Page 4209 of 5121

NISSAN TEANA 2008 Service Manual SEC-200
< SYMPTOM DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
VEHICLE SECURITY SYSTEM CAN NOT BE CANCELED
VEHICLE SECURITY SYSTEM CAN NOT BE CANCELED
INTELLIGENT KEY
INTELLIGENT KEY : DescriptionINFOID:000000

Page 4210 of 5121

NISSAN TEANA 2008 Service Manual KEY SLOT INDICATOR DOES NOT ILLUMINATE
SEC-201
< SYMPTOM DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
KEY SLOT INDICATOR DOES NOT ILLUMINATE
DescriptionINFOID:0000000003815113

Page 4211 of 5121

NISSAN TEANA 2008 Service Manual SEC-202
< PRECAUTION >[INTELLIGENT KEY SYSTEM]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003940028
Th

SEC-202
< PRECAUTION >[INTELLIGENT KEY SYSTEM]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003940028
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the “SRS AIRBAG” and
“SEAT BELT” of this Service Manual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIRBAG”.
Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.
Precaution for Procedure without Cowl Top CoverINFOID:0000000003940027
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
Precaution Necessary for Steering Wheel Rotation after Battery Disconnect
INFOID:0000000003940026
NOTE:
Before removing and installing any control units, first turn the push-button ignition switch to the LOCK posi-
tion, then disconnect both battery cables.
After finishing work, confirm that all control unit connectors are connected properly, then re-connect both
battery cables.
Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If a DTC is detected, perform trouble diagnosis according to self-diagnosis results.
This vehicle is equipped with a push-button ignition switch and a steering lock unit.
If the battery is disconnected or discharged, the steering wheel will lock and cannot be turned.
If turning the steering wheel is required with the battery disconnected or discharged, follow the procedure
below before starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Turn the push-button ignition switch to ACC position.
(At this time, the steering lock will be released.)
3. Disconnect both battery cables. The steering lock will remain released with both battery cables discon-
nected and the steering wheel can be turned.
4. Perform the necessary repair operation.
PIIB3706J

Page 4212 of 5121

NISSAN TEANA 2008 Service Manual PRECAUTIONS
SEC-203
< PRECAUTION >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
5. When the repair work is completed, re-connect both battery cables. With the brake pedal released, turn
th

Page 4213 of 5121

NISSAN TEANA 2008 Service Manual SEC-204
< ON-VEHICLE REPAIR >[INTELLIGENT KEY SYSTEM]
KEY SLOT
ON-VEHICLE REPAIR
KEY SLOT
Removal and InstallationINFOID:0000000003815119
REMOVAL
1. Remove the instrument lower panel LH. Refer to IP-1

Page 4214 of 5121

NISSAN TEANA 2008 Service Manual PUSH BUTTON IGNITION SWITCH
SEC-205
< ON-VEHICLE REPAIR >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
PUSH BUTTON IGNITION SWITCH
Removal and InstallationINFOID:0000000003839086
REMOVAL
R

Page 4215 of 5121

NISSAN TEANA 2008 Service Manual SR-1
RESTRAINTS
C
DE
F
G
I
J
K L
M
SECTION SR
A
B
SR
N
O P
CONTENTS
SRS AIRBAG
PRECAUTION ................ ...............................2
PRECAUTIONS .............................................. .

SR-1
RESTRAINTS
C
DE
F
G
I
J
K L
M
SECTION SR
A
B
SR
N
O P
CONTENTS
SRS AIRBAG
PRECAUTION ................ ...............................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect .....................................
2
Service ......................................................................2
Occupant Classification System ..............................3
PREPARATION ............................................4
PREPARATION .............................................. .....4
Special Service Tool ........................................... ......4
Commercial Service Tool ..........................................5
ON-VEHICLE REPAIR ..................................6
DRIVER AIR BAG MODULE .......................... .....6
Exploded View .................................................... ......6
Removal and Installation ...........................................6
SPIRAL CABLE ..................................................9
Exploded View .................................................... ......9
Removal and Installation ...........................................9
FRONT PASSENGER AIR BAG MODULE .......12
Exploded View .................................................... ....12
Removal and Installation ..................................... ....12
SIDE CURTAIN AIR BAG MODULE ................14
Exploded View .........................................................14
Removal and Installation .........................................14
FRONT SIDE AIR BAG MODULE ....................16
Exploded View .........................................................16
Removal and Installation .........................................16
CRASH ZONE SENSOR ...................................18
Exploded View ..................................................... ....18
Removal and Installation .........................................18
SIDE AIR BAG (SATELLITE) SENSOR ...........20
Exploded View .........................................................20
Removal and Installation .........................................20
DIAGNOSIS SENSOR UNIT .............................22
Exploded View .........................................................22
Removal and Installation .........................................22
FRONT SEAT BELT PRE-TENSIONER ...........24
Removal and Installation .........................................24
DISPOSAL OF AIR BAG MODULE AND
SEAT BELT PRE-TENSIONER ........................
25
Caution for Air Bag Module and Seat Belt Pre-ten-
sioner .......................................................................
25

Page 4216 of 5121

NISSAN TEANA 2008 Service Manual SR-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003838497
The Supplemental Restraint Sy

SR-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003838497
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the “SRS AIRBAG” and
“SEAT BELT” of this Service Manual.
WARNING:
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIRBAG”.
Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.
Precaution Necessary for Steering Wheel Rotation after Battery Disconnect
INFOID:0000000003838498
NOTE:
Before removing and installing any control units, first turn the push-button ignition switch to the LOCK posi-
tion, then disconnect both battery cables.
After finishing work, confirm that all control unit connectors are connected properly, then re-connect both
battery cables.
Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If a DTC is detected, perform trouble diagnosis according to self-diagnosis results.
This vehicle is equipped with a push-button ignition switch and a steering lock unit.
If the battery is disconnected or discharged, the steering wheel will lock and cannot be turned.
If turning the steering wheel is required with the battery disconnected or discharged, follow the procedure
below before starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Turn the push-button ignition switch to ACC position.
(At this time, the steering lock will be released.)
3. Disconnect both battery cables. The steering lock will remain released with both battery cables discon-
nected and the steering wheel can be turned.
4. Perform the necessary repair operation.
5. When the repair work is completed, re-connect both battery cables. With the brake pedal released, turn
the push-button ignition switch from ACC position to ON position, then to LOCK position. (The steering
wheel will lock when the push-button ignition switch is turned to LOCK position.)
6. Perform self-diagnosis check of all control units using CONSULT-III.
ServiceINFOID:0000000003751420
Do not use electrical test equipment to check SRS circuits unless instructed to in this Service Manual.
Before servicing the SRS, turn ignition switch OFF, disconnect both battery cables and wait at least 3 min-
utes.
For approximately 3 minutes after the cables are removed, it is still possible for the air bag and seat belt pre-
tensioner to deploy. Therefore, do not work on any SRS connectors or wires until at least 3 minutes have
elapsed.
