Page 1025 of 5121
BRC-84
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
NOTE:
A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an
operation for checking.
ABS MOTOR Touch “On” and “Off” on screen. Make sure motor relay and actuator relay operates as shown in table below.
NOTE:
A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an
operation for checking.
ECU IDENTIFICATION
ABS actuator and electric unit (control unit) part number can be read.
Test item Display itemDisplay
On Off
ABS MOTORMOTOR RELAY On Off
ACTUATOR RLY (Note) On On
Page 1026 of 5121
![NISSAN TEANA 2008 Service Manual C1101, C1102, C1103, C1104 WHEEL SENSOR
BRC-85
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
COMPONENT DIAGNOSIS
C1101, C1102, C1103, C1104 WHEEL SENSOR
DescriptionINFOID:00000 NISSAN TEANA 2008 Service Manual C1101, C1102, C1103, C1104 WHEEL SENSOR
BRC-85
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
COMPONENT DIAGNOSIS
C1101, C1102, C1103, C1104 WHEEL SENSOR
DescriptionINFOID:00000](/manual-img/5/57391/w960_57391-1025.png)
C1101, C1102, C1103, C1104 WHEEL SENSOR
BRC-85
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
COMPONENT DIAGNOSIS
C1101, C1102, C1103, C1104 WHEEL SENSOR
DescriptionINFOID:0000000003766902
When the sensor rotor rotates, the magnetic field changes. Wheel sensor converts the magnetic field changes
to current signals (rectangular wave) and transmits them to the ABS actuator and electric unit (control unit).
DTC LogicINFOID:0000000003766903
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Start the engine and drive the vehicle at 30 km/h (19 MPH) or more for approximately 1 minute.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1101”, “C1102”, “C1103” or “C1104” detected?
YES >> Proceed to diagnosis. Refer to BRC-85, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766904
CAUTION:
Do not check between wheel sensor terminals.
1.CHECK TIRES
Check air pressure, wear and size. Refer to WT-5, "
Tire Air Pressure".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK SENSOR AND SENSOR ROTOR
Check sensor rotor for damage.
Check wheel sensor for damage, disconnection or looseness.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair wheel sensor mount or replace sensor rotor. Then perform the self-diagnosis.
3.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Disconnect malfunctioning wheel sensor connector.
4. Check terminal to see if it is deformed, disconnected, looseness, etc.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
DTC Display item Malfunction detected condition Possible cause
C1101 RR RH SENSOR-1Circuit of rear RH wheel sensor is open. Or when the sen-
sor power voltage is outside the standard.
Harness or connector
Wheel sensor
ABS actuator and electric unit
(control unit) C1102 RR LH SENSOR-1Circuit of rear LH wheel sensor is open. Or when the sen-
sor power voltage is outside the standard.
C1103 FR RH SENSOR-1Circuit of front RH wheel sensor is open. Or when the
sensor power voltage is outside the standard.
C1104 FR LH SENSOR-1Circuit of front LH wheel sensor is open. Or when the
sensor power voltage is outside the standard.
Page 1027 of 5121
![NISSAN TEANA 2008 Service Manual BRC-86
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1101, C1102, C1103, C1104 WHEEL SENSOR
4.CHECK WHEEL SENSOR HARNESS
1. Check the continuity between ABS actuator and electric unit (control unit) harness c NISSAN TEANA 2008 Service Manual BRC-86
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1101, C1102, C1103, C1104 WHEEL SENSOR
4.CHECK WHEEL SENSOR HARNESS
1. Check the continuity between ABS actuator and electric unit (control unit) harness c](/manual-img/5/57391/w960_57391-1026.png)
BRC-86
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1101, C1102, C1103, C1104 WHEEL SENSOR
4.CHECK WHEEL SENSOR HARNESS
1. Check the continuity between ABS actuator and electric unit (control unit) harness connector and wheel
sensor harness connector. (Also check continuity when steering wheel is turned right and left and when
sensor harness inside the wheel house is moved.)
