NISSAN TEANA 2008 Service Manual TM-56
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P0720 VEHICLE SPEED SENSOR CVT (SECONDARY SPEED SENSOR)
Is the inspection result normal?
YES >> GO TO 11.
NO >> GO TO 2.
2.CHECK POWER AND SENSOR GROUND
1.

Page 4530 of 5121

NISSAN TEANA 2008 Service Manual P0720 VEHICLE SPEED SENSOR CVT (SECONDARY SPEED SENSOR)
TM-57
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or rep

P0720 VEHICLE SPEED SENSOR CVT (SECONDARY SPEED SENSOR)
TM-57
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK HARNESS BETWEEN TCM AND OUTPUT SPEED SENSOR (SECONDARY SPEED SENSOR)
(PART 2)
Check continuity between TCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace damaged parts.
6.CHECK HARNESS BETWEEN IPDM E/R AND OUTPUT SPEED SENSOR (SECONDARY SPEED SEN-
SOR) (POWER) (PART 1)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R vehicle side harness connector terminal and output speed sensor
(secondary speed sensor) vehicle side harness connector terminal.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace damaged parts.
7.CHECK HARNESS BETWEEN IPDM E/R AND OUTPUT SPEED SENSOR (SECONDARY SPEED SEN-
SOR) (POWER) (PART 2)
Check continuity between IPDM E/R vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> Check the following.
Harness for short or open between ignition switch and IPDM E/R
10 A fuse (No. 43, located in IPDM E/R)
Ignition switch
NO >> Repair or replace damaged parts.
8.CHECK HARNESS BETWEEN TCM AND OUTPUT SPEED SENSOR (SECONDARY SPEED SENSOR)
(SENSOR GROUND) (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM vehicle side harness connector terminal and output speed sensor (sec-
ondary speed sensor) vehicle side harness connector terminal.
TCM vehicle side harness connectorOutput speed sensor (secondary speed sensor) ve-
hicle side harness connector
Continuity
Connector Terminal Connector Terminal
F2334F19 2Existed
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F23 34 Not existed
IPDM E/R vehicle side harness connectorOutput speed sensor (secondary speed sensor) ve-
hicle side harness connector
Continuity
Connector Terminal Connector Terminal
F1258F19 3Existed
IPDM E/R vehicle side harness connector
GroundContinuity
Connector Terminal
F12 58 Not existed

Page 4531 of 5121

NISSAN TEANA 2008 Service Manual TM-58
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P0720 VEHICLE SPEED SENSOR CVT (SECONDARY SPEED SENSOR)
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair or replace damaged parts.
9.CHECK HARN

Page 4532 of 5121

NISSAN TEANA 2008 Service Manual P0725 ENGINE SPEED SIGNAL
TM-59
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P0725 ENGINE SPEED SIGNAL
DescriptionINFOID:0000000003848970
The engine speed signal is transmitte

Page 4533 of 5121

NISSAN TEANA 2008 Service Manual TM-60
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P0730 BELT DAMAGE
P0730 BELT DAMAGE
DescriptionINFOID:0000000003848973
TCM selects the gear ratio using the engine load (throttle position), the primary pul

TM-60
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P0730 BELT DAMAGE
P0730 BELT DAMAGE
DescriptionINFOID:0000000003848973
TCM selects the gear ratio using the engine load (throttle position), the primary pulley revolution speed, and
the secondary pulley revolution speed as input signals. Then it changes the operating pressure of the primary
pulley and the secondary pulley and changes the groove width of the pulley.
DTC LogicINFOID:0000000003848974
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
Immediately after performing any “DTC CONFIRMATION PROCEDURE”, always turn ignition switch OFF.
Then wait at least 10 seconds before performing the next test.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Make sure that output voltage of CVT fluid temperature sensor is within the range below.
4. Start engine and maintain the following conditions for at least 30 consecutive seconds.
Is
“P0730 BELT DAMG” detected?
YES >> Go to TM-60, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003848975
1.CHECK DTC
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self-Diagnostic Results” mode for “TRANSMISSION”.
Are any DTC detected?
YES-1 (DTC for “P0730 BELT DAMG” is detected)>>Replace transaxle assembly. Refer to TM-168,
"Exploded View".
YES-2 (DTC except for “P0730 BELT DAMG” is detected)>>Check DTC detected item. Refer to TM-37,
"CONSULT-III Function (TRANSMISSION)".
NO >> GO TO 2.
2.DETECT MALFUNCTIONING ITEMS
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0730 BELT DAMG Unexpected gear ratio detected. Transaxle assembly
ATF TEMP SEN : 1.0 – 2.0 V
If it is out of range, drive the vehicle to decrease the voltage (warm up the fluid) or stop engine to increase the voltage
(cool down the fluid)
Start test from 0 km/h (0 MPH)
Constant acceleration : Keep 30 sec or more
VEHICLE SPEED : 10 km/h (6 MPH) or more
ACC PEDAL OPEN : More than 1.0/8
RANGE : “D” position
ENG SPEED : 450 rpm or more

Page 4534 of 5121

NISSAN TEANA 2008 Service Manual P0730 BELT DAMAGE
TM-61
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection

Page 4535 of 5121

NISSAN TEANA 2008 Service Manual TM-62
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
DescriptionINFOID:0000000003848976
The torque converter clutch s

TM-62
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
DescriptionINFOID:0000000003848976
The torque converter clutch solenoid valve is activated by the TCM in response to signals sent from the vehi-
cle speed and accelerator pedal position sensors. Lock-up piston operation will then be controlled.
Lock-up operation, however, is prohibited when CVT fluid temperature is too low.
When the accelerator pedal is depressed (less than 2.0/8) in lock-up condition, the engine speed shall not
change abruptly. If there is a big jump in engine speed, there is no lock-up.
DTC LogicINFOID:0000000003848977
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
NOTE:
Immediately after performing any “DTC CONFIRMATION PROCEDURE”, always turn ignition switch OFF.
Then wait at least 10 seconds before performing the next test.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Wait at least 10 consecutive seconds.
3. Perform “Self-Diagnostic Results” mode for “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0740 TCC SOLENOID/CIRC” detected?
YES >> Go to TM-62, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003848978
1.CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check resistance between TCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN TCM AND CVT UNIT (TORQUE CONVERTER CLUTCH SOLENOID
VA LV E ) ( PA R T 1 )
1. Disconnect CVT unit connector.
2. Check continuity between TCM vehicle side harness connector terminal and CVT unit vehicle side har-
ness connector terminal.
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0740 TCC SOLENOID/CIRCNormal voltage is not applied to solenoid
due to open or short circuit. Torque converter clutch solenoid valve
Harness or connectors
(Solenoid circuit is open or shorted.)
TCM vehicle side harness connector
GroundResistance (Approx.)
Connector Terminal
F23 38 3.0 – 9.0 Ω

Page 4536 of 5121

NISSAN TEANA 2008 Service Manual P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
TM-63
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damage
