NISSAN TEANA 2008 Service Manual B2630, B2631 SUNLOAD SENSOR
HAC-53
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
B2630, B2631 SUNLOAD SENSOR
DescriptionINFOID:0000000003846340
COMPONENT DESCRIPTION

B2630, B2631 SUNLOAD SENSOR
HAC-53
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
B2630, B2631 SUNLOAD SENSOR
DescriptionINFOID:0000000003846340
COMPONENT DESCRIPTION
Sunload Sensor
The sunload sensor (1) is located on the driver’s side speaker
grille.
It detects sunload entering through windshield by means of a
photo diode. The sensor converts the sunload into a current value
which is then input into the A/C auto amp.
Sunload Sensor Circuit
SUNLOAD INPUT PROCESS
The A/C auto amp. also equips a processing circuit which averages the variations in detected sunload over a
period of time. This prevents drastic swings in the air temperature control system operation due to small or
quick variations in detected sunload.
For example, consider driving along a road bordered by an occasional group of large trees. The sunload
detected by the sunload sensor varies whenever the trees obstruct the sunlight. The processing circuit aver-
ages the detected sunload over a period of time, so that the (insignificant) effect of the trees momentarily
obstructing the sunlight does not cause any change in the air temperature control system operation. On the
other hand, shortly after entering a long tunnel, the system recognizes the change in sunload, and the system
reacts accordingly.
DTC LogicINFOID:0000000003846341
DTC DETECTION LOGIC
NOTE:
If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
42, "DTC Logic" or HAC-43, "DTC Logic".
Sunload sensor may register a malfunction when indoors, at dusk, or at other times when light is insufficient.
When performing the diagnosis indoors, light the sunload sensor with a lamp (60 W or more).
JPIIA0904ZZ
JPIIA0615GB
DTCItems
(CONSULT-III screen
terms)Diagnostic item is detected when... Possible cause
B2630 SUNLOAD SEN (SHORT)Detected calorie at sunload sensor 64.7 W/m
2
(30 kcal/m2·h) or less Sunload sensor
A/C auto amp.
Harness and connector
(Sunload sensor circuit is open, or
there is a short in the circuit) B2631 SUNLOAD SEN (OPEN)Detected calorie at sunload sensor 2832 W/m
2
(1304 kcal/m2·h) or more

Page 2682 of 5121

NISSAN TEANA 2008 Service Manual HAC-54
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
B2630, B2631 SUNLOAD SENSOR
DTC CONFIRMATION PROCEDURE
1.CHECK WITH SELF-DIAGNOSIS FUNCTION OF CONSULT-III
1. Using CONSULT-III, perform “SELF-

HAC-54
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
B2630, B2631 SUNLOAD SENSOR
DTC CONFIRMATION PROCEDURE
1.CHECK WITH SELF-DIAGNOSIS FUNCTION OF CONSULT-III
1. Using CONSULT-III, perform “SELF-DIAGNOSIS RESULTS” of HVAC.
2. Check if any DTC is displayed in the self-diagnosis results.
NOTE:
If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
42, "DTC Logic" or HAC-43, "DTC Logic".
Sunload sensor may register a malfunction when indoors, at dusk, or at other times when light is insufficient.
When performing the diagnosis indoors, light the sunload sensor with a lamp (60 W or more).
Is DTC
“B2630” or “B2631” displayed?
YES >> Perform trouble diagnosis for the sunload sensor. Refer to HAC-54, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003846342
1.CHECK VOLTAGE BETWEEN SUNLOAD SENSOR AND GROUND
1. Disconnect sunload sensor connector.
2. Turn ignition switch ON.
3. Check voltage between sunload sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK CIRCUIT CONTINUITY BETWEEN SUNLOAD SENSOR AND A/C AUTO AMP.
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between sunload sensor harness connector and A/C auto amp. harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK SUNLOAD SENSOR
1. Reconnect sunload sensor connector and A/C auto amp. connector.
2. Check sunload sensor. Refer to HAC-55, "
Component Inspection".
Is the inspection result normal?
YES >> Replace A/C auto amp.
NO >> Replace sunload sensor.
4.CHECK CIRCUIT CONTINUITY BETWEEN SUNLOAD SENSOR AND A/C AUTO AMP.
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between sunload sensor harness connector and A/C auto amp. harness connector.
(+) (−)
Vol tag e Sunload sensor
—
Connector Terminal
M74 1 Ground Approx. 5 V
Sunload sensor A/C auto amp.
Continuity
Connector Terminal Connector Terminal
M74 2 M50 37 Existed

