EC-268
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1554 BATTERY CURRENT SENSOR
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-268, "
Diagnosis Procedure"
Diagnosis ProcedureINFOID:0000000003858140
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E38. Refer to Ground Inspection in GI-37, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK BATTERY CURRENT SENSOR POWER SUPPLY CIRCUIT
1. Disconnect battery current sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between battery current sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
3.CHECK BATTERY CURRENT SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between battery current sensor harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK BATTERY CURRENT SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between battery current sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
ECM
Ground Voltage (V)
Connector Terminal
F842
(Battery current
sensor signal)Ground Above 2.3 at least once
Battery current sensor
Ground Voltage (V)
Connector Terminal
F76 1 Ground Approx. 5
Battery current sensor ECM
Continuity
Connector Terminal Connector Terminal
F76 2 F8 44 Existed
Battery current sensor ECM
Continuity
Connector Terminal Connector Terminal
F76 3 F8 42 Existed
Page 1730 of 5121
![NISSAN TEANA 2008 Service Manual P1554 BATTERY CURRENT SENSOR
EC-269
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
5.CHE NISSAN TEANA 2008 Service Manual P1554 BATTERY CURRENT SENSOR
EC-269
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
5.CHE](/manual-img/5/57391/w960_57391-1729.png)
P1554 BATTERY CURRENT SENSOR
EC-269
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
5.CHECK BATTERY CURRENT SENSOR
Refer to EC-269, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace battery negative cable assembly.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000003858141
1.CHECK BATTERY CURRENT SENSOR
1. Turn ignition switch OFF.
2. Reconnect harness connectors disconnected.
3. Disconnect battery negative cable (1).
4. Install jumper cable (A) between battery negative terminal and
body ground.
5. Turn ignition switch ON.
6. Check the voltage between ECM harness connector terminals
under the following conditions.
Before measuring the terminal voltage, confirm that the battery is fully charged. Refer to PG-3, "How to Handle Battery".
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace battery negative cable assembly.
: Vehicle front
: To body ground
ECM
Voltage (V)
Connector+–
Te r m i n a l Te r m i n a l
F842
(Battery current
sensor signal)44
(Sensor ground)Approx. 2.5
ALBIA0076ZZ
Page 1731 of 5121
![NISSAN TEANA 2008 Service Manual EC-270
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1564 ASCD STEERING SWITCH
P1564 ASCD STEERING SWITCH
DescriptionINFOID:0000000003856749
ASCD steering switch has variant values of electrical resistance NISSAN TEANA 2008 Service Manual EC-270
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1564 ASCD STEERING SWITCH
P1564 ASCD STEERING SWITCH
DescriptionINFOID:0000000003856749
ASCD steering switch has variant values of electrical resistance](/manual-img/5/57391/w960_57391-1730.png)
EC-270
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1564 ASCD STEERING SWITCH
P1564 ASCD STEERING SWITCH
DescriptionINFOID:0000000003856749
ASCD steering switch has variant values of electrical resistance for each button. ECM reads voltage variation
of switch, and determines which button is operated.
Refer to EC-51, "
System Diagram" for the ASCD function.
DTC LogicINFOID:0000000003856750
DTC DETECTION LOGIC
NOTE:
If DTC P1564 is displayed with DTC P0605, first perform the trouble diagnosis for DTC P0605. Refer to
EC-240, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait at least 10 seconds.
2. Press MAIN switch for at least 10 seconds, then release it and wait at least 10 seconds.
3. Press CANCEL switch for at least 10 seconds, then release it and wait at least 10 seconds.
4. Press RESUME/ACCELERATE switch for at least 10 seconds, then release it and wait at least 10 sec-
onds.
5. Press SET/COAST switch for at least 10 seconds, then release it and wait at least 10 seconds.
6. Check DTC.
Is DTC detected?
YES >> Go to EC-270, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003856751
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E38. Refer to Ground Inspection in GI-37, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK ASCD STEERING SWITCH CIRCUIT
With CONSULT-III
1. Turn ignition switch ON.
2. Select “MAIN SW”, “CANCEL SW”, “RESUME/ACC SW” and “SET SW” in “DATA MONITOR” mode with
CONSULT-III.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
P1564 ASCD steering switch An excessively high voltage signal from the
ASCD steering switch is sent to ECM.
ECM detects that input signal from the
ASCD steering switch is out of the specified
range.
ECM detects that the ASCD steering switch
is stuck ON. Harness or connectors
(The switch circuit is open or shorted.)
