Page 2377 of 5121
EXL-348
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
OPTICAL SENSOR
OPTICAL SENSOR
Exploded ViewINFOID:0000000003894363
Removal and InstallationINFOID:0000000003894364
REMOVAL
1. Insert an appropriate tool between the optical sensor and the speaker grille (RH). Pull out the optical sen-
sor upward.
2. Disconnect the optical sensor connector. And then remove the optical sensor.
INSTALLATION
Install in the reverse order of removal.
1. Optical sensor
JPLIA1092ZZ
Page 2378 of 5121
LIGHTING & TURN SIGNAL SWITCH
EXL-349
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
LIGHTING & TURN SIGNAL SWITCH
Exploded ViewINFOID:0000000003894365
Removal and InstallationINFOID:0000000003894366
Lighting & turn signal switch is integrated in the combination switch. Refer to BCS-79, "Exploded View".
Page 2379 of 5121
EXL-350
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
HEADLAMP AIMING SWITCH
HEADLAMP AIMING SWITCH
Exploded ViewINFOID:0000000003773632
Removal and InstallationINFOID:0000000003773633
REMOVAL
1. Remove the instrument driver lower panel. Refer to IP-11, "Exploded View".
2. Disengage the pawls. And then remove the headlamp aiming switch.
INSTALLATION
Install in the reverse order of removal.
1. Headlamp aiming switch
A. Pawls
JPLIA1106ZZ
Page 2380 of 5121
HAZARD SWITCH
EXL-351
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
HAZARD SWITCH
Exploded ViewINFOID:0000000003894367
Removal and InstallationINFOID:0000000003894368
REMOVAL
1. Remove the cluster lid D. Refer to IP-11, "Exploded View".
2. Disengage the pawls. And then remove the hazard switch.
INSTALLATION
Install in the reverse order of removal.
1. Hazard switch 2. Cluster lid D
A. Pawls
JPLIA1093ZZ
Page 2381 of 5121
EXL-352
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
SIDE TURN SIGNAL LAMP
SIDE TURN SIGNAL LAMP
Exploded ViewINFOID:0000000003894369
Removal and InstallationINFOID:0000000003894370
CAUTION:
Disconnect battery negative terminal or remove the fuse.
REMOVAL
1. Remove the door mirror glass. Refer to MIR-18, "GLASS MIRROR : Exploded View".
2. Remove the door mirror outer cover. Refer to MIR-19, "
DOOR MIRROR COVER : Exploded View".
3. Remove the door mirror actuator mounting screws (A) and (B).
And then remove the side turn signal lamp mounting screw (C).
4. Remove the door mirror under cover. Refer to MIR-19, "
DOOR MIRROR COVER : Exploded View".
5. Remove the screws (A) and connector (1). And then remove the
side turn signal lamp (2).
INSTALLATION
1. Side turn signal lamp 2. Door mirror under cover
JPLIA1094ZZ
JPLIA1095ZZ
JPLIA1096ZZ
Page 2382 of 5121
SIDE TURN SIGNAL LAMP
EXL-353
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
Install in the reverse order of removal.
Page 2383 of 5121
EXL-354
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
REAR COMBINATION LAMP
REAR COMBINATION LAMP
Exploded ViewINFOID:0000000003894373
REMOVAL
DISASSEMBLY
Removal and InstallationINFOID:0000000003894374
CAUTION:
Disconnect the battery negative terminal or remove the fuse.
REMOVAL
1. Remove the rear combination lamp finisher.
2. Remove the rear combination lamp mounting bolts.
3. Pull the rear combination lamp toward outside of the vehicle. And then remove the rear combination lamp.
4. Disconnect the rear combination lamp connector.
INSTALLATION
Install in the reverse order of removal.
1. Rear combination lamp 2. Rear combination lamp finisher
JPLIA1097ZZ
1. Back-up lamp bulb 2. Back-up lamp bulb socket 3. Rear turn signal lamp bulb socket
4. Rear turn signal lamp bulb
JPLIA1098ZZ
Page 2384 of 5121
![NISSAN TEANA 2008 Service Manual REAR COMBINATION LAMP
EXL-355
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
ReplacementINFOID:0000000003894375
CAUTION:
Disconnect the battery negative terminal or remove the NISSAN TEANA 2008 Service Manual REAR COMBINATION LAMP
EXL-355
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
ReplacementINFOID:0000000003894375
CAUTION:
Disconnect the battery negative terminal or remove the](/manual-img/5/57391/w960_57391-2383.png)
REAR COMBINATION LAMP
EXL-355
< ON-VEHICLE REPAIR >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
ReplacementINFOID:0000000003894375
CAUTION:
Disconnect the battery negative terminal or remove the fuse.
Never touch the glass of bulb directly by hand. Keep grease and other oily matters away from it.
Never touch bulb by hand while it is lit or right after being turned off.
Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bulb, be sure to replace it with new one.
STOP/TAIL LAMP
Replacement integral with rear combination lamp. Refer to EXL-354, "Exploded View".
REAR TURN SIGNAL LAMP BULB
1. Remove the rear combination lamp. Refer to EXL-354, "Exploded View".
2. Rotate the rear turn signal lamp bulb socket counterclockwise, and unlock it.
3. Remove the bulb from the rear turn signal lamp bulb socket.
BACK-UP LAMP BULB
1. Remove the rear combination lamp. Refer to EXL-354, "Exploded View".
2. Rotate the back-up lamp bulb socket counterclockwise, and unlock it.
3. Remove the bulb from the back-up lamp bulb socket.
