NISSAN TEANA 2008 Service Manual HEATED SEAT SWITCH
SE-17
< COMPONENT DIAGNOSIS >[WITH VENTILATION SEAT]
C
D
E
F
G
H
I
K
L
MA
B
SE
N
O
P
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace rear ventilation seat control uni

Page 3882 of 5121

NISSAN TEANA 2008 Service Manual SE-18
< COMPONENT DIAGNOSIS >[WITH VENTILATION SEAT]
VENTILATION SEAT SWITCH
VENTILATION SEAT SWITCH
FRONT SEAT
FRONT SEAT : DescriptionINFOID:0000000003825956
Switches the LO or HI air flow of the fr

Page 3883 of 5121

NISSAN TEANA 2008 Service Manual VENTILATION SEAT SWITCH
SE-19
< COMPONENT DIAGNOSIS >[WITH VENTILATION SEAT]
C
D
E
F
G
H
I
K
L
MA
B
SE
N
O
P
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK F

Page 3884 of 5121

NISSAN TEANA 2008 Service Manual SE-20
< COMPONENT DIAGNOSIS >[WITH VENTILATION SEAT]
VENTILATION SEAT SWITCH
FRONT SEAT : Component Inspection
INFOID:0000000003847165
1.CHECK FRONT VENTILATION SEAT SWITCH
1. Turn ignition OFF.
2. Di

Page 3885 of 5121

NISSAN TEANA 2008 Service Manual VENTILATION SEAT SWITCH
SE-21
< COMPONENT DIAGNOSIS >[WITH VENTILATION SEAT]
C
D
E
F
G
H
I
K
L
MA
B
SE
N
O
P
YES >> Rear ventilation seat switch circuit is OK.
NO-1 >> LO or HI mode is NG: GO TO 2.
NO

Page 3886 of 5121

NISSAN TEANA 2008 Service Manual SE-22
< COMPONENT DIAGNOSIS >[WITH VENTILATION SEAT]
VENTILATION SEAT SWITCH
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace rear ventilation seat control unit. Refer to SE-100, "
Disas

Page 3887 of 5121

NISSAN TEANA 2008 Service Manual VENTILATION MOTOR
SE-23
< COMPONENT DIAGNOSIS >[WITH VENTILATION SEAT]
C
D
E
F
G
H
I
K
L
MA
B
SE
N
O
P
VENTILATION MOTOR
FRONT SEAT
FRONT SEAT : DescriptionINFOID:0000000003841898
Sends air flow to th

Page 3888 of 5121

NISSAN TEANA 2008 Service Manual SE-24
< COMPONENT DIAGNOSIS >[WITH VENTILATION SEAT]
VENTILATION MOTOR
YES >> Replace front ventilation seat control unit. Refer to SE-93, "Disassembly and Assembly".
NO >> Repair or replace harness.

SE-24
< COMPONENT DIAGNOSIS >[WITH VENTILATION SEAT]
VENTILATION MOTOR
YES >> Replace front ventilation seat control unit. Refer to SE-93, "Disassembly and Assembly".
NO >> Repair or replace harness.
3.CHECK FRONT VENTILATION MOTOR SPEED CONTROL SIGNAL
1. Check voltage between front ventilation motor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.CHECK FRONT VENTILATION MOTOR SPEED CONTROL SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front ventilation motor connector and front ventilation seat control unit connector.
3. Check continuity between front ventilation motor harness connector and front ventilation seat control unit
harness connector.
4. Check continuity between front ventilation motor harness connector and ground.
Is the inspection result normal?
YES >> Replace front ventilation seat control unit. Refer to SE-93, "Disassembly and Assembly".
NO >> Repair or replace harness.
5.CHECK FRONT VENTILATION MOTOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front ventilation motor connector and front ventilation seat control unit connector.
3. Check continuity between front ventilation motor harness connector and front ventilation seat control unit
harness connector.
4. Check continuity between front ventilation motor harness connector and ground.
(+)
(–) ConditionVoltage (V)
(Approx.) Front ventilation motor
Connector Terminal
Driver side B468
56 GroundVentilation seat LO mode 8
HI mode 10.5
Other than above 0
Passenger side B444 Ventilation seatLO mode 8
HI mode 10.5
Other than above 0
Front ventilation motor Front ventilation seat control unit
Continuity
Connector Terminal Connector Terminal
Driver side B468
56B467
56 Existed
Passenger side B444 B443
Front ventilation motor
GroundContinuity
Connector Terminal
Driver side B468
56 Not existed
Passenger side B444
Front ventilation motor Front ventilation seat control unit
Continuity
Connector Terminal Connector Terminal
Driver side B468
55B467
55 Existed
Passenger side B444 B443
