Page 4097 of 5121
SEC-88
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2612 STEERING STATUS
3. Check continuity between steering lock unit harness connector and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-34, "Removal and Installation".
NO >> Repair or replace harness.
Steering lock unit
GroundContinuity
Connector Terminal
M12 3 Not existed
Page 4098 of 5121
![NISSAN TEANA 2008 Service Manual B2617 STARTER RELAY CIRCUIT
SEC-89
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2617 STARTER RELAY CIRCUIT
DescriptionINFOID:0000000003815026
Located in IPDM E/R, NISSAN TEANA 2008 Service Manual B2617 STARTER RELAY CIRCUIT
SEC-89
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2617 STARTER RELAY CIRCUIT
DescriptionINFOID:0000000003815026
Located in IPDM E/R,](/manual-img/5/57391/w960_57391-4097.png)
B2617 STARTER RELAY CIRCUIT
SEC-89
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2617 STARTER RELAY CIRCUIT
DescriptionINFOID:0000000003815026
Located in IPDM E/R, it runs the starter motor. The starter relay is turned ON by the BCM when the ignition
switch is in the START position. IPDM E/R transmits the starter relay ON signal to BCM via CAN communica-
tion.
DTC LogicINFOID:0000000003815027
DTC DETECTION LOGIC
NOTE:
If DTC B2617 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
If DTC B2617 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
If DTC B2617 is displayed with DTC B2611, first perform the trouble diagnosis for DTC B2611. Refer to
SEC-89, "
DTC Logic".
If DTC B2617 is displayed with DTC B210E for IPDM E/R, first perform the trouble diagnosis for DTC
B210E. Refer to SEC-105, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions and wait for at least 1 second.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-89, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003815028
1.CHECK STARTER RELAY
1. Turn ignition switch ON.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK STARTER RELAY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector and IPDM E/R connector.
3. Check continuity between IPDM E/R harness connector and BCM harness connector.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2617STARTER RELAY
CIRCUITAn immediate operation of starter relay is request-
ed by BCM, but there is no response for more than
1 second Harness or connectors
(Starter relay circuit is open or short-
ed)
IPDM E/R
(+)
(–) ConditionVoltage (V)
(Approx.) BCM
Connector Terminal
M121 52 Ground Selector leverN or P position Battery voltage
Other than above 0
Page 4099 of 5121
SEC-90
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2617 STARTER RELAY CIRCUIT
4. Check continuity between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-34, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
IPDM E/R BCM
Continuity
Connector Terminal Connector Terminal
E11 46 M121 52 Existed
IPDM E/R
GroundContinuity
Connector Terminal
E11 46 Not existed
Page 4100 of 5121
![NISSAN TEANA 2008 Service Manual B2619 BCM
SEC-91
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2619 BCM
DescriptionINFOID:0000000003815029
BCM requests IPDM E/R to supply power to steering lock un NISSAN TEANA 2008 Service Manual B2619 BCM
SEC-91
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2619 BCM
DescriptionINFOID:0000000003815029
BCM requests IPDM E/R to supply power to steering lock un](/manual-img/5/57391/w960_57391-4099.png)
B2619 BCM
SEC-91
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2619 BCM
DescriptionINFOID:0000000003815029
BCM requests IPDM E/R to supply power to steering lock unit. After receiving the power, the steering lock unit
transmits an ON signal to BCM.
DTC LogicINFOID:0000000003815030
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Press the push-button ignition switch under the following conditions and wait for at least 1 second.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-91, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003815031
1.INSPECTION START
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
3. Touch “ERASE”.
4.Perform DTC Confirmation Procedure.
See SEC-91, "
DTC Logic".
Is the DTC B2619 displayed again?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B2619 BCMBCM detects a mismatch between the power supplied to the
steering lock unit and the feedback for one second or more.BCM
Page 4101 of 5121
![NISSAN TEANA 2008 Service Manual SEC-92
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B261A PUSH-BUTTON IGNITION SWITCH
B261A PUSH-BUTTON IGNITION SWITCH
DescriptionINFOID:0000000003815032
BCM transmits the change in the power supp NISSAN TEANA 2008 Service Manual SEC-92
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B261A PUSH-BUTTON IGNITION SWITCH
B261A PUSH-BUTTON IGNITION SWITCH
DescriptionINFOID:0000000003815032
BCM transmits the change in the power supp](/manual-img/5/57391/w960_57391-4100.png)
SEC-92
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B261A PUSH-BUTTON IGNITION SWITCH
B261A PUSH-BUTTON IGNITION SWITCH
DescriptionINFOID:0000000003815032
BCM transmits the change in the power supply position with the push-button ignition switch to IPDM E/R via
CAN communication. IPDM E/R transmits the power supply position status via CAN communication to BCM.