ASCD steering switch
ECM
Page 1732 of 5121
![NISSAN TEANA 2008 Service Manual P1564 ASCD STEERING SWITCH
EC-271
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
3. Check each item indication under the following conditions.
Without CONSULT-III
1. Turn ign NISSAN TEANA 2008 Service Manual P1564 ASCD STEERING SWITCH
EC-271
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
3. Check each item indication under the following conditions.
Without CONSULT-III
1. Turn ign](/manual-img/5/57391/w960_57391-1731.png)
P1564 ASCD STEERING SWITCH
EC-271
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
3. Check each item indication under the following conditions.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals under the following conditions.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 3.
3.CHECK ASCD STEERING SWITCH GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect combination switch harness connector.
4. Check the continuity between combination switch and ECM harness connector.
5. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors M11, E105
Combination switch (spiral cable)
Harness for open and short between ECM and combination switch
>> Repair open circuit, short to ground or short to power in harness or connectors.
5.CHECK ASCD STEERING SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between combination switch and ECM harness connector.
Monitor item Condition Indication
MAIN SW MAIN switchPressed ON
Released OFF
CANCEL SW CANCEL switchPressed ON
Released OFF
RESUME/ACC SWRESUME/ACCEL-
ERATE switchPressed ON
Released OFF
SET SW SET/COAST switchPressed ON
Released OFF
ECM
Condition Voltage (V)
Con-
nector+–
Te r m i n a l Te r m i n a l
E1685
(ASCD steering switch
signal)92
(ASCD steering switch
ground)MAIN switch: Pressed Approx. 0
CANCEL switch: Pressed Approx. 1
SET/COAST switch: Pressed Approx. 2
RESUME/ACCELERATE switch: Pressed Approx. 3
All ASCD steering switches: Released Approx. 4
Combination switch ECM
Continuity
Connector Terminal Connector Terminal
M33 16 E16 92 Existed
Page 1733 of 5121
![NISSAN TEANA 2008 Service Manual EC-272
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1564 ASCD STEERING SWITCH
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
NISSAN TEANA 2008 Service Manual EC-272
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1564 ASCD STEERING SWITCH
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.](/manual-img/5/57391/w960_57391-1732.png)
EC-272
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1564 ASCD STEERING SWITCH
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
6.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors M11, E105
Combination switch (spiral cable)
Harness for open and short between ECM and combination switch
>> Repair open circuit, short to ground or short to power in harness or connectors.
7.CHECK ASCD STEERING SWITCH
Refer to EC-272, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace ASCD steering switch.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>>INSPECTION END
Component InspectionINFOID:0000000003856752
1.CHECK ASCD STEERING SWITCH
1. Turn ignition switch OFF.
2. Disconnect combination switch (spiral cable) harness connector.
3. Check resistance between combination switch harness connector terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace ASCD steering switch
Combination switch ECM
Continuity
Connector Terminal Connector Terminal
M33 13 E16 85 Existed
Combination switch
Condition Resistance [Ω]
Connector Terminals
M33 13 and 16MAIN switch: Pressed Approx. 0
CANCEL switch: Pressed Approx. 250
SET/COAST switch: Pressed Approx. 660
RESUME/ACCELERATE switch: Pressed Approx. 1,480
All ASCD steering switches: Released Approx. 4,000
Page 1734 of 5121
![NISSAN TEANA 2008 Service Manual P1572 ASCD BRAKE SWITCH
EC-273
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1572 ASCD BRAKE SWITCH
DescriptionINFOID:0000000003856753
When the brake pedal is depressed, ASC NISSAN TEANA 2008 Service Manual P1572 ASCD BRAKE SWITCH
EC-273
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1572 ASCD BRAKE SWITCH
DescriptionINFOID:0000000003856753
When the brake pedal is depressed, ASC](/manual-img/5/57391/w960_57391-1733.png)
P1572 ASCD BRAKE SWITCH
EC-273
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1572 ASCD BRAKE SWITCH
DescriptionINFOID:0000000003856753
When the brake pedal is depressed, ASCD brake switch is turned OFF and stop lamp switch is turned ON.
ECM detects the state of the brake pedal by two kinds of input (ON/OFF signal).
Refer to EC-51, "
System Diagram" for the ASCD function.
DTC LogicINFOID:0000000003856754
DTC DETECTION LOGIC
NOTE:
If DTC P1572 is displayed with DTC P0605, first perform the trouble diagnosis for DTC P0605. Refer
to EC-240, "
DTC Logic".
This self-diagnosis has the one trip detection logic. When malfunction A is detected, DTC is not
stored in ECM memory. And in that case, 1st trip DTC and 1st trip freeze frame data are displayed.