Measurement terminal for power supply circuit
Measurement terminal for signal circuit
2. Check the continuity between ABS actuator and electric unit (control unit) harness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK WHEEL SENSOR POWER SUPPLY CIRCUIT
1. Connect ABS actuator and electric unit (control unit) connector.
2. Turn the ignition switch ON.
CAUTION:
Never start the engine.
3. Check the voltage between wheel sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace damaged parts.
6.CHECK DATA MONITOR
1. Turn the ignition switch OFF.
2. Connect each wheel sensor connector.
ABS actuator and electric unit (control unit) Wheel sensor
Continuity
Connector Terminal Connector Terminal
E369 E39 (Front RH)
1 Existed 16 E22 (Front LH)
8 C4 (Rear RH)
6 C3 (Rear LH)
ABS actuator and electric unit (control unit) Wheel sensor
Continuity
Connector Terminal Connector Terminal
E3610 E39 (Front RH)
2 Existed 5 E22 (Front LH)
19 C4 (Rear RH)
17 C3 (Rear LH)
ABS actuator and electric unit (control unit)
Continuity
Connector Terminal Connector Terminal
E369, 10
E36 1, 4 Not existed 16, 5
8, 19
6, 17
Wheel sensor
—Voltage
Connector Terminal
E39 (Front RH)
1 Ground 8 V or more E22 (Front LH)
C4 (Rear RH)
C3 (Rear LH)
Page 1028 of 5121
![NISSAN TEANA 2008 Service Manual C1101, C1102, C1103, C1104 WHEEL SENSOR
BRC-87
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
3. Check wheel sensor signal. Refer to BRC-87, "Component Inspection".
Is the inspe NISSAN TEANA 2008 Service Manual C1101, C1102, C1103, C1104 WHEEL SENSOR
BRC-87
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
3. Check wheel sensor signal. Refer to BRC-87, "Component Inspection".
Is the inspe](/manual-img/5/57391/w960_57391-1027.png)
C1101, C1102, C1103, C1104 WHEEL SENSOR
BRC-87
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
3. Check wheel sensor signal. Refer to BRC-87, "Component Inspection".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace damaged parts.
Component InspectionINFOID:0000000003766905
1.CHECK DATA MONITOR
On “DATA MONITOR”, select “FR LH SENSOR”, “FR RH SENSOR”, “RR LH SENSOR”, and “RR RH SEN-
SOR”, and check the vehicle speed.
NOTE:
Confirm tire pressure is normal.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to diagnosis procedure. Refer to BRC-85, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000003766906
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform the neutral position adjustment for the steering angle sensor, when replacing the ABS actua-
tor and electric unit (control unit). Refer to BRC-66, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEU-
TRAL POSITION : Description".
>> END
Wheel sensor Condition Vehicle speed (DATA MONITOR)
FR LH SENSORVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note)Nearly matches the speedometer display
(± 10% or less)
FR RH SENSORVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note)Nearly matches the speedometer display
(± 10% or less)
RR LH SENSORVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note)Nearly matches the speedometer display
(± 10% or less)
RR RH SENSORVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note)Nearly matches the speedometer display
(± 10% or less)
Page 1029 of 5121
![NISSAN TEANA 2008 Service Manual BRC-88
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1105, C1106, C1107, C1108 WHEEL SENSOR
C1105, C1106, C1107, C1108 WHEEL SENSOR
DescriptionINFOID:0000000003767326
When the sensor rotor rotates, the magnet NISSAN TEANA 2008 Service Manual BRC-88
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1105, C1106, C1107, C1108 WHEEL SENSOR
C1105, C1106, C1107, C1108 WHEEL SENSOR
DescriptionINFOID:0000000003767326
When the sensor rotor rotates, the magnet](/manual-img/5/57391/w960_57391-1028.png)
BRC-88
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1105, C1106, C1107, C1108 WHEEL SENSOR
C1105, C1106, C1107, C1108 WHEEL SENSOR
DescriptionINFOID:0000000003767326
When the sensor rotor rotates, the magnetic field changes. Wheel sensor converts the magnetic field changes
to current signals (rectangular wave) and transmits them to the ABS actuator and electric unit (control unit).
