NISSAN TEANA 2008 Service Manual TM-40
< FUNCTION DIAGNOSIS >[CVT: RE0F09B]
DIAGNOSIS SYSTEM (TCM)
Diagnostic Tool Function
INFOID:0000000003848945
OBD SELF-DIAGNOSTIC PROCEDURE
Refer to EC-122, "DiagnosisToolFunction".
LUSEL SOL MON

Page 4514 of 5121

NISSAN TEANA 2008 Service Manual U1000 CAN COMM CIRCUIT
TM-41
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000003848946
CAN (Controller Area Ne

U1000 CAN COMM CIRCUIT
TM-41
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000003848946
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent malfunction detection ability.
Many electronic control units are equipped onto a vehicle, and each control unit shares information and links
with other control units during operation (not independent). In CAN communication, control units are con-
nected with 2 communication lines (CAN-H and CAN-L) allowing a high rate of information transmission with
less wiring. Each control unit transmits/receives data but selectively reads required data only.
DTC LogicINFOID:0000000003848947
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
NOTE:
Immediately after performing any “DTC CONFIRMATION PROCEDURE”, always turn ignition switch OFF.
Then wait at least 10 seconds before performing the next test.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Start engine and wait for at least 6 seconds.
3. Perform “Self-Diagnostic Results” mode for “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“U1000 CAN COMM CIRCUIT” detected?
YES >> Go to TM-41, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003848948
1.CHECK CAN COMMUNICATION CIRCUIT
With CONSULT-III
1. Turn ignition switch ON and start engine.
2. Perform “Self-Diagnostic Results” mode for “TRANSMISSION”.
Is
“U1000 CAN COMM CIRCUIT” indicated?
YES >> Go to LAN section. Refer to LAN-22, "CAN System Specification Chart".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
U1000 CAN COMM CIRCUITWhen TCM is not transmitting or receiving
CAN communication signal for 2 seconds or
more.Harness or connectors
(CAN communication line is open or short-
ed.)

Page 4515 of 5121

NISSAN TEANA 2008 Service Manual TM-42
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P0615 START SIGNAL
P0615 START SIGNAL
DescriptionINFOID:0000000003848949
TCM controls starter relay in IPDM E/R.
TCM switches starter relay ON at “P�

TM-42
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P0615 START SIGNAL
P0615 START SIGNAL
DescriptionINFOID:0000000003848949
TCM controls starter relay in IPDM E/R.
TCM switches starter relay ON at “P” or “N” position and allows to crank engine.
Then it prohibits cranking other than at “P” or “N” position.
DTC LogicINFOID:0000000003848950
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
Immediately after performing any “DTC CONFIRMATION PROCEDURE”, always turn ignition switch OFF.
Then wait at least 10 seconds before performing the next test.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self-Diagnostic Results” mode for “TRANSMISSION”.
Is
“P0615 STARTER RELAY/CIRC” detected?
YES >> Go to TM-42, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003848951
1.CHECK STARTER RELAY SIGNAL
1. Turn ignition switch ON.
2. Disconnect IPDM E/R harness connector.
3. Check voltage between IPDM E/R vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> Check starter relay and starter control relay. Refer to STR-10, "Wiring Diagram - STARTING SYS-
TEM -".
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN TCM AND IPDM E/R (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM vehicle side harness connector terminal and IPDM E/R vehicle side har-
ness connector terminal.
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0615 STARTER RELAY/CIRCIf this signal is ON other than in “P” or “N” po-
sition, this is judged to be a malfunction.
(And if it is OFF in “P” or “N” position, this too
is judged to be a malfunction.) Harness or connectors
(Starter relay and TCM circuit is open or
shorted.)
Starter relay circuit
IPDM E/R vehicle side harness connector
GroundCondition Voltage (Approx.)
Connector Terminal
F12 72Selector lever in “P” and “N” positions Battery voltage
Selector lever in other positions 0 V

Page 4516 of 5121

NISSAN TEANA 2008 Service Manual P0615 START SIGNAL
TM-43
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK HARNESS B

Page 4517 of 5121

NISSAN TEANA 2008 Service Manual TM-44
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P0703 STOP LAMP SWITCH
P0703 STOP LAMP SWITCH
DescriptionINFOID:0000000003848952
BCM detects ON/OFF state of the stop lamp switch and transmits the data to

Page 4518 of 5121

NISSAN TEANA 2008 Service Manual P0703 STOP LAMP SWITCH
TM-45
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK HARNE

Page 4519 of 5121

NISSAN TEANA 2008 Service Manual TM-46
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P0703 STOP LAMP SWITCH
NO >> Replace stop lamp switch. Refer to BR-17, "Exploded View".

Page 4520 of 5121

NISSAN TEANA 2008 Service Manual P0705 PARK/NEUTRAL POSITION SWITCH
TM-47
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P0705 PARK/NEUTRAL POSITION SWITCH
DescriptionINFOID:0000000003848956
The PNP switch is

P0705 PARK/NEUTRAL POSITION SWITCH
TM-47
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P0705 PARK/NEUTRAL POSITION SWITCH
DescriptionINFOID:0000000003848956
The PNP switch is included in the control valve assembly.
The PNP switch includes 4 transmission position switches.
TCM judges the selector lever position by the PNP switch signal.
DTC LogicINFOID:0000000003848957
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
Immediately after performing any “DTC CONFIRMATION PROCEDURE”, always turn ignition switch OFF.
Then wait at least 10 seconds before performing the next test.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Start engine.
4. Drive vehicle and maintain the following conditions for at least 2 consecutive seconds.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0705 PNP SW/CIRC” detected?
YES >> Go to TM-47, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003848958
1.CHECK CVT POSITION
1. Disconnect CVT unit connector.
2. Remove control cable from manual lever. Refer toTM-157, "
Exploded View".
3. Check PNP switch. Refer to TM-48, "
Component Inspection".
Is the inspection result normal?
YES >> Adjust CVT position. Refer to TM-152, "Inspection and Adjustment".
Shift position PNP switch 1 PNP switch 2 PNP switch 3 PNP switch 4 PNP switch 3 (monitor)
P OFF OFF OFF OFF OFF
R ON OFF OFF ON OFF
N ON ON OFF OFF OFF
DONONONON ON
L OFF ON ON OFF ON
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0705 PNP SW/CIRCTCM does not receive the correct voltage
signal (based on the gear position) from the
switch. Harness or connectors
(PNP switches circuit is open or shorted.)
PNP switch
VEHICLE SPEED More than 10 km/h (6 MPH)
ENG SPEED SIG : More than 450 rpm
ACC PEDAL OPEN : More than 1.0/8
