NISSAN TEANA 2008 Service Manual EC-212
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P0300, P0301, P0302, P0303, P0304, P0305, P0306 MISFIRE
7.CHECK SPARK PLUG
Check the initial spark plug for fouling, etc.
Is the inspection result normal

Page 1674 of 5121

NISSAN TEANA 2008 Service Manual P0300, P0301, P0302, P0303, P0304, P0305, P0306 MISFIRE
EC-213
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
2. Disconnect corresponding A/F sensor 1 harness connector.
3. Di

Page 1675 of 5121

NISSAN TEANA 2008 Service Manual EC-214
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P0300, P0301, P0302, P0303, P0304, P0305, P0306 MISFIRE
18.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END

Page 1676 of 5121

NISSAN TEANA 2008 Service Manual P0327, P0328, P0332, P0333 KS
EC-215
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0327, P0328, P0332, P0333 KS
DescriptionINFOID:0000000003856619
The knock sensor is attach

P0327, P0328, P0332, P0333 KS
EC-215
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0327, P0328, P0332, P0333 KS
DescriptionINFOID:0000000003856619
The knock sensor is attached to the cylinder block. It senses engine knocking using a piezoelectric element. A
knocking vibration from the cylinder block is sensed as vibrational pressure. This pressure is converted into a
voltage signal and sent to the ECM.
DTC LogicINFOID:0000000003856620
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and run it for at least 5 seconds at idle speed.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-215, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003856621
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E38. Refer to Ground Inspection in GI-37, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK KNOCK SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Disconnect knock sensor harness connector and ECM harness connector.
2. Check the continuity between knock sensor harness connector and ECM harness connector.
DTC No.Trouble diagnosis
nameDTC detected condition Possible cause
P0327Knock sensor (bank 1)
circuit low inputAn excessively low voltage from the sensor is
sent to ECM.
Harness or connectors
(The sensor circuit is open or shorted.)
Knock sensor P0328Knock sensor (bank 1)
circuit high inputAn excessively high voltage from the sensor is
sent to ECM.
P0332Knock sensor (bank 2)
circuit low inputAn excessively low voltage from the sensor is
sent to ECM.
P0333Knock sensor (bank 2)
circuit high inputAn excessively high voltage from the sensor is
sent to ECM.

Page 1677 of 5121

NISSAN TEANA 2008 Service Manual EC-216
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P0327, P0328, P0332, P0333 KS
3. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO

Page 1678 of 5121

NISSAN TEANA 2008 Service Manual P0327, P0328, P0332, P0333 KS
EC-217
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
3. Check resistance between knock sensor terminal as per the following.
NOTE:
It is necessa

Page 1679 of 5121

NISSAN TEANA 2008 Service Manual EC-218
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P0335 CKP SENSOR (POS)
P0335 CKP SENSOR (POS)
DescriptionINFOID:0000000003856623
The crankshaft position sensor (POS) is located on the oil pan facing
th

EC-218
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P0335 CKP SENSOR (POS)
P0335 CKP SENSOR (POS)
DescriptionINFOID:0000000003856623
The crankshaft position sensor (POS) is located on the oil pan facing
the gear teeth (cogs) of the signal plate. It detects the fluctuation of
the engine revolution.
The sensor consists of a permanent magnet and Hall IC.
When the engine is running, the high and low parts of the teeth
cause the gap with the sensor to change.
The changing gap causes the magnetic field near the sensor to
change.
Due to the changing magnetic field, the voltage from the sensor
changes.
The ECM receives the voltage signal and detects the fluctuation of
the engine revolution.
ECM receives the signals as shown in the figure.
DTC LogicINFOID:0000000003856624
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10.5 V with igni-
tion switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 5 seconds.
If engine does not start, crank engine for at least 2 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
JMBIA0062ZZ
JMBIA0001GB
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0335Crankshaft position sen-
sor (POS) circuit The crankshaft position sensor (POS) signal
is not detected by the ECM during the first
few seconds of engine cranking.
The proper pulse signal from the crankshaft
position sensor (POS) is not sent to ECM
while the engine is running.
The crankshaft position sensor (POS) signal
is not in the normal pattern during engine run-
ning. Harness or connectors
[CKP sensor (POS) circuit is open or
shorted.]
(APP sensor 2 circuit is shorted.)
(Refrigerant pressure sensor circuit is
shorted.)
Crankshaft position sensor (POS)
Accelerator pedal position sensor
Refrigerant pressure sensor
Signal plate

Page 1680 of 5121

NISSAN TEANA 2008 Service Manual P0335 CKP SENSOR (POS)
EC-219
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
YES >> Go to EC-219, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000
