Page 1513 of 5121
![NISSAN TEANA 2008 Service Manual EC-52
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
Brake pedal is depressed
Selector lever position is N, P or R
Vehicle speed decreased to 13 km/h (8 MPH) lower NISSAN TEANA 2008 Service Manual EC-52
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
Brake pedal is depressed
Selector lever position is N, P or R
Vehicle speed decreased to 13 km/h (8 MPH) lower](/manual-img/5/57391/w960_57391-1512.png)
EC-52
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
Brake pedal is depressed
Selector lever position is N, P or R
Vehicle speed decreased to 13 km/h (8 MPH) lower than the set speed
TCS system is operated
CVT control system has a malfunction. Refer to EC-280, "
Description".
When the ECM detects any of the following conditions, the ECM will cancel the cruise operation and inform
the driver by blinking indicator lamp.
Engine coolant temperature is slightly higher than the normal operating temperature, CRUISE lamp may
blink slowly.
When the engine coolant temperature decreases to the normal operating temperature, CRUISE lamp will
stop blinking and the cruise operation will be able to work by pressing SET/COAST switch or RESUME/
ACCELERATE switch.
Malfunction for some self-diagnoses regarding ASCD control: SET lamp will blink quickly.
If MAIN switch is turned to OFF while ASCD is activated, all of ASCD operations will be canceled and vehicle
speed memory will be erased.
COAST OPERATION
When the SET/COAST switch is pressed during cruise control driving, decrease vehicle set speed until the
switch is released. And then ASCD will maintain the new set speed.
RESUME OPERATION
When the RESUME/ACCELERATE switch is pressed after cancel operation other than pressing MAIN switch
is performed, vehicle speed will return to last set speed. To resume vehicle set speed, vehicle condition must
meet following conditions.
Brake pedal is released
Selector lever position is other than P and N
Vehicle speed is greater than 40 km/h (25 MPH) and less than 144 km/h (89 MPH)
Page 1514 of 5121
![NISSAN TEANA 2008 Service Manual AUTOMATIC SPEED CONTROL DEVICE (ASCD)
EC-53
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Component Parts LocationINFOID:0000000003857774
1. Intake valve timing control soleno NISSAN TEANA 2008 Service Manual AUTOMATIC SPEED CONTROL DEVICE (ASCD)
EC-53
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Component Parts LocationINFOID:0000000003857774
1. Intake valve timing control soleno](/manual-img/5/57391/w960_57391-1513.png)
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
EC-53
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Component Parts LocationINFOID:0000000003857774
1. Intake valve timing control solenoid
valve (bank 1)2. Intake valve timing control solenoid
valve (bank 2)3. Electronic controlled engine mount
control solenoid valve
4. Fuel injector (bank 2) 5. Cooling fan motor-2 6. A/F sensor 1 (bank 2)
7. Ignition coil (with power transistor)
and spark plug (bank 2)8. Camshaft position sensor (PHASE)
(bank 2)9. Crankshaft position sensor (POS)
10. Engine coolant temperature sensor 11. Cooling fan motor-1 12. ECM
13. Refrigerant pressure sensor 14. Battery current sensor 15. IPDM E/R
16. Mass air flow sensor (with intake air
temperature sensor)17. Electric throttle control actuator 18. Power valve actuator 2 (VQ35DE
models)
19. EVAP canister purge volume control
solenoid valve20. Camshaft position sensor (PHASE)
(bank 1)21. Ignition coil (with power transistor)
and spark plug (bank 1)
22. A/F sensor 1 (bank 1) 23. Fuel injector (bank 1) 24. VIAS control solenoid valve 1 and 2
(VQ35DE models)
25. Power valve actuator 1
JMBIA1373ZZ
Page 1515 of 5121
EC-54
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
1. Mass air flow sensor (with intake air
temperature sensor)2. Electric throttle control actuator
: Vehicle front
1. Ignition coil (with power transistor)
and spark plug (bank 1)2. Fuel injector (bank 1) 3. Fuel injector (bank 2)
4. Ignition coil (with power transistor)
and spark plug (bank 2)5. EVAP canister
: Vehicle front
1. Knock sensor (bank 1) 2. Knock sensor (bank 2) 3. Knock sensor
: Vehicle front
JMBIA1374ZZ
JMBIA1375ZZ
JMBIA1376GB
JMBIA1377ZZ
Page 1516 of 5121
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
EC-55
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. Crankshaft position sensor (POS) 2. Camshaft position sensor (PHASE)
(bank 2)3. Camshaft position sensor (PHASE)
(bank 1)
: Vehicle front
1. Refrigerant pressure sensor 2. Battery current sensor
: Vehicle front
1. ECM 2. Fuel pump fuse 3. IPDM E/R
: Vehicle front
JMBIA1378ZZ
JMBIA1379ZZ
PBIB1686E
Page 1517 of 5121
EC-56
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
1. A/F sensor 1 (bank 1) harness con-
nector2. A/F sensor 1 (bank 1) 3. A/F sensor 1 (bank 2) harness con-
nector
4. A/F sensor 1 (bank 2)
: Vehicle front
1. HO2S2 (bank 1) 2. HO2S2 (bank 2) 3. HO2S2 (bank 2) harness connector
4. Tie-rod (RH) 5. Power steering pressure sensor 6. HO2S2 (bank 1) harness connector
: Vehicle front
1. Electronic controlled engine mount
control solenoid valve2. VIAS control solenoid valve 1 3. VIAS control solenoid valve 2
4. EVAP canister purge volume control
solenoid valve
JMBIA1116ZZ
JMBIA1380ZZ
JMBIA1381GB
Page 1518 of 5121
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
EC-57
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. Electronic controlled engine mount
control solenoid valve2. VIAS control solenoid valve 3. EVAP canister purge volume control
solenoid valve
1. Intake valve timing control solenoid
valve (bank 1)2. Intake valve timing control solenoid
valve (bank 2)3. Data link connector
1. Stop lamp switch 2. ASCD brake switch 3. Accelerator pedal position sensor
1. ASCD steering switch 2. CANCEL switch 3. RESUME/ACCELERATE switch
4. SET/COAST switch 5. MAIN switch
JMBIA1382GB
JMBIA1383ZZ
JMBIA1384ZZ
JMBIA1120ZZ
Page 1519 of 5121
EC-58
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
Component Description
INFOID:0000000003856480
1. Fuel level sensor unit and fuel pump
harness connector2. Fuel pressure regulator 3. Fuel level sensor unit and fuel pump
: Vehicle front
JMBIA1385ZZ
Component Reference
ASCD steering switchEC-270, "
Description"
ASCD brake switchEC-273, "Description"
ASCD clutch switchEC-273, "Description"
Stop lamp switchEC-291, "Description"
Electric throttle control actuatorEC-302, "Description"
ASCD indicatorEC-323, "Description"
Page 1520 of 5121
CAN COMMUNICATION
EC-59
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
CAN COMMUNICATION
System DescriptionINFOID:0000000003856481
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
Refer to LAN-22, "
CAN System Specification Chart", about CAN communication for detail.
