![NISSAN TEANA 2008 Service Manual TM-312
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
ROAD TEST
Cruise Test
INFOID:0000000003806511
1.CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 1
1. Drive vehicle for approximately 10 minutes to war NISSAN TEANA 2008 Service Manual TM-312
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
ROAD TEST
Cruise Test
INFOID:0000000003806511
1.CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 1
1. Drive vehicle for approximately 10 minutes to war](/manual-img/5/57391/w960_57391-4784.png)
TM-312
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
ROAD TEST
Cruise Test
INFOID:0000000003806511
1.CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 1
1. Drive vehicle for approximately 10 minutes to warm engine oil and CVT fluid up to operating temperature.
2. Park vehicle on flat surface.
3. Move selector lever to “P” position.
4. Start engine.
5. Move selector lever to “D” position.
6. Accelerate vehicle at 2/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Is the inspection results normal?
YES >> GO TO 2.
NO >> Refer to TM-286, "
Symptom Table". GO TO 2.
2.CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 2
1. Park vehicle on flat surface.
2. Move selector lever to “D” position.
3. Accelerate vehicle at 8/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Is the inspection results normal?
YES >> GO TO 3.
NO >> Refer to TM-286, "
Symptom Table". GO TO 3.
3.CHECK SPORT MODE CONDITION (PART 1)
1. Park vehicle on flat surface.
2. Push sport mode switch. (Sport mode ON.)
3. Accelerate vehicle at 2/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Is the inspection results normal?
YES >> GO TO 4.
NO >> Refer to TM-286, "
Symptom Table". GO TO 4.
4.CHECK SPORT MODE CONDITION (PART 2)
1. Park vehicle on flat surface.CVT fluid operating temperature : 50 – 80°C (122 – 176°F)
SCIA6644E
SCIA4366E
SCIA6644E
Page 4786 of 5121
![NISSAN TEANA 2008 Service Manual ROAD TEST
TM-313
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Accelerate vehicle at 8/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT- NISSAN TEANA 2008 Service Manual ROAD TEST
TM-313
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Accelerate vehicle at 8/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-](/manual-img/5/57391/w960_57391-4785.png)
ROAD TEST
TM-313
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Accelerate vehicle at 8/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Is the inspection results normal?
YES >> GO TO 5.
NO >> Refer to TM-286, "
Symptom Table". GO TO 5.
5.CHECK “L” POSITION FUNCTION (PART 1)
1. Park vehicle on flat surface.
2. Move selector lever to “L” position.
3. Accelerate vehicle at 2/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Is the inspection results normal?
YES >> GO TO 6.
NO >> Refer to TM-286, "
Symptom Table". GO TO 6.
6.CHECK “L” POSITION FUNCTION (PART 2)
1. Park vehicle on flat surface.
2. Accelerate vehicle at 8/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Does it switch to manual mode?
YES >> GO TO 7.
NO >> Refer to TM-286, "
Symptom Table". GO TO 7.
7.CHECK ENGINE BRAKE FUNCTION
Check engine brake.
Does engine braking effectively reduce vehicle speed in
“L” position?
YES >> 1. Stop the vehicle.
2. Perform self-diagnosis. Refer to TM-204, "
CONSULT-III Function (TRANSMISSION)".
NO >> Refer to TM-286, "
Symptom Table". Then continue trouble diagnosis.
SCIA4366E
SCIA6644E
SCIA4366E
Page 4787 of 5121
![NISSAN TEANA 2008 Service Manual TM-314
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
CVT POSITION
CVT POSITION
Inspection and AdjustmentINFOID:0000000003806512
INSPECTION
1. Place selector lever in “P” position, and turn ignition swi NISSAN TEANA 2008 Service Manual TM-314
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
CVT POSITION
CVT POSITION
Inspection and AdjustmentINFOID:0000000003806512
INSPECTION
1. Place selector lever in “P” position, and turn ignition swi](/manual-img/5/57391/w960_57391-4786.png)
TM-314
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
CVT POSITION
CVT POSITION
Inspection and AdjustmentINFOID:0000000003806512
INSPECTION
1. Place selector lever in “P” position, and turn ignition switch ON (engine stop).
2. Check that selector lever can be shifted to other than “P” position when brake pedal is depressed. Also
check that selector lever can be shifted from “P” position only when brake pedal is depressed.
3. Move the selector lever and check for excessive effort, sticking, noise or rattle.
4. Check that selector lever stops at each position with the feel of engagement when it is moved through all
the positions. Check that the actual position of the selector lever matches the position shown by the shift
position indicator and the manual lever on the transaxle.
5. The method of operating the selector lever to individual posi-
tions correctly should be as shown.
6. When selector button is pressed in “P”, “R”, “N”, “D” or “L” posi-
tion without applying forward/backward force to selector lever,
check button operation for sticking.
7. Check that back-up lamps illuminate only when selector lever is
placed in the “R” position.
8. When in “R” position, check that back-up lamps illuminate even
when the selector lever is pushed toward the “P” position.
CAUTION:
Check the lighting without pressing shift button.
9. Check that the back-up lamps do not illuminate when selector lever is pushed toward the “R” position
when in the “P” or “N” position.
CAUTION:
Check the lighting without pressing shift button.