1st trip DTC is erased when ignition switch is turned OFF. And even when malfunction A is detected
in two consecutive trips, DTC is not stored in ECM memory.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
NOTE:
Procedure for malfunction B is not described here. It takes extremely long time to complete procedure for mal-
function B. By performing procedure for malfunction A, the incident that causes malfunction B can be
detected.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-III
1. Start engine (VDC switch OFF).
2. Select “DATA MONITOR” mode with CONSULT-III.
3. Press MAIN switch and check that CRUISE lamp illuminates.
4. Drive the vehicle for at least 5 consecutive seconds under the following conditions.
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
This procedure may be conducted with the drive wheels lifted in the shop or by driving the vehicle.
If a road test is expected to be easier, it is unnecessary to lift the vehicle.
5. Check 1st trip DTC.
With GST
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
P1572 ASCD brake switchA)When the vehicle speed is above 30 km/h
(19 MPH), ON signals from the stop lamp
switch and the ASCD brake switch are sent
to the ECM at the same time. Harness or connectors
(The stop lamp switch circuit is shorted.)
Harness or connectors
(The ASCD brake switch circuit is shorted.)
Stop lamp switch
ASCD brake switch
Incorrect stop lamp switch installation
Incorrect ASCD brake switch installation
ECM B)ASCD brake switch signal is not sent to
ECM for extremely long time while the ve-
hicle is being driver.
VHCL SPEED SE More than 30 km/h (19 mph)
Selector lever Suitable position
Page 1735 of 5121
![NISSAN TEANA 2008 Service Manual EC-274
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1572 ASCD BRAKE SWITCH
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Go to EC-274, "Diagnosis Procedure".
NO >> GO NISSAN TEANA 2008 Service Manual EC-274
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1572 ASCD BRAKE SWITCH
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Go to EC-274, "Diagnosis Procedure".
NO >> GO](/manual-img/5/57391/w960_57391-1734.png)
EC-274
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P1572 ASCD BRAKE SWITCH
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Go to EC-274, "Diagnosis Procedure".
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-III
1. Drive the vehicle for at least 5 consecutive seconds under the following conditions.
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
This procedure may be conducted with the drive wheels lifted in the shop or by driving the vehicle.
If a road test is expected to be easier, it is unnecessary to lift the vehicle.
2. Check 1st trip DTC.
With GST
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Go to EC-274, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003856755
1.CHECK OVERALL FUNCTION-I
With CONSULT-III
1. Turn ignition switch ON.
2. Select “BRAKE SW1” in “DATA MONITOR” mode with CONSULT-III.
3. Check “BRAKE SW1” indication under the following conditions.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK OVERALL FUNCTION-II
With CONSULT-III
Check “BRAKE SW2” indication in “DATA MONITOR” mode.
VHCL SPEED SE More than 30 km/h (19 mph)
Selector lever Suitable position
Driving locationDepress the brake pedal for more than 5
seconds so as not to come off from the
above-mentioned vehicle speed.
Monitor item Condition Indication
BRAKE SW1 Brake pedalSlightly depressed OFF
Fully released ON
ECM
Condition Voltage +−
Connector Terminal Connector Terminal
E1611 0
(ASCD brake switch signal)E16 112 Brake pedalSlightly depressed Approx. 0V
Fully released Battery voltage
Page 1736 of 5121
![NISSAN TEANA 2008 Service Manual P1572 ASCD BRAKE SWITCH
EC-275
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Without CONSULT-III
Check the voltage between ECM harness connector and ground.
Is the inspectio NISSAN TEANA 2008 Service Manual P1572 ASCD BRAKE SWITCH
EC-275
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Without CONSULT-III
Check the voltage between ECM harness connector and ground.
Is the inspectio](/manual-img/5/57391/w960_57391-1735.png)
P1572 ASCD BRAKE SWITCH
EC-275
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Without CONSULT-III
Check the voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 12.
NO >> GO TO 7.
3.CHECK ASCD BRAKE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ASCD brake switch harness connector.
3. Turn ignition switch ON.
4. Check the voltage between ASCD brake switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
Fuse block (J/B) connector E103
10A fuse (No.3)
Harness for open or short between ASCD brake switch and fuse
>> Repair open circuit, short to ground or short to power in harness or connectors.
5.CHECK ASCD BRAKE SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between ASCD brake switch harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
6.CHECK ASCD BRAKE SWITCH
Refer to EC-277, "
Component Inspection (ASCD Brake Switch)"
Monitor item Condition Indication
BRAKE SW2 Brake pedalSlightly depressed ON
Fully released OFF
ECM
Condition Voltage +−
Connector Terminal Connector Terminal
E16106
(Stop lamp switch signal)E16 112 Brake pedalSlightly depressed Battery voltage
Fully released Approx. 0V
ASCD brake switch
Ground Voltage
Connector Terminal
E49 1 Ground Battery voltage
ASCD brake switch ECM
Continuity
Connector Terminal Connector Terminal
E49 2 E16 110 Existed
