NISSAN TEANA 2008 Service Manual RF-94
< ON-VEHICLE REPAIR >
REAR SUNROOF GLASS
REAR SUNROOF GLASS
Exploded ViewINFOID:0000000003812896
Removal and InstallationINFOID:0000000003812897
REMOVAL
1. Remove the roof side finisher. Refer t

Page 3826 of 5121

NISSAN TEANA 2008 Service Manual REAR SUNROOF GLASS
RF-95
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
5. Remove weather-strip.
6. Cut adhesive.
Cut the resin part of the rear sunroof glass rear using cutter
(A).
Pass pi

REAR SUNROOF GLASS
RF-95
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
5. Remove weather-strip.
6. Cut adhesive.
Cut the resin part of the rear sunroof glass rear using cutter
(A).
Pass piano wire though the adhesive with a wire pierce.
Tie both ends of piano wire to wire grip.
Pull piano wire in turn and cut off adhesive.
7. Remove rear sunroof glass from vehicle using suction lifter.
WARNING:
Always use safety glasses and heavy gloves to help prevent glass splinters from entering your eyes
or cutting your hands when cutting the glass from the vehicle.
CAUTION:
Never reuse the rear sunroof glass which has been removed once.
INSTALLATION
WARNING:
Keep heat and open flames away as primers and adhesive are flammable.
The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let
them in contact with the skin and eyes.
Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.
Move immediately to an area with fresh air if affected by vapor inhalation.
CAUTION:
After installing the rear sunroof glass, perform the leak test and check that there is no malfunction.
NOTE:
Use a genuine Nissan Urethane Adhesive Kit (if available) or an equivalent and follow the instructions fur-
nished with it.
Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely
cured (approximately 24 hours). Curing time varies with temperature and humidity.
1. Using a knife or spatula, trim the adhesive (sealant) remaining
on body down to approximately 2 mm thick (a) so that the con-
tour becomes smooth.
CAUTION:
If bonded area on sunroof frame is scratched, always repair
it with 2-component urethane. Never use lacquer.
2. Clean bonded area on glass with white gasoline.
3. Apply glass primer along the entire circumference of glass.
CAUTION:
There are 2 types of primer. Never confuse the application methods.
Paint primer: for painted surfaces
Glass primer: for glass
4. Apply paint primer on areas where adhesive contacts on the side of sunroof frame.
CAUTION:
JMKIA2510ZZ
JMKIA0307ZZ

Page 3827 of 5121

NISSAN TEANA 2008 Service Manual RF-96
< ON-VEHICLE REPAIR >
REAR SUNROOF GLASS
If paint primer adheres to a painted surface other than bonding area, or if it overflows, quickly
remove it with white gasoline.
5. After applying primer

Page 3828 of 5121

NISSAN TEANA 2008 Service Manual WIND DEFLECTOR
RF-97
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
WIND DEFLECTOR
Exploded ViewINFOID:0000000003812898
Removal and InstallationINFOID:0000000003812899
REMOVAL
1. Fully open the

Page 3829 of 5121

NISSAN TEANA 2008 Service Manual RF-98
< ON-VEHICLE REPAIR >
WIND DEFLECTOR
Push and slide the fastener as shown by the arrows (1) and
(2) in the figure to remove.
Remove the screws (A), and then remove wind deflector (1).
INSTAL

Page 3830 of 5121

NISSAN TEANA 2008 Service Manual SUNSHADE
RF-99
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
SUNSHADE
Exploded ViewINFOID:0000000003843880
Removal and InstallationINFOID:0000000003812901
REMOVAL
1. Remove the headlining. Ref

Page 3831 of 5121

NISSAN TEANA 2008 Service Manual RF-100
< ON-VEHICLE REPAIR >
SUNSHADE
Remove it to the lower part while pushing the front sunshade (1)
and rear sunshade (2) towards the direction of the arrow in the
figure.
INSTALLATION
Install in t

Page 3832 of 5121

NISSAN TEANA 2008 Service Manual SUNROOF SWITCH
RF-101
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
SUNROOF SWITCH
Exploded ViewINFOID:0000000003812902
Refer to INT-53, "SUNROOF : Exploded View".
Removal and InstallationINFO