10. Check that the engine can only be started with the selector lever in the “P” and “N” positions.
11. Check that transaxle is locked completely in “P” position.
ADJUSTMENT
1. Place selector lever in “ P” position.
CAUTION:
Turn wheels more than 1/4 rotations and apply the park lock.
2. Loosen nut (A) and place manual lever (B) in “P” position.
CAUTION:
Never apply any force to the manual lever.
3. Tighten nut. Refer to TM-319, "
Exploded View".
CAUTION:
Fix the manual lever when tightening.
JPDIA0343GB
JPDIA0780ZZ
Page 4788 of 5121
TRANSMISSION CONTROL MODULE
TM-315
< ON-VEHICLE REPAIR >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ON-VEHICLE REPAIR
TRANSMISSION CONTROL MODULE
Exploded ViewINFOID:0000000003806513
Removal and InstallationINFOID:0000000003806514
REMOVAL
CAUTION:
Never impact on TCM when removing or installing TCM.
1. Disconnect the battery cable from negative terminal.
2. Remove the air duct (inlet). Refer to EM-26, "
Exploded View".
3. Disconnect the TCM connector (A).
4. Remove the TCM (1) from the bracket.
INSTALLATION
Note the following, and install in the reverse order of removal.
1. Bracket 2. TCM
: Vehicle front
Refer to GI-4, "
Components" for symbols in the figure.
JPDIA0591GB
: Vehicle front
JPDIA0596ZZ
Page 4789 of 5121
TM-316
< ON-VEHICLE REPAIR >[CVT: RE0F10A]
TRANSMISSION CONTROL MODULE
CAUTION:
After TCM is replaced, refer to TM-179, "
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT :
Service After Replacing TCM and Transaxle Assembly".
Page 4790 of 5121
CONTROL DEVICE
TM-317
< ON-VEHICLE REPAIR >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
CONTROL DEVICE
Exploded ViewINFOID:0000000003890382
Removal and InstallationINFOID:0000000003890383
REMOVAL
1. Disconnect the battery cable from the negative terminal.
1. Selector lever knob 2. Lock pin 3. Knob cover
4. Control device assembly 5. Shift lock unit 6. Dust cover
Refer to GI-4, "
Components" for symbols in the figure.
JPDIA0741GB
Page 4791 of 5121
![NISSAN TEANA 2008 Service Manual TM-318
< ON-VEHICLE REPAIR >[CVT: RE0F10A]
CONTROL DEVICE
2. Slide knob cover (1) below selector lever downward.
CAUTION:
Be careful not to damage knob cover.
3. Pull lock pin (2) out of selector leve NISSAN TEANA 2008 Service Manual TM-318
< ON-VEHICLE REPAIR >[CVT: RE0F10A]
CONTROL DEVICE
2. Slide knob cover (1) below selector lever downward.
CAUTION:
Be careful not to damage knob cover.
3. Pull lock pin (2) out of selector leve](/manual-img/5/57391/w960_57391-4790.png)
TM-318
< ON-VEHICLE REPAIR >[CVT: RE0F10A]
CONTROL DEVICE
2. Slide knob cover (1) below selector lever downward.
CAUTION:
Be careful not to damage knob cover.
3. Pull lock pin (2) out of selector lever knob (3).
4. Remove selector lever knob and knob cover.
5. Remove center console assembly. Refer to IP-22, "
Exploded
View".
6. Remove control cable (1) from control device assembly. Refer to
TM-319, "
Exploded View".
7. Remove control device assembly (2).
8. Remove control device connector (A) using a flat-bladed screw-
driver (B).
CAUTION:
Be careful not to damage control device connector.
9. Remove shift lock unit from control device assembly.
INSTALLATION
Note the following, and install in the reverse order of removal.
When installing control cable (1) to control device assembly (2),
check that control cable is fully pressed in with the ribbed (A) surface
facing upward.
Inspection and AdjustmentINFOID:0000000003890384
ADJUSTMENT AFTER INSTALLATION
Adjust the CVT positions after installing control device. Refer to TM-152, "Inspection and Adjustment".
INSPECTION AFTER INSTALLATION
Check the CVT positions after adjusting the CVT positions. Refer to TM-152, "Inspection and Adjustment".
JPDIA0606ZZ
: Bolt
JPDIA0615ZZ
JPDIA0616ZZ
JPDIA0609ZZ
Page 4792 of 5121
CONTROL CABLE
TM-319
< ON-VEHICLE REPAIR >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
CONTROL CABLE
Exploded ViewINFOID:0000000003806518
Removal and InstallationINFOID:0000000003806519
REMOVAL
CAUTION:
Check that parking brake is applied before removal/installation.
1. Disconnect control cable from control device assembly. Refer to TM-319, "
Exploded View".
2. Remove the air duct (inlet) and air cleaner case. Refer to EM-26, "
Exploded View".
3. Remove control cable (1) from manual lever (A).
4. Remove lock plate (2) from control cable.
5. Remove control cable from bracket 2 (3).
6. Remove exhaust front tube. Refer to EX-5, "
Exploded View".
7. Remove heat plate.
1. Bracket 1 2. Lock plate 3. Bracket 2
4. Transaxle assembly 5. Control cable 6. Control device assembly
Refer to GI-4, "
Components" for symbols in the figure.
JPDIA0742GB
: Nut
JPDIA0738ZZ
