NISSAN TEANA 2008 Service Manual TM-224
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0720 VEHICLE SPEED SENSOR CVT (SECONDARY SPEED SENSOR)
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK HARNESS BETWEEN TCM AND OUTPUT SPEED

TM-224
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0720 VEHICLE SPEED SENSOR CVT (SECONDARY SPEED SENSOR)
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK HARNESS BETWEEN TCM AND OUTPUT SPEED SENSOR (SECONDARY SPEED SENSOR)
(PART 1)
Check continuity between TCM vehicle side harness connector terminal and output speed sensor (secondary
speed sensor) vehicle side harness connector terminal.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK HARNESS BETWEEN TCM AND OUTPUT SPEED SENSOR (SECONDARY SPEED SENSOR)
(PART 2)
Check continuity between TCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace damaged parts.
6.CHECK HARNESS BETWEEN IPDM E/R AND OUTPUT SPEED SENSOR (SECONDARY SPEED SEN-
SOR) (POWER) (PART 1)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R vehicle side harness connector terminal and output speed sensor
(secondary speed sensor) vehicle side harness connector terminal.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace damaged parts.
7.CHECK HARNESS BETWEEN IPDM E/R AND OUTPUT SPEED SENSOR (SECONDARY SPEED SEN-
SOR) (POWER) (PART 2)
Check continuity between IPDM E/R vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> Check the following.
Harness for short or open between ignition switch and IPDM E/R
10 A fuse (No. 43, located in IPDM E/R)
Ignition switch
NO >> Repair or replace damaged parts.
TCM vehicle side harness connectorOutput speed sensor (secondary speed sensor) ve-
hicle side harness connector
Continuity
Connector Terminal Connector Terminal
F2334F19 2Existed
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F23 34 Not existed
IPDM E/R vehicle side harness connectorOutput speed sensor (secondary speed sensor) ve-
hicle side harness connector
Continuity
Connector Terminal Connector Terminal
F1258F19 3Existed
IPDM E/R vehicle side harness connector
GroundContinuity
Connector Terminal
F12 58 Not existed

Page 4698 of 5121

NISSAN TEANA 2008 Service Manual P0720 VEHICLE SPEED SENSOR CVT (SECONDARY SPEED SENSOR)
TM-225
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
8.CHECK HARNESS BETWEEN TCM AND OUTPUT SPEED SENSOR (SECONDARY SPEE

Page 4699 of 5121

NISSAN TEANA 2008 Service Manual TM-226
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0725 ENGINE SPEED SIGNAL
P0725 ENGINE SPEED SIGNAL
DescriptionINFOID:0000000003806400
The engine speed signal is transmitted from ECM to TCM via CAN commu

TM-226
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0725 ENGINE SPEED SIGNAL
P0725 ENGINE SPEED SIGNAL
DescriptionINFOID:0000000003806400
The engine speed signal is transmitted from ECM to TCM via CAN communication line.
DTC LogicINFOID:0000000003806401
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Start engine and maintain the following conditions for at least 10 consecutive seconds.
Is
“P0725 ENGINE SPEED SIG” detected?
YES >> Go to TM-226, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806402
1. CHECK DTC WITH ECM
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Results” mode for “ENGINE”.
Is any DTC other than
“P0725 ENGINE SPEED SIG” detected?
YES >> Check the DTC detected item. Refer to EC-113, "CONSULT-III Function".
NO >> GO TO 2.
2. CHECK DTC WITH TCM
With CONSULT-III
Select “Self Diagnostic Results” mode for “TRANSMISSION”.
Is any DTC other than
“P0725 ENGINE SPEED SIG” detected?
YES >> Check the DTC detected item. Refer to TM-204, "CONSULT-III Function (TRANSMISSION)".
NO >> GO TO 3.
3. CHECK INPUT SIGNALS
With CONSULT-III
1. Start engine.
2. Select “Data Monitor” mode for “TRANSMISSION”.
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0725 ENGINE SPEED SIG TCM does not receive the
CAN communication signal
from the ECM.
Engine speed is too low while
driving. Harness or connectors
(The ECM to the TCM circuit
is open or shorted.)
PRI SPEED SEN : More than 1000 rpm