Page 2683 of 5121

NISSAN TEANA 2008 Service Manual B2630, B2631 SUNLOAD SENSOR
HAC-55
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
4. Check continuity between sunload sensor harness connector and ground.
Is the insp

Page 2684 of 5121

NISSAN TEANA 2008 Service Manual HAC-56
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
B2632, B2633 AIR MIX DOOR MOTOR (DRIVER SIDE)
B2632, B2633 AIR MIX DOOR MOTOR (DRIVER SIDE)
DescriptionINFOID:0000000003846347
COMPONENT DESCRIPT

HAC-56
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
B2632, B2633 AIR MIX DOOR MOTOR (DRIVER SIDE)
B2632, B2633 AIR MIX DOOR MOTOR (DRIVER SIDE)
DescriptionINFOID:0000000003846347
COMPONENT DESCRIPTION
Air Mix Door Motor (Driver Side)
The air mix door motor (driver side) (1) are attached to the heater
& cooling unit assembly.
It rotates so that the air mix door is opened or closed to a position
set by the A/C auto amp.
Motor rotation is then conveyed through a shaft and the air mix
door position feedback is then sent to the A/C auto amp. by PBR
built-in air mix door motor.
DTC LogicINFOID:0000000003846348
DTC DETECTION LOGIC
NOTE:
If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
42, "DTC Logic" or HAC-43, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.CHECK WITH SELF-DIAGNOSIS FUNCTION OF CONSULT-III
1. Using CONSULT-III, perform “SELF-DIAGNOSIS RESULTS” of HVAC.
2. Check if any DTC is displayed in the self-diagnosis results.
NOTE:
If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
42, "DTC Logic" or HAC-43, "DTC Logic".
Is DTC
“B2632” or “B2633” displayed?
YES >> Perform trouble diagnosis for the air mix door motor (driver side). Refer to HAC-57, "Diagnosis
Procedure".
NO >> GO TO 2.
2.FUNCTION INSPECTION
1. Press temperature control “UP” switch (driver side) until 32°C (90°F) is displayed.
2. Check for warm air at discharge air outlets.
3. Operate the compressor.
4. Press temperature control “DOWN” switch (driver side) until 18°C (60°F) is displayed.
5. Check for cool air at air discharge outlets.
Does it operate normally?
YES >> END.
NO >> Check air mix door motor (driver side) installation, and repair or replace the malfunctioning parts.
:Vehicle front
JPIIA0891ZZ
DTCItems
(CONSULT-III screen terms)Diagnostic item is detected when... Possible cause
B2632 DR AIRMIX ACTR (SHORT)Air mix door PBR (driver side) position
5% or less Air mix door motor (driver side)
A/C auto amp.
Harness and connector
(CAN communication line is
open or shorted)
(Air mix door motor is open or
shorted) B2633 DR AIRMIX ACTR (OPEN)Air mix door PBR (driver side) position
95% or more

Page 2685 of 5121

NISSAN TEANA 2008 Service Manual B2632, B2633 AIR MIX DOOR MOTOR (DRIVER SIDE)
HAC-57
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
Diagnosis ProcedureINFOID:0000000003846349
1.CHECK POWER SUPPLY FO

Page 2686 of 5121

NISSAN TEANA 2008 Service Manual HAC-58
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
B2634, B2635 AIR MIX DOOR MOTOR (PASSENGER SIDE)
B2634, B2635 AIR MIX DOOR MOTOR (PASSENGER SIDE)
DescriptionINFOID:0000000003846350
COMPONENT DE