DTC LogicINFOID:0000000003815033
DTC DETECTION LOGIC
NOTE:
If DTC B261A is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
If DTC B261A is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE 1
1. Press push-button ignition switch for 1 second under the following condition.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-92, "Diagnosis Procedure"
NO >> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE 2
1. Insert Intelligent Key into the key slot.
2. Press the push-button ignition switch under the following conditions and wait for at least 1 second.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
3. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-92, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003815034
1.INSPECTION START
Check the case in which DTC is detected.
Case1: It is detected when push-button ignition switch is pressed for 1 second
Case2: It is detected after Intelligent Key is inserted into key slot and push-button ignition switch is pressed
In which case is DTC detected?
Case1 >> GO TO 2.
Case2 >> GO TO 4.
2.CHECK PUSH-BUTTON IGNITION SWITCH OUTPUT SIGNAL 1
1. Turn ignition switch OFF.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B261APUSH-BUTTON
IGNITION
SWITCHBCM detects the difference between the following for
1 second or more
Power supply position with push-button ignition
switch
Power supply position from IPDM E/R (CAN) Harness or connectors
(Push-button ignition switch circuit is
open or shorted)
Between BCM and push-button igni-
tion switch
Between IPDM E/R and push-button
ignition switch
Page 4102 of 5121
![NISSAN TEANA 2008 Service Manual B261A PUSH-BUTTON IGNITION SWITCH
SEC-93
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
2. Disconnect push-button ignition switch connector and IPDM E/R connector.
3. NISSAN TEANA 2008 Service Manual B261A PUSH-BUTTON IGNITION SWITCH
SEC-93
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
2. Disconnect push-button ignition switch connector and IPDM E/R connector.
3.](/manual-img/5/57391/w960_57391-4101.png)
B261A PUSH-BUTTON IGNITION SWITCH
SEC-93
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
2. Disconnect push-button ignition switch connector and IPDM E/R connector.
3. Check voltage between push-button ignition switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 3.
3.CHECK PUSH-BUTTON IGNITION SWITCH CIRCUIT 1
1. Disconnect BCM connector.
2. Check continuity between push-button ignition switch harness connector and BCM harness connector.
3. Check continuity between push-button ignition switch harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
4.CHECK PUSH-BUTTON IGNITION SWITCH OUTPUT SIGNAL 2
1. Turn ignition switch OFF.
2. Disconnect push-button ignition switch connector and BCM connector.
3. Check voltage between push-button ignition switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.CHECK PUSH-BUTTON IGNITION SWITCH CIRCUIT 2
1. Disconnect IPDM E/R connector.
2. Check continuity between push-button ignition switch harness connector and IPDM E/R harness connec-
tor.
3. Check continuity between push-button ignition switch harness connector and ground.
(+)
(–)Voltage (V)
(Approx.) Push-button ignition switch
Connector Terminal
M101 4 Ground Battery voltage
Push-button ignition switch BCM
Continuity
Connector Terminal Connector Terminal
M101 4 M122 89 Existed
Push-button ignition switch
GroundContinuity
Connector Terminal
M101 4 Not existed
(+)
(–)Voltage (V)
(Approx.) Push-button ignition switch
Connector Terminal
M101 4 Ground Battery voltage
Push-button ignition switch IPDM E/R
Continuity
Connector Terminal Connector Terminal
M101 4 E10 28 Existed
Push-button ignition switch
GroundContinuity
Connector Terminal
M101 4 Not existed
Page 4103 of 5121
SEC-94
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B261A PUSH-BUTTON IGNITION SWITCH
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-34, "Removal and Installation".
NO >> Repair or replace harness.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
Page 4104 of 5121
![NISSAN TEANA 2008 Service Manual B261E VEHICLE TYPE
SEC-95
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B261E VEHICLE TYPE
DescriptionINFOID:0000000003815035
There are two types of vehicles.
HEV
NISSAN TEANA 2008 Service Manual B261E VEHICLE TYPE
SEC-95
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B261E VEHICLE TYPE
DescriptionINFOID:0000000003815035
There are two types of vehicles.
HEV](/manual-img/5/57391/w960_57391-4103.png)
B261E VEHICLE TYPE
SEC-95
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B261E VEHICLE TYPE
DescriptionINFOID:0000000003815035
There are two types of vehicles.
HEV
Conventional
DTC LogicINFOID:0000000003815036
DTC DETECTION LOGIC
NOTE:
If DTC B261E is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
If DTC B261E is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-95, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003815037
1.INSPECTION START
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
3. Touch “ERASE”.
4.Perform DTC Confirmation Procedure.
See SEC-95, "
DTC Logic".
Is the 1st trip DTC B261E displayed again?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B261E VEHICLE TYPE Difference of BCM configuration BCM
