NISSAN TEANA 2008 Service Manual LAN-54
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
DLC BRANCH LINE CIRCUIT
DLC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841876
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Dis

Page 3122 of 5121

NISSAN TEANA 2008 Service Manual LAN
ABS BRANCH LINE CIRCUIT
LAN-55
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
ABS BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841877
1.CHECK CONNECTOR
1. Tu

Page 3123 of 5121

NISSAN TEANA 2008 Service Manual LAN-56
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
TCM BRANCH LINE CIRCUIT
TCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841878
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Dis

Page 3124 of 5121

NISSAN TEANA 2008 Service Manual LAN
IPDM-E BRANCH LINE CIRCUIT
LAN-57
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
IPDM-E BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841879
1.CHECK CONNECTOR

Page 3125 of 5121

NISSAN TEANA 2008 Service Manual LAN-58
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
CAN COMMUNICATION CIRCUIT
CAN COMMUNICATION CIRCUIT
Diagnosis ProcedureINFOID:0000000003841880
1.CONNECTOR INSPECTION
1. Turn the ignition switch OF

Page 3126 of 5121

NISSAN TEANA 2008 Service Manual LAN
CAN COMMUNICATION CIRCUIT
LAN-59
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
Inspection result
Reproduced>>GO TO 6.
Non-reproduced>>Start the diagnosis again. Follow

Page 3127 of 5121

NISSAN TEANA 2008 Service Manual LAN-60
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 4)]
MAIN LINE BETWEEN DLC AND BCM CIRCUIT
COMPONENT DIAGNOSIS
MAIN LINE BETWEEN
DLC AND BCM CIRCUIT
Diagnosis ProcedureINFOID:0000000004459799
INSPECTI

Page 3128 of 5121

NISSAN TEANA 2008 Service Manual LAN
MAIN LINE BETWEEN BCM AND ABS CIRCUITLAN-61
< COMPONENT DIAGNOSIS > [CAN SYSTEM (TYPE 4)]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN
BCM AND ABS CIRCUIT
Diagnosis ProcedureINFOID:00000000044

LAN
MAIN LINE BETWEEN BCM AND ABS CIRCUITLAN-61
< COMPONENT DIAGNOSIS > [CAN SYSTEM (TYPE 4)]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN
BCM AND ABS CIRCUIT
Diagnosis ProcedureINFOID:0000000004459800
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side
and harness side).
- Harness connector M11
- Harness connector E105
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the following harness connectors.
-BCM
- Harness connectors M11 and E105
2. Check the continuity between the BC M harness connector and the harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the BCM and the harness connector M11.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of ABS actuat or and electric unit (control unit).
2. Check the continuity between the harness connector and the ABS actuator and electric unit (control unit)
harness connector.
- Models with ABS
- Models with VDC
Is the inspection result normal?
YES (Present error)>>Check CA N system type decision again.
YES (Past error)>>Error was detected in the main line between the BCM and the ABS actuator and electric
unit (control unit).
NO >> Repair the main line between the harness connec tor E105 and the ABS actuator and electric unit
(control unit).
BCM harness connector Harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
M122 91
M11 12 Existed
90 11 Existed
Harness connector ABS actuator and electric unit (control unit)
harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
E105 12
E34 26 Existed
11 1 5 E x i s t e d
Harness connector ABS actuator and electric unit (control unit)
harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
E105 12
E36 26 Existed
11 1 5 E x i s t e d