HAC-58
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
B2634, B2635 AIR MIX DOOR MOTOR (PASSENGER SIDE)
B2634, B2635 AIR MIX DOOR MOTOR (PASSENGER SIDE)
DescriptionINFOID:0000000003846350
COMPONENT DESCRIPTION
Air Mix Door Motor (Passenger Side)
The air mix door motor (passenger side) (1) are attached to the
heater & cooling unit assembly.
It rotates so that the air mix door is opened or closed to a position
set by the A/C auto amp.
Motor rotation is then conveyed through a shaft and the air mix
door position feedback is then sent to the A/C auto amp. by PBR
built-in air mix door motor.
DTC LogicINFOID:0000000003846351
DTC DETECTION LOGIC
NOTE:
If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
42, "DTC Logic" or HAC-43, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.CHECK WITH SELF-DIAGNOSIS FUNCTION OF CONSULT-III
1. Using CONSULT-III, perform “SELF-DIAGNOSIS RESULTS” of HVAC.
2. Check if any DTC is displayed in the self-diagnosis results.
NOTE:
If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
42, "DTC Logic" or HAC-43, "DTC Logic".
Is DTC
“B2634” or “B2635” displayed?
YES >> Perform trouble diagnosis for the air mix door motor (passenger side). Refer to HAC-59, "Diagno-
sis Procedure".
NO >> GO TO 2.
2.FUNCTION INSPECTION
1. Press temperature control “UP” switch (passenger side) until 32°C (90°F) is displayed.
2. Check for warm air at discharge air outlets.
3. Operate the compressor.
4. Press temperature control “DOWN” switch (passenger side) until 18°C (60°F) is displayed.
5. Check for cool air at air discharge outlets.
Does it operate normally?
YES >> END.
NO >> Check air mix door motor (passenger side) installation, and repair or replace the malfunctioning
parts.
:Vehicle front
JPIIA0892ZZ
DTCItems
(CONSULT-III screen terms)Diagnostic item is detected when... Possible cause
B2634 PASS AIRMIX ACTR (SHORT)Air mix door PBR (passenger side) position
5% or less Air mix door motor (passenger
side)
A/C auto amp.
Harness and connector
(CAN communication line is open
or shorted)
(Air mix door motor is open or
shorted) B2635 PASS AIRMIX ACTR (OPEN)Air mix door PBR (passenger side) position
95% or more

Page 2687 of 5121

NISSAN TEANA 2008 Service Manual B2634, B2635 AIR MIX DOOR MOTOR (PASSENGER SIDE)
HAC-59
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
Diagnosis ProcedureINFOID:0000000003846352
1.CHECK POWER SUPPLY

Page 2688 of 5121

NISSAN TEANA 2008 Service Manual HAC-60
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
B2636, B2637, B2638, B2639, B2654, B2655 MODE DOOR MOTOR
B2636, B2637, B2638, B2639, B2654, B2655 MODE DOOR MOTOR
DescriptionINFOID:0000000003846

HAC-60
< COMPONENT DIAGNOSIS >[WITHOUT 7 INCH DISPLAY]
B2636, B2637, B2638, B2639, B2654, B2655 MODE DOOR MOTOR
B2636, B2637, B2638, B2639, B2654, B2655 MODE DOOR MOTOR
DescriptionINFOID:0000000003846353
COMPONENT DESCRIPTION
Mode Door Motor
The mode door motor (1) are attached to the heater & cooling unit
assembly.
It rotates so that air is discharged from the outlet set by the A/C
auto amp. Motor rotation is conveyed to a link which activates the
mode door.
DTC LogicINFOID:0000000003846354
DTC DETECTION LOGIC
NOTE:
If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
42, "DTC Logic" or HAC-43, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.CHECK WITH SELF-DIAGNOSIS FUNCTION OF CONSULT-III
1. Using CONSULT-III, perform “SELF-DIAGNOSIS RESULTS” of HVAC.
2. Check if any DTC is displayed in the self-diagnosis results.
NOTE:
If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
42, "DTC Logic" or HAC-43, "DTC Logic".
Is DTC
“ B2636 ”, “ B2637 ”, “B2638 ”, “B2639 ”, “B2654 ” or “B2655 ” displayed?
YES >> Perform trouble diagnosis for the mode door motor. Refer to HAC-61, "Diagnosis Procedure".
NO >> GO TO 2.
2.FUNCTION INSPECTION
1. Press MODE switch and DEF switch.
2. Each position indicator should change shape.
:Vehicle front
JPIIA0893ZZ
DTCItems
(CONSULT-III screen terms)Diagnostic item is detected when... Possible cause
B2636 DR VENT DOOR FAILWhen the malfunctioning door position is
detected at VENT position
Mode door motor
A/C auto amp.
Harness and connector
(CAN communication line is open
or shorted)
(Mode door motor is open or short-
ed) B2637 DR B/L DOOR FAILWhen the malfunctioning door position is
detected at B/L position
B2638 DR D/F1 DOOR FAILWhen the malfunctioning door position is
detected at FOOT position
B2639 DR DEF DOOR FAILWhen the malfunctioning door position is
detected at DEF position
B2654 D/F2 DOOR FAILWhen the malfunctioning door position is
detected at D/F position
B2655 B/L2 DOOR FAILWhen the malfunctioning door position is
detected at B/L2 position

Load next 8 pages

Page: < prev 1-10 ... 2649-2656 2657-2664 2665-2672 2673-2680 2681-2688 2689-2696 2697-2704 2705-2712 2713-2720 ... 5128 next >

CD player headlight bulb automatic transmission service reset brakes alarm
