN TEANA 2008 Service Manual PG-102
< COMPONENT DIAGNOSIS >[POWER SUPPLY&GROUND CIRCUIT]
FUSE, FUSIBLE LINK AND RELAY BOX
FUSE, FUSIBLE LINK AND RELAY BOX
Fuse and Fusible Link ArrangementINFOID:0000000003792685
JCMWM1767GB

Page 3621 of 5121

NISSAN TEANA 2008 Service Manual PG
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
PG-103
< COMPONENT DIAGNOSIS >[POWER SUPPLY&GROUND CIRCUIT]
C
D
E
F
G
H
I
J
K
L B A
O
P N
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODUL

Page 3622 of 5121

NISSAN TEANA 2008 Service Manual PG-104
< PRECAUTION >[POWER SUPPLY&GROUND CIRCUIT]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:000000000384433

Page 3623 of 5121

NISSAN TEANA 2008 Service Manual PG
BATTERY CHARGING CHART
PG-105
< ON-VEHICLE MAINTENANCE >[POWER SUPPLY&GROUND CIRCUIT]
C
D
E
F
G
H
I
J
K
L B A
O
P N
ON-VEHICLE MAINTENANCE
BATTERY CHARGING CHART
Slow ChargeINFOID:0000000003809462

Page 3624 of 5121

NISSAN TEANA 2008 Service Manual PG-106
< ON-VEHICLE MAINTENANCE >[POWER SUPPLY&GROUND CIRCUIT]
BATTERY CHARGING CHART
Set charging current to value specified in “Initial Charging Current Setting (Slow Charge)”. If charger
is n

PG-106
< ON-VEHICLE MAINTENANCE >[POWER SUPPLY&GROUND CIRCUIT]
BATTERY CHARGING CHART
Set charging current to value specified in “Initial Charging Current Setting (Slow Charge)”. If charger
is not capable of producing specified current value, set its charging current as close to that value as
possible.
Keep battery away from open flame while it is being charged.
When connecting charger, connect leads first, then turn on charger. Never turn on charger first, as
this may cause a spark.
If battery temperature rises above 55°C (131°F), stop charging. Always charge battery when its tem-
perature is below 55°C (131°F).
Standard ChargeINFOID:0000000003809463
1.DETERMINE INITIAL CHARGING CURRENT
1. Determine initial charging current from specific gravity.
2. Check battery type and determine the specified current using the table.
NOTE:
After starting charging, adjustment of charging current is not necessary.
Initial Charging Current Setting (Standard Charge)
>> GO TO 2.
2.CHARGE BATTERY
Charge battery for 8 hours.
>> GO TO 3.
3.CHECKING SPECIFIC GRAVITY
Check specific gravity. Refer to PG-3, "
How to Handle Battery".
Is the specific gravity 1.240 or more?
YES >> Complete standard charge. Perform “CAPACITY TEST”. Refer to PG-5, "Work Flow".
NO >> GO TO 4.
4.CONDUCT ADDITIONAL CHARGE
Add charging time depending on specific gravity.
Additional Charge (Standard Charge)
CONVERTED SPECIFIC
GRAVITYBATTERY TYPE
28B19R(L)
34B19R(L)
46B24R(L)
55B24R(L)
50D23R(L)
55D23R(L)
025 [YUASA type code]
027 [YUASA type code]
80D23R(L)
65D26R(L)
80D26R(L)
067 [YUASA type code]
096 [YUASA type code]
75D31R(L)
95D31R(L)
115D31R(L)
110D26R(L)
95E41R(L)
130E41R(L)
1.100 - 1.130 4.0 (A) 5.0 (A) 6.0 (A) 7.0 (A)8.0
(A)9.0 (A)13.0
(A)
1.130 - 1.160 3.0 (A) 4.0 (A) 5.0 (A) 6.0 (A)7.0
(A)8.0 (A)11 . 0
(A)
1.160 - 1.190 2.0 (A) 3.0 (A) 4.0 (A) 5.0 (A)6.0
(A)7.0 (A)9.0
(A)
1.190 - 1.220 2.0 (A) 2.0 (A) 3.0 (A) 4.0 (A)5.0
(A)5.0 (A)7.0
(A)
SPECIFIC GRAVITY CHARGING TIME (h)
Below 1.150 3.5
1.150 - 1.200 2.5
1.200 - 1.240 1.5
