Page 4497 of 5121
TM-24
< FUNCTION DIAGNOSIS >[CVT: RE0F09B]
CONTROL SYSTEM
*1: Input via CAN communications.
*2: Output via CAN communications.
*3: If these input and output signals are different, the TCM triggers the fail-safe function.Control itemFluid
pressure
controlSelect con-
trolShift con-
trolLock-up
controlCAN com-
munica-
tion controlFail-safe
function
*3
InputPNP switch XXXXXX
Accelerator pedal position signal
*1XXXXXX
Closed throttle position signal
*1X XXX
Engine speed signal
*1XX XXX
CVT fluid temperature sensor X X X X X
Sport mode switch signal
*1X XXX
Stop lamp switch signal
*1X XXX
Primary speed sensor X XXXX
Secondary speed sensor XXXXXX
Primary pressure sensor X X
Secondary pressure sensor X X X
TCM power supply voltage signal XXXXXX
OutputSte p m ot or X X
TCC solenoid valve X X X
Lock-up select solenoid valve X X X
Line pressure solenoid valve X X X X
Secondary pressure solenoid valve X X X
SPORT indicator signal
*2XX
Page 4498 of 5121
CONTROL SYSTEM
TM-25
< FUNCTION DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Component Parts LocationINFOID:0000000003848930
*1: Primary pressure sensor is included in CVT assembly.
*2: Control valve assembly is included in CVT assembly.
NOTE:
The following components are included in control valve assembly (7).
PNP switch
Primary speed sensor
Step motor
Secondary pressure solenoid valve
Line pressure solenoid valve
Torque converter clutch solenoid valve
Shift control valve
Secondary valve
Manual valve
Lock-up select solenoid valve
1. Sport mode switch 2. Shift position indicator 3. SPORT indicator lamp
4.
TCM5. Secondary speed sensor 6.
Primary pressure sensor
*1
7.
Control valve assembly*28. CVT unit connector 9. Accelerator pedal position sensor
A. Control device B. Combination meter C. Engine room LH
D. CVT assembly E. Accelerator pedal, upper
JPDIA0747ZZ
Page 4499 of 5121
TM-26
< FUNCTION DIAGNOSIS >[CVT: RE0F09B]
CONTROL SYSTEM
CVT fluid temperature sensor
Secondary pressure sensor
ROM assembly
Component DescriptionINFOID:0000000003848931
TRANSAXLE ASSEMBLY
EXCEPT TRANSAXLE ASSEMBLY
Name Function
PNP switchTM-47
CVT fluid temperature sensorTM-50
Primary speed sensorTM-52
Secondary speed sensorTM-55
Primary pressure sensorTM-80
Secondary pressure sensorTM-74
Ste p m ot orTM-97
TCC solenoid valveTM-62
Lock-up select solenoid valveTM-94
Line pressure solenoid valveTM-66
Secondary pressure solenoid valveTM-72
Name Function
TCMTM-22
Stop lamp switchTM-44
Page 4500 of 5121
![NISSAN TEANA 2008 Service Manual LOCK-UP AND SELECT CONTROL SYSTEM
TM-27
< FUNCTION DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
LOCK-UP AND SELECT CONTROL SYSTEM
System DiagramINFOID:0000000003848932
System DescriptionI NISSAN TEANA 2008 Service Manual LOCK-UP AND SELECT CONTROL SYSTEM
TM-27
< FUNCTION DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
LOCK-UP AND SELECT CONTROL SYSTEM
System DiagramINFOID:0000000003848932
System DescriptionI](/manual-img/5/57391/w960_57391-4499.png)
LOCK-UP AND SELECT CONTROL SYSTEM
TM-27
< FUNCTION DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
LOCK-UP AND SELECT CONTROL SYSTEM
System DiagramINFOID:0000000003848932
System DescriptionINFOID:0000000003848933
The torque converter clutch piston in the torque converter is engaged to eliminate torque converter slip to
increase power transmission efficiency.
The torque converter clutch control valve operation is controlled by the torque converter clutch solenoid
valve, which is controlled by a signal from TCM. The torque converter clutch control valve engages or
releases the torque converter clutch piston.
When shifting between “N” (“P”) ⇔“D” (“R”), torque converter clutch solenoid valve controls engagement
power of forward clutch and reverse brake.
The lock-up applied gear range was expanded by locking up the
torque converter at a lower vehicle speed than conventional CVT
models.