DTC LogicINFOID:0000000003766908
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Start the engine and drive the vehicle at 30 km/h (19 MPH) or more for approximately 1 minute.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1105”, “C1106”, “C1107” or “C1108” detected?
YES >> Proceed to diagnosis. Refer to BRC-88, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003767327
CAUTION:
Do not check between wheel sensor terminals.
1.CHECK TIRES
Check air pressure, wear and size. Refer to WT-5, "
Tire Air Pressure".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK SENSOR AND SENSOR ROTOR
Check sensor rotor for damage.
Check wheel sensor for damage, disconnection or looseness.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair wheel sensor mount or replace sensor rotor. Then perform the self-diagnosis.
3.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Disconnect malfunctioning wheel sensor connector.
DTC Display item Malfunction detected condition Possible cause
C1105 RR RH SENSOR-2When the circuit in the rear RH wheel sensor is short-cir-
cuited. Or when the distance between the wheel sensor
and sensor rotor is too large and the sensor pulse cannot
be recognized by the control unit.
Harness or connector
Wheel sensor
ABS actuator and electric unit
(control unit) C1106 RR LH SENSOR-2When the circuit in the rear LH wheel sensor is short-cir-
cuited. Or when the distance between the wheel sensor
and sensor rotor is too large and the sensor pulse cannot
be recognized by the control unit.
C1107 FR RH SENSOR-2When the circuit in the front RH wheel sensor is short-cir-
cuited. Or when the distance between the wheel sensor
and sensor rotor is too large and the sensor pulse cannot
be recognized by the control unit.
C1108 FR LH SENSOR-2When the circuit in the front LH wheel sensor is short-cir-
cuited. Or when the distance between the wheel sensor
and sensor rotor is too large and the sensor pulse cannot
be recognized by the control unit.
Page 1030 of 5121
![NISSAN TEANA 2008 Service Manual C1105, C1106, C1107, C1108 WHEEL SENSOR
BRC-89
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
4. Check terminal to see if it is deformed, disconnected, looseness, etc.
Is the in NISSAN TEANA 2008 Service Manual C1105, C1106, C1107, C1108 WHEEL SENSOR
BRC-89
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
4. Check terminal to see if it is deformed, disconnected, looseness, etc.
Is the in](/manual-img/5/57391/w960_57391-1029.png)
C1105, C1106, C1107, C1108 WHEEL SENSOR
BRC-89
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
4. Check terminal to see if it is deformed, disconnected, looseness, etc.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK WHEEL SENSOR HARNESS
1. Check the continuity between ABS actuator and electric unit (control unit) harness connector and wheel
sensor harness connector. (Also check continuity when steering wheel is turned right and left and when
sensor harness inside the wheel house is moved.)
Measurement terminal for power supply circuit
Measurement terminal for signal circuit
2. Check the continuity between ABS actuator and electric unit (control unit) harness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK WHEEL SENSOR POWER SUPPLY CIRCUIT
1. Connect ABS actuator and electric unit (control unit) connector.
2. Turn the ignition switch ON.
CAUTION:
Never start the engine.
3. Check the voltage between wheel sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
ABS actuator and electric unit (control unit) Wheel sensor
Continuity
Connector Terminal Connector Terminal
E369 E39 (Front RH)
1 Existed 16 E22 (Front LH)
8 C4 (Rear RH)
6 C3 (Rear LH)
ABS actuator and electric unit (control unit) Wheel sensor
Continuity
Connector Terminal Connector Terminal
E3610 E39 (Front RH)
2 Existed 5 E22 (Front LH)
19 C4 (Rear RH)
17 C3 (Rear LH)
ABS actuator and electric unit (control unit)
Continuity
Connector Terminal Connector Terminal
E369, 10
E36 1, 4 Not existed 16, 5
8, 19
6, 17
Wheel sensor
—Voltage
Connector Terminal
E39 (Front RH)
1 Ground 8 V or more E22 (Front LH)
C4 (Rear RH)
C3 (Rear LH)
Page 1031 of 5121
![NISSAN TEANA 2008 Service Manual BRC-90
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1105, C1106, C1107, C1108 WHEEL SENSOR
NO >> Repair or replace damaged parts.
