Page 4905 of 5121

NISSAN TEANA 2008 Service Manual VTL-94 < ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY] HEATER & COOLING UNIT ASSEMBLY 1. Ventilator seal 2. Defroster seal 3. Distributor upper case 4. Center case 5. Heater & cooling unit case cover 6. Fo

Page 4906 of 5121

NISSAN TEANA 2008 Service Manual HEATER & COOLING UNIT ASSEMBLY VTL-95 < ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY] C D E F G H J K L MA B VTL N O P Removal and InstallationINFOID:0000000003940515 REMOVAL 1. Collect the refrigerant wit

Page 4907 of 5121

NISSAN TEANA 2008 Service Manual VTL-96 < ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY] HEATER & COOLING UNIT ASSEMBLY 8. Remove mounting bolts (A) from heater & cooling unit assembly and blower unit. 9. Remove steering column mounting n

Page 4908 of 5121

NISSAN TEANA 2008 Service Manual HEATER & COOLING UNIT ASSEMBLY VTL-97 < ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY] C D E F G H J K L MA B VTL N O P 16. Remove floor duct 1 (left and right) (1) and rear ventilator duct 1 (2), and then

Page 4909 of 5121

NISSAN TEANA 2008 Service Manual VTL-98 < ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY] MODE DOOR MOTOR MODE DOOR MOTOR Exploded ViewINFOID:0000000003894509 Removal and InstallationINFOID:0000000003894510 REMOVAL 1. Remove BCM. Refer to B

Page 4910 of 5121

NISSAN TEANA 2008 Service Manual AIR MIX DOOR MOTOR VTL-99 < ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY] C D E F G H J K L MA B VTL N O P AIR MIX DOOR MOTOR Exploded ViewINFOID:0000000003894511 Removal and InstallationINFOID:00000000039

Page 4911 of 5121

NISSAN TEANA 2008 Service Manual VTL-100 < ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY] AIR MIX DOOR MOTOR 2. Remove mounting screws (A), and then move foot duct (passen- ger side) (1) to a position where it does not inhibit work. 3. Rem

Page 4912 of 5121

NISSAN TEANA 2008 Service Manual HEATER CORE VTL-101 < ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY] C D E F G H J K L MA B VTL N O P HEATER CORE Exploded ViewINFOID:0000000003894514 1. Ventilator seal 2. Defroster seal 3. Distributor upp
