NISSAN TEANA 2008 Service Manual TM-232
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0744 A/T TCC S/V FUNCTION (LOCK -UP)
P0744 A/T TCC S/V FUNCTION (LOCK -UP)
DescriptionINFOID:0000000003806410
This malfunction is detected when the torque

TM-232
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0744 A/T TCC S/V FUNCTION (LOCK -UP)
P0744 A/T TCC S/V FUNCTION (LOCK -UP)
DescriptionINFOID:0000000003806410
This malfunction is detected when the torque converter clutch does not lock-up as instructed by the TCM. This
is not only caused by electrical malfunctions (circuits open or shorted), but also by mechanical malfunctions
such as control valve sticking, improper solenoid valve operation, etc.
DTC LogicINFOID:0000000003806411
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Start engine and maintain the following condition for at least 30 seconds.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0744 A/T TCC S/V FNCTN” detected?
YES >> Go to TM-232, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806412
1.CHECK LINE PRESSURE
Perform line pressure test. Refer to TM-308, "
Inspection and Judgment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts. Refer to TM-308, "
Inspection and Judgment".
2.CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE
1. Turn ignition switch OFF.
2. Disconnect CVT unit connector.
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0744 A/T TCC S/V FNCTN CVT cannot perform lock-up
even if electrical circuit is
good.
TCM detects as irregular by
comparing reference value
with slip rotation.
There is a big difference be-
tween engine speed and pri-
mary speed sensor when
TCM lock-up signal is on. Torque converter clutch sole-
noid valve
Hydraulic control circuit
ACC PEDAL OPEN : More than 1.0/8
RANGE : “D” position
VEHICLE SPEED : Constant speed of more than 40 km/h (25 MPH)

Page 4706 of 5121

NISSAN TEANA 2008 Service Manual P0744 A/T TCC S/V FUNCTION (LOCK -UP)
TM-233
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Check torque converter clutch solenoid valve. Refer to TM-233, "Component Inspecti

P0744 A/T TCC S/V FUNCTION (LOCK -UP)
TM-233
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Check torque converter clutch solenoid valve. Refer to TM-233, "Component Inspection (Torque Con-
verter Clutch Solenoid Valve)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK LOCK-UP SELECT SOLENOID VALVE
Check lock-up select solenoid valve. Refer to TM-233, "
Component Inspection (Lock-up Select Solenoid
Va l v e )".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK OUTPUT SPEED SENSOR (SECONDARY SPEED SENSOR) SYSTEM
Check output speed sensor (secondary speed sensor) system. Refer to TM-222, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK INPUT SPEED SENSOR (PRIMARY SPEED SENSOR) SYSTEM
Check input speed sensor (primary speed sensor) system. Refer to TM-218, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace damaged parts.
6.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-315, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection (Torque Converter Clutch Solenoid Valve)INFOID:0000000003806413
1.CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE
Check resistance between CVT unit connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace transaxle assembly. Refer to TM-332, "
Exploded View".
Component Inspection (Lock-up Select Solenoid Valve)INFOID:0000000003806414
1.CHECK LOCK-UP SELECT SOLENOID VALVE
Check resistance between CVT unit connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace transaxle assembly. Refer to TM-332, "
Exploded View".
CVT unit connector
GroundResistance (Approx.)
Connector Terminal
F24 12 3.0 – 9.0 Ω
CVT unit connector
GroundResistance (Approx.)
Connector Terminal
F24 13 17.0 – 38.0 Ω