Page 4700 of 5121

NISSAN TEANA 2008 Service Manual P0725 ENGINE SPEED SIGNAL
TM-227
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Check for engine speed change corresponding to “ACC PEDAL OPEN” while monitoring “ENG SP

Page 4701 of 5121

NISSAN TEANA 2008 Service Manual TM-228
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0730 BELT DAMAGE
P0730 BELT DAMAGE
DescriptionINFOID:0000000003806403
TCM selects the gear ratio using the engine load (throttle position), the primary pu

TM-228
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0730 BELT DAMAGE
P0730 BELT DAMAGE
DescriptionINFOID:0000000003806403
TCM selects the gear ratio using the engine load (throttle position), the primary pulley revolution speed, and
the secondary pulley revolution speed as input signals. Then it changes the operating pressure of the primary
pulley and the secondary pulley and changes the groove width of the pulley.
DTC LogicINFOID:0000000003806404
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Make sure that output voltage of CVT fluid temperature sensor is within the range specified below.
4. Start engine and maintain the following conditions for at least 30 consecutive seconds.
Is
“P0730 BELT DAMG” detected?
YES >> Go to TM-228, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806405
1.CHECK DTC
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Results” mode for “TRANSMISSION”.
Are any DTC displayed?
YES - 1 (DTC for “P0730 BELT DAMG” is displayed)>>Replace the transaxle assembly. Refer to TM-332,
"Exploded View".
YES - 2 (DTC except for “P0730 BELT DAMG” is displayed)>>Check the DTC detected item. Refer to TM-
204, "CONSULT-III Function (TRANSMISSION)".
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0730 BELT DAMGUnexpected gear ratio is de-
tected.Transaxle assembly
ATF TEMP SEN : 1.0 – 2.0 V
If it is out of range, drive the vehicle to decrease the voltage (warm up the fluid) or stop engine to increase the
voltage (cool down the fluid)
Start test from 0 km/h (0 MPH)
Constant acceleration : Keep 30 sec or more
VEHICLE SPEED : 10 km/h (6 MPH) or more
ACC PEDAL OPEN : More than 1.0/8
RANGE : “D” position
ENG SPEED : 450 rpm or more

Page 4702 of 5121

NISSAN TEANA 2008 Service Manual P0730 BELT DAMAGE
TM-229
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
NO >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".

Page 4703 of 5121

NISSAN TEANA 2008 Service Manual TM-230
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
DescriptionINFOID:0000000003806406
The torque converter clutch

TM-230
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
DescriptionINFOID:0000000003806406
The torque converter clutch solenoid valve is activated by the TCM in response to signals sent from the vehi-
cle speed and accelerator pedal position sensors. Lock-up piston operation will then be controlled.
Lock-up operation, however, is prohibited when CVT fluid temperature is too low.
When the accelerator pedal is depressed (less than 2.0/8) in lock-up condition, the engine speed shall not
change abruptly. If there is a big jump in engine speed, there is no lock-up.
DTC LogicINFOID:0000000003806407
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Wait at least 10 consecutive seconds.
3. Check “Self Diagnostic Results” mode for “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0740 TCC SOLENOID/CIRC” detected?
YES >> Go to TM-230, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806408
1.CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check resistance between TCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN TCM AND CVT UNIT (TORQUE CONVERTER CLUTCH SOLENOID
VA LV E ) ( PA R T 1 )
1. Disconnect CVT unit connector.
2. Check continuity between TCM vehicle side harness connector terminal and CVT unit vehicle side har-
ness connector terminal.
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0740 TCC SOLENOID/CIRCNormal voltage is not applied to
solenoid due to open or short
circuit. Torque converter clutch sole-
noid valve
Harness or connectors
(Solenoid circuit is open or
shorted.)
TCM vehicle side harness connector
GroundResistance (Approx.)
Connector Terminal
F23 38 3.0 – 9.0 Ω

Page 4704 of 5121

NISSAN TEANA 2008 Service Manual P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
TM-231
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damag
