C1109 POWER AND GROUND SYSTEM
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace damaged parts. (Check ABS earth bolt for tightness and corrosion.)
Special Repair RequirementINFOID:0000000003767330
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform the neutral position adjustment for the steering angle sensor, when replacing the ABS actua-
tor and electric unit (control unit). Refer to BRC-66, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEU-
TRAL POSITION : Description".
>> END
ABS actuator and electric unit (control unit)
— Continuity
Connector Terminal
E361
Ground Existed
4
Page 1034 of 5121
![NISSAN TEANA 2008 Service Manual C1110, C1153, C1170 ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-93
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
C1110, C1153, C1170 ABS ACTUATOR AND ELECTRIC UNIT (CONTR NISSAN TEANA 2008 Service Manual C1110, C1153, C1170 ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-93
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
C1110, C1153, C1170 ABS ACTUATOR AND ELECTRIC UNIT (CONTR](/manual-img/5/57391/w960_57391-1033.png)
C1110, C1153, C1170 ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-93
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
C1110, C1153, C1170 ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)
DTC LogicINFOID:0000000003766916
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C 111 0”, “C1153” or “C1170” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-93, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766917
1.REPLACE ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
CAUTION:
Replace ABS actuator and electric unit (control unit) when self-diagnostic result shows items other
than those applicable.
>> Replace ABS actuator and electric unit (control unit).
Special Repair RequirementINFOID:0000000003767331
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform the neutral position adjustment for the steering angle sensor, when replacing the ABS actua-
tor and electric unit (control unit). Refer to BRC-66, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEU-
TRAL POSITION : Description".
>> END
DTC Display item Malfunction detected condition Possible cause
C1110 CONTROLLER FAILUREWhen there is an internal malfunction in the ABS actuator
and electric unit (control unit).
ABS actuator and electric unit
(control unit) C1153 EMERGENCY BRAKEWhen ABS actuator and electric unit (control unit) is mal-
functioning. (Pressure increase is too much or too little)
C1170 VARIANT CODING In a case where VARIANT CODING is different.
