NISSAN TEANA 2008 Service Manual PG
BATTERY CHARGING CHART
PG-107
< ON-VEHICLE MAINTENANCE >[POWER SUPPLY&GROUND CIRCUIT]
C
D
E
F
G
H
I
J
K
L B A
O
P N
>> Complete standard charge. Perform “CAPACITY TEST”. Refer to PG-5, "Work

PG
BATTERY CHARGING CHART
PG-107
< ON-VEHICLE MAINTENANCE >[POWER SUPPLY&GROUND CIRCUIT]
C
D
E
F
G
H
I
J
K
L B A
O
P N
>> Complete standard charge. Perform “CAPACITY TEST”. Refer to PG-5, "Work Flow".
CAUTION:
Never use standard charge method on a battery whose specific gravity is less than 1.100.
Set charging current to value specified in “Initial Charging Current Setting (Standard Charge)”. If
charger is not capable of producing specified current value, set its charging current as close to that
value as possible.
Keep battery away from open flame while it is being charged.
When connecting charger, connect leads first, then turn on charger. Never turn on charger first, as
this may cause a spark.
If battery temperature rises above 55°C (131°F), stop charging. Always charge battery when its tem-
perature is below 55°C (131°F).
Quick ChargeINFOID:0000000003809464
1.DETERMINE INITIAL CHARGING CURRENT
1. Determine initial charging current setting and charging time from specific gravity.
2. Check battery type and determine the specified current using the table.
NOTE:
After starting charging, adjustment of charging current is not necessary.
Initial Charging Current Setting and Charging Time (Quick Charge)
CAUTION:
Never use quick charge method on a battery whose specific gravity is less than 1.100.
Set initial charging current to value specified in “Initial Charging Current Setting and Charging Time
(Quick Charge)”. If charger is not capable of producing specified current value, set its charging cur-
rent as close to that value as possible.
Keep battery away from open flame while it is being charged.
When connecting charger, connect leads first, then turn on charger. Never turn on charger first, as
this may cause a spark.
Be careful of a rise in battery temperature because a large current flow is required during quick-
charge operation.
If battery temperature rises above 55°C (131°F), stop charging. Always charge battery when its tem-
perature is below 55°C (131°F).
Never exceed the charging time specified in “Initial Charging Current Setting and Charging Time
(Quick Charge)”, because charging battery over the charging time can cause deterioration of the
battery.
BATTERY TYPE
28B19R(L)
34B19R(L)
46B24R(L)
55B24R(L)
50D23R(L)
55D23R(L)
80D23R(L)
65D26R(L)
80D26R(L)
025 [YUASA type code]
027 [YUASA type code]
067 [YUASA type code]
096 [YUASA type code]
75D31R(L)
95D31R(L)
115D31R(L)
110D26R(L)
95E41R(L)
130E41R(L)
CURRENT [A] 10 15 20 25 30 40
CONVERTED SPECIFIC GRAVITY
1.100 -
1.1302.5 hours
1.130 -
1.1602.0 hours
1.160 -
1.1901.5 hours
1.190 -
1.2201.0 hour
Above
1.2200.75 hour (45 min.)

Page 3626 of 5121

NISSAN TEANA 2008 Service Manual PG-108
< ON-VEHICLE MAINTENANCE >[POWER SUPPLY&GROUND CIRCUIT]
BATTERY CHARGING CHART
>> GO TO 2.
2.CHARGE BATTERY
Charge battery.
>> Complete quick charge. Perform “CAPACITY TEST”. Refer to PG-5,

Page 3627 of 5121

NISSAN TEANA 2008 Service Manual PG
BATTERY
PG-109
< ON-VEHICLE REPAIR >[POWER SUPPLY&GROUND CIRCUIT]
C
D
E
F
G
H
I
J
K
L B A
O
P N
ON-VEHICLE REPAIR
BATTERY
Exploded ViewINFOID:0000000003792690
Removal and InstallationINFOID:0000000

Page 3628 of 5121

NISSAN TEANA 2008 Service Manual PG-110
< ON-VEHICLE REPAIR >[POWER SUPPLY&GROUND CIRCUIT]
BATTERY
Reset electronic systems as necessary. Refer to GI-48, "ADDITIONAL SERVICE WHEN REMOVING BAT-
TERY NEGATIVE TERMINAL : Required Proced

Page 3629 of 5121

NISSAN TEANA 2008 Service Manual PG
BATTERY TERMINAL WITH FUSIBLE LINK
PG-111
< ON-VEHICLE REPAIR >[POWER SUPPLY&GROUND CIRCUIT]
C
D
E
F
G
H
I
J
K
L B A
O
P N
BATTERY TERMINAL WITH FUSIBLE LINK
Exploded ViewINFOID:0000000003792692
Re

Page 3630 of 5121

NISSAN TEANA 2008 Service Manual PG-112
< SERVICE DATA AND SPECIFICATIONS (SDS) [POWER SUPPLY&GROUND CIRCUIT]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
BatteryIN