6.CHECK DATA MONITOR
1. Turn the ignition switch OFF.
2. Connect each wheel s NISSAN TEANA 2008 Service Manual BRC-90
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1105, C1106, C1107, C1108 WHEEL SENSOR
NO >> Repair or replace damaged parts.
6.CHECK DATA MONITOR
1. Turn the ignition switch OFF.
2. Connect each wheel s](/manual-img/5/57391/w960_57391-1030.png)
BRC-90
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1105, C1106, C1107, C1108 WHEEL SENSOR
NO >> Repair or replace damaged parts.
6.CHECK DATA MONITOR
1. Turn the ignition switch OFF.
2. Connect each wheel sensor connector.
3. Check wheel sensor signal. Refer to BRC-90, "
Component Inspection".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace damaged parts.
Component InspectionINFOID:0000000003767328
1.CHECK DATA MONITOR
On “DATA MONITOR”, select “FR LH SENSOR”, “FR RH SENSOR”, “RR LH SENSOR”, and “RR RH SEN-
SOR”, and check the vehicle speed.
NOTE:
Confirm tire pressure is normal.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to diagnosis procedure. Refer to BRC-88, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000003767329
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform the neutral position adjustment for the steering angle sensor, when replacing the ABS actua-
tor and electric unit (control unit). Refer to BRC-66, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEU-
TRAL POSITION : Description".
>> END
Wheel sensor Condition Vehicle speed (DATA MONITOR)
FR LH SENSORVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note)Nearly matches the speedometer display
(± 10% or less)
FR RH SENSORVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note)Nearly matches the speedometer display
(± 10% or less)
RR LH SENSORVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note)Nearly matches the speedometer display
(± 10% or less)
RR RH SENSORVehicle stopped 0 [km/h (MPH)]
Vehicle running
(Note)Nearly matches the speedometer display
(± 10% or less)
Page 1032 of 5121
![NISSAN TEANA 2008 Service Manual C1109 POWER AND GROUND SYSTEM
BRC-91
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
C1109 POWER AND GROUND SYSTEM
DescriptionINFOID:0000000003766912
Supplies electric power to t NISSAN TEANA 2008 Service Manual C1109 POWER AND GROUND SYSTEM
BRC-91
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
C1109 POWER AND GROUND SYSTEM
DescriptionINFOID:0000000003766912
Supplies electric power to t](/manual-img/5/57391/w960_57391-1031.png)
C1109 POWER AND GROUND SYSTEM
BRC-91
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
C1109 POWER AND GROUND SYSTEM
DescriptionINFOID:0000000003766912
Supplies electric power to the ABS actuator and electric unit (control unit).
DTC LogicINFOID:0000000003766913
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch OFF to ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1109” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-91, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766914
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check terminal for deformation, disconnection, looseness, etc.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY CIRCUIT
1. Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
2. Check 30A fusible link (G).
3. Check the continuity between ABS actuator and electric unit (control unit) harness connector and battery
positive terminal.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts. (Check ABS earth bolt for tightness and corrosion.)
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Check the continuity between ABS actuator and electric unit (control unit) harness connector and ground.
DTC Display item Malfunction detected condition Possible cause
C1109BATTERY VOLTAGE
[ABNORMAL]When the ABS actuator and electric unit (control unit)
power supply voltage is lower than normal. Harness or connector
ABS actuator and electric unit
(control unit)
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E36 3 Ground Battery voltage
ABS actuator and electric unit (control unit)
—Continuity
Connector Terminal
E36 3Battery positive
terminalExisted
