2008 NISSAN TEANA Service Manual

turn signal bulb maintenance reset recommended oil isofix airbag off spare tire

Load previous 8 pages

Page 4881 of 5121

NISSAN TEANA 2008 Service Manual VTL-70
< PRECAUTION >[WITH 7 INCH DISPLAY]
PRECAUTIONS
5. Place a known weight (dumbbell or similar weight), between 4.5 and 8.6 kg (10 and 19 lb.) on the center
of the weight scale.
6. Enter the know

Page 4882 of 5121

NISSAN TEANA 2008 Service Manual COMPRESSOR
VTL-71
< PRECAUTION >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
COMPRESSOR
General PrecautionsINFOID:0000000003894453
CAUTION:
Plug all openings to prevent moisture and foreig

Page 4883 of 5121

NISSAN TEANA 2008 Service Manual VTL-72
< PRECAUTION >[WITH 7 INCH DISPLAY]
FLUORESCENT LEAK DETECTOR
FLUORESCENT LEAK DETECTOR
General PrecautionsINFOID:0000000003894454
CAUTION:
The A/C system contains a fluorescent leak detectio

VTL-72
< PRECAUTION >[WITH 7 INCH DISPLAY]
FLUORESCENT LEAK DETECTOR
FLUORESCENT LEAK DETECTOR
General PrecautionsINFOID:0000000003894454
CAUTION:
The A/C system contains a fluorescent leak detection dye used for locating refrigerant leakages. An
ultraviolet (UV) lamp is required to illuminate the dye when inspecting for leakages.
Wear always fluorescence enhancing UV safety goggles to protect eyes and enhance the visibility of
the fluorescent dye.
The fluorescent dye leak detector is not a replacement for an electrical leak detector (SST). The fluo-
rescent dye leak detector should be used in conjunction with an electrical leak detector (SST) to pin-
point refrigerant leakages.
Read and follow all manufacture’s operating instructions and precautions prior to performing the
work for the purpose of safety and customer’s satisfaction.
A compressor shaft seal should not necessarily be repaired because of dye seepage. The compres-
sor shaft seal should only be repaired after confirming the leakage with an electrical leak detector
(SST).
Remove always any remaining dye from the leakage area after repairs are completed to avoid a mis-
diagnosis during a future service.
Never allow dye to come into contact with painted body panels or interior components. Clean imme-
diately with the approved dye cleaner if dye is spilled. Fluorescent dye left on a surface for an
extended period of time cannot be removed.
Never spray the fluorescent dye cleaning agent on hot surfaces (engine exhaust manifold, etc.).
Never use more than one refrigerant dye bottle (1/4 ounce /7.4 cc) per A/C system.
Leak detection dyes for HFC-134a (R-134a) and CFC-12 (R-12) A/C systems are different. Never use
HFC-134a (R-134a) leak detection dye in CFC-12 (R-12) A/C system, or CFC-12 (R-12) leak detection
dye in HFC-134a (R-134a) A/C system, or A/C system damage may result.
The fluorescent properties of the dye remains for three or more years unless a compressor malfunc-
tion occurs.
IDENTIFICATION
NOTE:
Vehicles with factory installed fluorescent dye have a green label.
Vehicles without factory installed fluorescent dye have a blue label.
IDENTIFICATION LABEL FOR VEHICLE
Vehicles with factory installed fluorescent dye have the identification label on the front side of hood.

Page 4884 of 5121

NISSAN TEANA 2008 Service Manual PREPARATION
VTL-73
< PREPARATION >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000003894466
HFC-134a (R-134a) Service Tool and Equipmen

Page 4885 of 5121

NISSAN TEANA 2008 Service Manual VTL-74
< PREPARATION >[WITH 7 INCH DISPLAY]
PREPARATION
(J-42220)
UV lamp and UV safety gogglesPower supply:
DC 12 V (Battery terminal)
For checking refrigerant leak when fluores-
cent dye is install

Page 4886 of 5121

NISSAN TEANA 2008 Service Manual PREPARATION
VTL-75
< PREPARATION >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
PCommercial Service ToolINFOID:0000000003894468
Sealant or/and LubricantINFOID:0000000003894469
HFC-134a (R-134a)

Page 4887 of 5121

NISSAN TEANA 2008 Service Manual VTL-76
< PREPARATION >[WITH 7 INCH DISPLAY]
PREPARATION
Tool name Description
HFC-134a (R-134a) refrigerantContainer color: Light blue
Container marking: HFC-134a (R-
134a)
Fitting size: Thread size

Page 4888 of 5121

NISSAN TEANA 2008 Service Manual AIR CONDITIONER FILTER
VTL-77
< ON-VEHICLE MAINTENANCE >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
ON-VEHICLE MAINTENANCE
AIR CONDITIONER FILTER
Exploded ViewINFOID:0000000003894471
Remova
