POWER SOCKET
POWER SOCKET
Wiring Diagram - POWER SOCKET -INFOID:0000000003792629
JCMWM1669GB
Page 3722 of 5121
PWO
POWER SOCKET
PWO-5
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L B A
O
P N
JCMWM1670GB
Page 3723 of 5121

PWO-6
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003844336
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the “SRS AIRBAG” and
“SEAT BELT” of this Service Manual.
WARNING:
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIRBAG”.
Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.
Page 3724 of 5121
PWO
CIGARETTE LIGHTER
PWO-7
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
L B A
O
P N
ON-VEHICLE REPAIR
CIGARETTE LIGHTER
Exploded ViewINFOID:0000000003792643
Removal and InstallationINFOID:0000000003792644
REMOVAL
1. Remove console ashtray assembly. Refer to IP-22, "Exploded View".
2. Remove the screws (A) from reverse side cigarette lighter
socket (1).
3. Disconnect illumination connector (B) (Models with illumination
connector).
4. Pull out cigarette lighter (1).
5. Pull out cigarette lighter socket (2) by pushing the cigarette
lighter ring pawl (A) from the cigarette lighter socket hole
(square) (B).
6. Remove cigarette lighter ring (3) from console ashtray assembly
while pressing pawls.
INSTALLATION
Install in the reverse order of removal.
NOTE:
Align cigarette lighter socket, cigarette lighter ring and console ashtray assembly cut out.
1 : Cigarette lighter
2 : Cigarette lighter socket
3 : Cigarette lighter ring
JPMIA1024ZZ
JPMIA1028ZZ
C : Cut out
JPMIA1025ZZ
Page 3725 of 5121
PWO-8
< ON-VEHICLE REPAIR >
POWER SOCKET
POWER SOCKET
Exploded ViewINFOID:0000000003792636
Removal and InstallationINFOID:0000000003792637
REMOVAL
1. Remove center console assembly. Refer to IP-22, "Exploded View".
2. Disconnect power socket connector (A).
3. Pull out inner socket (1) by pushing the ring pawl (B) from the
inner socket hole (square) (C).
4. Remove ring (2) from center console assembly while pressing
pawls.
INSTALLATION
Install in the reverse order of removal.
NOTE:
Align inner socket, ring and center console assembly cut out.
1 : Inner socket
2: Ring
JPMIA1026ZZ
D : Cut out
JPMIA1027ZZ
Page 3726 of 5121

RAX-1
TRANSMISSION & DRIVELINE
CEF
G H
I
J
K L
M
SECTION RAX
A
B
RAX
N
O P
CONTENTS
REAR AXLE
SYMPTOM DIAGNOSIS ..... ..........................2
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING ........................ .....
2
NVH Troubleshooting Chart ................................ ......2
ON-VEHICLE MAINTENANCE .....................3
REAR WHEEL HUB AND HOUSING ............ .....3
Inspection ............................................................ ......3
ON-VEHICLE REPAIR ..................................4
REAR WHEEL HUB AND HOUSING ................4
Exploded View ..................................................... .....4
Removal and Installation ..........................................4
Inspection .................................................................5
SERVICE DATA AND SPECIFICATIONS
(SDS) ............... ..............................................
6
SERVICE DATA AND SPECIFICATIONS
(SDS) ..................................................................
6
Wheel Bearing ..................................................... .....6
Page 3727 of 5121
RAX-2
< SYMPTOM DIAGNOSIS >
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooting ChartINFOID:0000000003811096
Use chart below to find the cause of the symptom. If necessary, repair or replace these parts.
×: ApplicableReference page
RAX-4—
RAX-3
NVH in RAX and RSU sections
NVH in WT section
NVH in WT section
NVH in BR section
Possible cause and SUSPECTED PARTS
Improper installation, looseness
Parts interference
Wheel bearing damage
REAR AXLE AND REAR SUSPENSION
TIRE
ROAD WHEEL
BRAKE
Symptom REAR AXLENoise×××××××
Shake×××××××
Vibration×××××
Shimmy×× ××××
Judder×××××
Poor quality ride or handling×× ×××
Page 3728 of 5121
REAR WHEEL HUB AND HOUSING
RAX-3
< ON-VEHICLE MAINTENANCE >
C
E
F
G
H
I
J
K
L
MA
B
RAX
N
O
P
ON-VEHICLE MAINTENANCE
REAR WHEEL HUB AND HOUSING
InspectionINFOID:0000000003811098
MOUNTING INSPECTION
Make sure the mounting conditions (looseness, back lash) of each component and component conditions
(wear, damage) are normal.
WHEEL BEARING INSPECTION
Move wheel hub and bearing assembly in the axial direction by hand. Make sure there is no looseness of
wheel bearing.
Rotate wheel hub, and make sure there is no unusual noise or other irregular conditions. If there is any of
irregular conditions, replace wheel hub and bearing assembly.Standard
Axial end play : Refer to RAX-6, "
Wheel Bearing".
