Page 1809 of 5121

NISSAN TEANA 2008 Service Manual EC-348 < COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE] REFRIGERANT PRESSURE SENSOR REFRIGERANT PRESSURE SENSOR DescriptionINFOID:0000000003856862 The refrigerant pressure sensor is installed at the condenser

Page 1810 of 5121

NISSAN TEANA 2008 Service Manual REFRIGERANT PRESSURE SENSOR EC-349 < COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE] C D E F G H I J K L MA EC N P O NO >> GO TO 3. 3.DETECT MALFUNCTIONING PART Check the following.  Harness connectors F123, E

Page 1811 of 5121

NISSAN TEANA 2008 Service Manual EC-350 < COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE] REFRIGERANT PRESSURE SENSOR YES >> Replace refrigerant pressure sensor. NO >> Repair or replace malfunctioning part.

Page 1812 of 5121

NISSAN TEANA 2008 Service Manual VARIABLE INDUCTION AIR SYSTEM EC-351 < COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE] C D E F G H I J K L MA EC N P O VARIABLE INDUCTION AIR SYSTEM DescriptionINFOID:0000000003856865 Power Valves 1 and 2 (VQ35

Page 1813 of 5121

NISSAN TEANA 2008 Service Manual EC-352 < COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE] VARIABLE INDUCTION AIR SYSTEM Is the inspection result normal? YES >> GO TO 2. NO >>EC-353, " Diagnosis Procedure (VQ35DE engine)". 2.CHECK OVERALL FUNCT

Page 1814 of 5121

NISSAN TEANA 2008 Service Manual VARIABLE INDUCTION AIR SYSTEM EC-353 < COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE] C D E F G H I J K L MA EC N P O Component Function Check (VQ25DE engine)INFOID:0000000003895854 1.CHECK OVERALL FUNCTION W

Page 1815 of 5121

NISSAN TEANA 2008 Service Manual EC-354 < COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE] VARIABLE INDUCTION AIR SYSTEM 1. Stop engine and disconnect vacuum hose connected to power valve actuator 1. 2. Disconnect VIAS control solenoid valve 1

Page 1816 of 5121

NISSAN TEANA 2008 Service Manual VARIABLE INDUCTION AIR SYSTEM EC-355 < COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE] C D E F G H I J K L MA EC N P O 4. When revving engine up to 5,000 rpm quickly. 5. Check vacuum existence under the followi
