Page 2401 of 5121

NISSAN TEANA 2008 Service Manual EXT-12 < ON-VEHICLE REPAIR > FRONT BUMPER Removal and Installation INFOID:0000000003819530 REMOVAL CAUTION: Bumper fascia is made of resin. Never apply strong force to it, and be careful to prevent co

Page 2402 of 5121

NISSAN TEANA 2008 Service Manual FRONT BUMPER EXT-13 < ON-VEHICLE REPAIR > C D E F G H I J L MA B EXT N O P 7. Pull bumper fascia side toward the vehicle side to disengage the bumper fascia from bumper side brackets (LH/RH). 8. Disen

Page 2403 of 5121

NISSAN TEANA 2008 Service Manual EXT-14 < ON-VEHICLE REPAIR > FRONT BUMPER Front bumper – Headlamp C – C 0.5 – 2.5 mm (0.020 – 0.098 in) — Front bumper – Front fender D – D 0.0 – 0.7 mm (0.000 – 0.028 in)−0.

Page 2404 of 5121

NISSAN TEANA 2008 Service Manual REAR BUMPER EXT-15 < ON-VEHICLE REPAIR > C D E F G H I J L MA B EXT N O P REAR BUMPER Exploded ViewINFOID:0000000003819531 1. Bumper side bracket LH 2. Grommet LH 3. Bumper molding LH 4. Rear fog lamp

Page 2405 of 5121

NISSAN TEANA 2008 Service Manual EXT-16 < ON-VEHICLE REPAIR > REAR BUMPER Removal and Installation INFOID:0000000003819532 REMOVAL CAUTION: Bumper fascia is made of resin. Never apply strong force to it, and be careful to prevent con

Page 2406 of 5121

NISSAN TEANA 2008 Service Manual REAR BUMPER EXT-17 < ON-VEHICLE REPAIR > C D E F G H I J L MA B EXT N O P 6. Pull rear bumper fascia side toward the vehicle side to disen- gage the rear bumper fascia from bumper side bracket (LH/RH)

Page 2407 of 5121

NISSAN TEANA 2008 Service Manual EXT-18 < ON-VEHICLE REPAIR > FRONT GRILLE FRONT GRILLE Exploded ViewINFOID:0000000003819533 Removal and InstallationINFOID:0000000003819534 REMOVAL CAUTION: Apply protection tape around outer circumfe

Page 2408 of 5121

NISSAN TEANA 2008 Service Manual FRONT GRILLE EXT-19 < ON-VEHICLE REPAIR > C D E F G H I J L MA B EXT N O P INSTALLATION Install in the reverse order of removal.