TORQUE CONVERTER CLUTCH AND SELECT CONTROL VALVE CONTROL
Lock-up Released
In the lock-up released state, the torque converter clutch control valve is set into the unlocked state by the
torque converter clutch solenoid valve and the lock-up apply pressure is drained.
In this way, the torque converter clutch piston is not coupled.
Lock-up Applied
In the lock-up applied state, the torque converter clutch control valve is set into the locked state by the torque
converter clutch solenoid valve and lock-up apply pressure is generated.
In this way, the torque converter clutch piston is pressed and coupled.
Select Control
When shifting between “N” (“P”) ⇔“D” (“R”), optimize the operating pressure on the basis of the throttle posi-
tion, the engine speed, and the secondary pulley (output) revolution speed to lessen the shift shock.
SCIA2374E
JPDIA0312GB
Page 4501 of 5121
TM-28
< FUNCTION DIAGNOSIS >[CVT: RE0F09B]
LOCK-UP AND SELECT CONTROL SYSTEM
Component Parts Location
INFOID:0000000003848934
*1: Primary pressure sensor is included in CVT assembly.
*2: Control valve assembly is included in CVT assembly.
NOTE:
The following components are included in control valve assembly (7).
PNP switch
Primary speed sensor
Step motor
Secondary pressure solenoid valve
Line pressure solenoid valve
Torque converter clutch solenoid valve
Shift control valve
Secondary valve
Manual valve
Lock-up select solenoid valve
1. Sport mode switch 2. Shift position indicator 3. SPORT indicator lamp
4.
TCM5. Secondary speed sensor 6.
Primary pressure sensor
*1
7.
Control valve assembly*28. CVT unit connector 9. Accelerator pedal position sensor
A. Control device B. Combination meter C. Engine room LH
D. CVT assembly E. Accelerator pedal, upper
JPDIA0747ZZ
Page 4502 of 5121
LOCK-UP AND SELECT CONTROL SYSTEM
TM-29
< FUNCTION DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
CVT fluid temperature sensor
Secondary pressure sensor
ROM assembly
Component DescriptionINFOID:0000000003848935
TRANSAXLE ASSEMBLY
EXCEPT TRANSAXLE ASSEMBLY
Name Function
Torque converter regulator valve
TM-22
TCC control valve
Select control valve
Select switch valve
Manual valve
TCC solenoid valveTM-62
Lock-up select solenoid valveTM-94
Primary speed sensorTM-52
Secondary speed sensorTM-55
CVT fluid temperature sensorTM-50
PNP switchTM-47
Forward clutch
TM-19
Reverse brake
Torque converter
Name Function
TCMTM-22
Accelerator pedal position sensorTM-88
Page 4503 of 5121
TM-30
< FUNCTION DIAGNOSIS >[CVT: RE0F09B]
SHIFT CONTROL SYSTEM
SHIFT CONTROL SYSTEM
System DiagramINFOID:0000000003848936
NOTE:
The gear ratio is set for each position separately.
System DescriptionINFOID:0000000003848937
In order to select the gear ratio that can obtain the driving force in accordance with driver's intention and the
vehicle condition, TCM monitors the driving conditions, such as the vehicle speed and the throttle position,
selects the optimum gear ratio, and determines the gear change steps to the gear ratio. Then TCM sends the
command to the step motor, controls the inflow/outflow of line pressure from the primary pulley to determine
the position of the moving-pulley and controls the gear ratio.
“D” POSITION
Shifting over all the ranges of gear ratios from the lowest to the high-
est.
SPORT MODE
Use this position for improved engine braking.
“L” POSITION
JPDIA0745GB
SCIA1953E
JPDIA0685GB
Page 4504 of 5121
SHIFT CONTROL SYSTEM
TM-31
< FUNCTION DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
By limiting the gear range to the lowest position, the strong driving
force and the engine brake can be secured.
DOWNHILL ENGINE BRAKE CONTROL (AUTO ENGINE BRAKE CONTROL)
When a downhill slope is detected with the accelerator pedal released, the engine brake will be strengthened
up by downshifting so as not to accelerate the vehicle more than necessary.
ACCELERATION CONTROL
According to vehicle speed and a change of accelerator pedal angle, driver's request for acceleration and driv-
ing scene are judged. This function assists improvement in the acceleration feeling by making the engine
speed proportionate to the vehicle speed. And a shift map that can gain a larger driving force is available for
compatibility of mileage with driveability.
Component Parts LocationINFOID:0000000003848938
JPDIA0686GB
JPDIA0747ZZ
